GE PVW7301 Installation Instructions Manual

I stallatio
I structios
GJass WalJ
Chimney Vent Hoods
PVW7301, PVW7361
Pl "If you have questions, call 800.GE.CARES (800.432.2737) or visit our website at: GEAppliances.com"
BEFORE YOU BEGIN
Read these instructions completely and
carefully.
.IMPORTANT - Save these
instructions
forlocal inspector's use.
,IMPORTANT - Observe all
governing
codes and ordinances.
, Note to Installer- Be sure to leavethese
instructions withthe Consumer.
, Note to Consumer - Keep these instructions
forfuturereference.
, Skill l evel - Installation of thisvent hood
requires basicmechanical and electrical skills.
,
Completion time
- Approximately i to 3 hours
, Proper installation isthe responsibility ofthe
installer.
* Product failure due to improper installation is
not covered under the Warranty.
^,,-
C AUTION:
Due to the weight and sizeof
these vent hoods and to reduce the risk of
personalinjury or damage to the product, TWO
PEOPLE ARE REQUIRED FOR PROPER
INSTALLATION.
FOR YOUR SAFETY:
AWARNING:
Beforebeginningthe
installation, switch power off at service panel and
lock the service disconnecting means to prevent
power from being switched on accidentally.
When the service disconnecting means cannot
be locked, securely fasten a prominent warning
device, such as a tag, to the service panel.
kLW/'_I_I_i I I_i_: TO REDUCE THE RISK
OF FIRE, ELECTRIC SHOCK OR INJURY TO
PERSONS, OBSERVE THE FOLLOWING:
A. Installation work and electrical wiring
must be done by qualified person(s) in
accordance with all applicable codes and
standards, including fire-rated construction.
B. Sufficient air is needed for proper
combustion and exhausting of gases
through the flue (chimney) of fuel burning
equipment to prevent back drafting. Follow
the heating equipment manufacturer's
guidelines and safety standards such
as those published by the National Fire
Protection Association (NFPA), the
American Society for Heating, Refrigeration
and Air Conditioning Engineers (ASHRAE)
and the local code authorities.
C.
D.
E.
When cutting or drilling into wall or ceiling,
do not damage electrical wiring and other
hidden utilities.
Ducted fans must always be vented to the
outdoors.
Turn off breaker to adjacent rooms while
working.
A, ,,,^,-., ,,,, ,., ,,'-
_W/4LKi_ilI_i_: TO REDUCE THE RISK
OF FIRE, USE ONLY METAL DUCT WORK.
!
Z
r-
r-
!
O
Z
!
Z
-4
C
N
-4
!
O
Z
