YASKAWA CIMR-RB Series Instruction Manual

R1000 series, power regenerative unit, 200 v class, three-phase input: 3.5 to 105 kw 400 v class, three-phase input: 3.5 to 300 kw
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
YASKAWA R1000 Series
Power Regenerative Unit
Instruction Manual
Type: CIMR-RA
CIMR-RD
Models: 200 V Class, Three-Phase Input: 3.5 to 105 kW
400 V Class, Three-Phase Input: 3.5 to 300 kW
To properly use the product, read this manual thoroughly and retain
for easy reference, inspection, and maintenance. Ensure the end user
receives this manual.
MANUAL NO. TOEP C710656 10B
, CIMR-RB
,
, CIMR-RT
Receiving
Mechanical Installation
Electrical Installation
Start-Up Programming &
Operation
Troubleshooting
Periodic Inspection &
Maintenance
Standard Configuration Devices,
Peripheral Devices, and Options
Specifications
Parameter List
MEMOBUS/Modbus
Communications
Standards Compliance
1
1
2
2
3
3
4
4
5
5
6
6
7
7
A
A
B
B
C
C
E
D
D
