Toyota 08691-00834 Installation Instructions Manual
Cd-changer; subwoofer for toyota yaris 2005
Hide thumbs
Also See for 08691-00834:
- Installation instructions manual (24 pages) ,
- Installation instructions manual (25 pages) ,
- Installation instructions manual (24 pages)
Related Manuals for Toyota 08691-00834
Summary of Contents for Toyota 08691-00834
- Page 1 Yaris AUDIO RHD installation instructions Model year: 2005 Vehicle code: **P90R-****KW Part number: • CD-Changer: 08601-00911 • Subwoofer: 08691-00834 Manual ref. n : AIM 000 481-01...
-
Page 2: Table Of Contents
Yaris AUDIO Revision Record Rev. Nr. Datum Seite Abbildung Aktualisierung Gelöschte Schritte Rev. N Date Page Picture Update Deleted steps No. version Date Page Image Mise à jour Nouveau Etapes supprimées Application Application 02-07 Chart Chart Europe Application Application 02-07 Chart Chart Japan 02-07... -
Page 3: Precautions
Yaris AUDIO PRECAUTIONS PLEASE READ THOROUGHLY THESE PRECAUTIONS BEFORE THE INSTALLATION . • Protect your car with fender • Be sure to disconnect the nega- tive (-) lead from the battery ter- covers, seat and so on. minals. • Use the correct tool when •... - Page 4 Yaris AUDIO TABLE OF CONTENTS Revision Record ..........................Precautions ............................Application Chart Europe production .................... Application Chart Japan production ....................AUDIO Installation Instructions • Vehicle Disassembly ........................• CD-Changer Installation ......................• Subwoofer Installation ......................02-07 Yaris (RHD) - 4...
-
Page 5: Application Chart Europe Production
Yaris AUDIO APPLICATION CHART EUROPE PRODUCTION Yaris (RHD) - 5 02-07... -
Page 6: Application Chart Japan Production
Yaris AUDIO APPLICATION CHART JAPAN PRODUCTION 02-07 Yaris (RHD) - 6... -
Page 7: Vehicle Disassembly
Yaris AUDIO VEHICLE DISASSEMBLY Put protective tape on the shaded areas. CAUTION Be sure to remove the parts carefully so you do not damage the panels. Fig. 1 Remove the center cluster panel (L) and (R) : Clip (6x) : Hook (8x) Fig. - Page 8 Yaris AUDIO Remove the audio unit : Clip (4x) : Screw (4x) Fig. 4 FOR EUROPE PRODUCTION Remove the scuff plate and the cowl side trim on the driver’s side. : Clip (1x) (Cowl side trim) : Hook (1x) (Cowl side trim) : Clip (2x) (Scuff plate) : Hook (2x) (Scuff plate) Fig.
- Page 9 Yaris AUDIO FOR JAPAN PRODUCTION Remove the scuff plate and the cowl side trim on the passenger’s side. : Clip (1x) (Cowl side trim) : Hook (1x) (Cowl side trim) : Clip (2x) (Scuff plate) : Hook (2x) (Scuff plate) Fig.
-
Page 10: Cd-Changer Installation
Yaris AUDIO CD-CHANGER INSTALLATION Cut one tape into ten pieces and another tape into six as shown in the picture. • : Component part of CD changer kit Fig. 1 08695-00370 FOR EUROPE PRODUCTION Route the changer wire by using the tape pieces. -
Page 11: Step
Yaris AUDIO Cut the floor carpet. Fig. 4 Route the changer wire . Bundle excess wire and tape with the large tape as shown by going through the hole of the cross member near the door. Excess wire Hole Fig. 5 Replace the carpet and pull through the changer wire . -
Page 12: Step
Yaris AUDIO Install the changer unit to the brack- b) Connect the changer wire to the changer unit : Screw (4x) • : Component part of CD changer kit Fig. 7 FOR JAPAN PRODUCTION Turn the floor carpet with felt. b) Route and tape the subwoofer wire with tapes Floor carpet... -
Page 13: Step
Yaris AUDIO 10. Attach the spacers and the tapes to the base bracket : Screw (M5x10) (4x) : Spacer with nut (4x) : Tape (2x) Fig. 10 11. Attach the base bracket to the floor and fold back the cut parts of the carpet Fig. -
Page 14: Step
Yaris AUDIO 12. Install the side brackets to the chang- er unit : Side bracket (2x) : Flat head screw (M5x8) (4x) Screw Hole position on the Hole position on the left side (G) right side (G) Fig. 12 13. Install the changer unit Connect the changer wire to the changer unit... -
Page 15: Subwoofer Installation
Yaris AUDIO SUBWOOFER INSTALLATION Put protective tape on the shaded areas. CAUTION Be sure to remove the parts carefully so you do not damage the panels. Fig. 1 Remove the center cluster panel (L) and (R) : Clip (6x) : Hook (8x) Fig. -
Page 16: Step
Yaris AUDIO Remove the audio unit : Clip (4x) : Screw (4x) Fig. 4 Remove the scuff plate and the cowl side trim on the passenger’s side. : Clip (1x) (Cowl side trim) : Hook (1x) (Cowl side trim) : Clip (2x) (Scuff plate) : Hook (2x) (Scuff plate) Fig. - Page 17 Yaris AUDIO Fit brackets to the subwoofer : Screw with washer (4x) • : Component part of audio mounting kit PZ425-B0221-60 • : Component part of subwoofer kit Fig. 7 Cut the carpet with felt as shown in the illustration. 130mm 100mm 60mm...
- Page 18 Yaris AUDIO Turn the floor carpet with felt. b) Route and tape the subwoofer wire with tapes Floor carpet Excess wire Fig. 10 11. Connect the subwoofer wire harness 10P Audio connector to the 10P audio connector of the vehi- cle wire harness and to the audio unit Fig.
- Page 19 Yaris AUDIO Replace the floor carpet with felt. b) Fit the base bracket to the floor using adhesive tape • : Component part of audio mounting kit PZ425-B0221-60 Fig. 13 14. Mount the subwoofer as shown in the illustration and connect the sub- woofer wire to the subwoofer 32mm...
- Page 20 GENUINE PARTS...
