Lorex LNE3142R SERIES Quick Start Manual

Contents
• IP Dome Camera*
• Mounting Kit*
• Mounting Template*
• Cat5e Ethernet Extension Cable*
* Per camera.
ATTENTION - It is recommended to connect the camera
to the NVR or an external PoE switch. If using a DC
power adapter with the camera, a REGULATED UL / CSA
APPROVED power supply is REQUIRED for use with this
camera. Use of a non-regulated, non-conforming power
supply can damage this product and voids the warranty.
Features
• High definition 1080p image sensor delivers superior
detail*
• Infrared cut filter ensures accurate color representation
• Anti-glare feature ensures clear images under strong
lighting conditions
• Split glass design minimizes IR reflection
• Weatherproof for outdoor & indoor installation (IP66
Rated)**
• Vandal resistant design
• Heavy-duty durable metal housing
• Simple installation of video and power on a single cable
with Power over Ethernet (POE) CAT5e cable
• Versatile ceiling or wall mounting options
• Expand your coverage with camera Ethernet cable up to
300' from the NVR
Disclaimers:
* Compatible with Lorex HD NVR LNR100/LNR400/LNR500 series only
** Not intended for submersion in water. Installation in a sheltered location recommended.
Warning/Caution
• Use the camera only with compatible Lorex NVRs
• Read this guide carefully and keep it for future reference
• Follow all instructions for safe use of the product and
handle with care
• Use the camera within given temperature, humidity and
voltage levels noted in Camera Specifications
• Do not disassemble the camera
• Do not point the camera directly towards the sun or a
source of intense light
• Periodic cleaning may be required. Use a damp cloth
only. Do not use harsh cleaners or aerosol cleaners
• The supplied extension cable is rated for surface
mounting only
• Cables for in-wall / floor-to-floor installations are sold
separately

Installation Tips

• Point the camera where there is the least amount of
obstructions (i.e. tree branches)
• Install the camera in a location that is difficult for vandals
to reach
• Secure cabling so that it is not exposed or easily cut
• Camera rated for outdoor use. Installation in a sheltered
location recommended
Dimensions
94mm / 3.7"
79mm / 3.9"
FOR SUPPORT AND INFORMATION,
VISIT WWW.LOREXTECHNOLOGY.COM
Specification Sheets
Product Information
User Manuals
Software Upgrades
Quick Start Guides Firmware Upgrades
