Quick Start Guide

Long Range Mesh Access Point

M36

1. Plug one end of the Ethernet cable into the RJ-45 port on the rear panel of the device and another end into your PC/Notebook.

2. Insert the DC-inlet of the power adapter into the port labeled "DC-IN" and the other end into the power socket on the wall.

This diagram depicts the hardware configuration

Ethernet

M36

AC/DC cable

Power Outlet

Press 1 second

Reset/Reboot

Press 5 seconds

Reset to factory default

DC-inlet for Power

Ethernet Port for RJ-45 cable

-1-

Page 1: Quick Start Guide
Quick Start Guide Long Range Mesh Access Point Physical Setup Hardware Installation 1. Plug one end of the Ethernet cable into the RJ-45 port on the rear panel of the device and another end into your PC/Notebook. 2. Insert the DC-inlet of the power adapter into the port labeled “DC-IN” and the other end into the power socket on the wall. This diagram depicts the hardware configuration Ethernet AC/DC cable...
Page 2: Software Installation
Software Installation IP Address Configuration The default IP address of the device is 192.168.1.1. In order to log into this device, you must first configure the TCP/IP settings of your PC/Notebook. 1. In the control panel, double click Network Connections and then double click on the connection of your Network Interface Card (NIC). You will then see the following screen.
