Liebert Nfinity User Manual page 44

Alarm Message
Load exceeds frame
limit
Battery Card Warning
Battery Card Failure
Configuration error! Re-
enter settings
Assert manual bypass
Output must be on
External Battery Mod-
ule Warning
External Battery Mod-
ule Failure
System Is Not Ready
Please Wait
Power Module Is Not
Ready - Please Wait
Please Review Or Set
Configuration
Not Available Due To
System Failure
Battery module commu-
nication failed
Power module commu-
nication failed
UI is not compatible with
this system
Reminder alarm - Check
air filter
Abnormal battery volt-
age
Comm failure, switch to
manual bypass
Internal comms failure
Cause
Load is greater then the rated
frame limit.
Something abnormal occurring
An Intelli-Battery Card has failed
The configurations in the UI and
ASC do not match.
If the user does a switch to man-
ual bypass from the UI they will
be prompted to physically switch
to manual bypass with this alarm.
The UPS's output must be on
prior to selecting bypass from the
UI. This alarm will be generated if
the customer requests bypass
from the UI when the output is
not on. [NM UPS General Warn-
ing]
Something abnormal occurring
with the external battery system
There is a failed battery in the
external battery system
The UPS's output could not be
turned on because the system
initialization is not yet complete.
The UPS's output could not be
turned on because the Power
Module initialization is not yet
complete.
The configurations in the UI and
ASC do not match.
The UPS's output could not be
turned on because there is a sys-
tem failure.
CAN communication between
the SC and a Battery Module
have failed.
CAN communication between
the SC and a Power Module
have failed.
The User Interface is not com-
patible with the current System
Control.
Fan Filter alarm is enabled and
time interval has passed
Abnormally low battery bus volt-
age
The User Interface has detected
a can bus off
The User Interface has detected
a can bus off
Remove some of the connected load
Contact qualified assistance
Replace faulty card
To clear, review or change configuration settings
Close manual bypass switch
Push UPS output button
Contact qualified assistance
Contact qualified assistance
Wait 30 seconds for alarm to clear
Wait 30 seconds for alarm to clear
To clear either review or change configuration set-
tings
Wait 30 seconds for alarm to clear
Contact qualified assistance
Contact qualified assistance
Contact qualified assistance
Make sure transformer air filter is free of dust
Contact qualified assistance
Contact qualified assistance
Contact qualified assistance
38
Action
