NETGEAR DGN2200 Quick Setup Manual

Quick Setup Guide for DGN2200
1. Connect DGN2200 to PC with an Ethernet cable.
2. Connect power supply and DSL line
3. Wait 1 minute, check the front panel, if the DSL LED light keep stable green, that
means both the router and your DSL service are good. If not, then please check if
your ADSL service is activated and your DSL line is working.
4. Input http://10.1.1.1/ in the address bar of your Internet browser.
Username: admin
Password: password
5. On the left hand side of screen, click "Basic Setting":
Un-tick the box "connect to Optus",
Encapsulation: PPPoE
Username: your ADSL username(provided by your ISP)
Password: your ADSL password
Then APPLY
6. On the left hand side of screen, click "Wireless basic setting"
Choose WAP and setup your own security key (at least 8 characters).
Note: if the modem can pass step 3 but still not connected, please double check your
username and password, we see many cases previously that customer's username
and password is incorrect, please double check with your ISP, as sometimes the
password may not same as the one your setup with your ISP, especially for TPG
Thank you.
