TP-Link TL-POE200A User Manual

User Guide

Power over Ethernet Adapter Kit
TL-POE200A (PoE Injector)
TL-POE200B (PoE Splitter)
Package Contents: TL-POE200 Power over Ethernet Adapter Kit, Ethernet Cable, Female-to-Female Power Connector, DC Power Adapter, User Guide
Connection
Use the Power over Ethernet Adapter Kit to supply power and transmit data to a Non-PoE device.
Power Socket
Note: TL-POE200 Power over Ethernet Kit is not compliant with IEEE 802.3af standard. The PoE Injector and PoE
Splitter can only be used together. Pairing TL-POE200A or TL-POE200B with any other devices is dangerous.
Power LED Explanation
PoE Injector:
LAN IN
Steady green
adapter is working properly.
Ethernet Device PoE Injector
(switch, router, etc.)
PWR DC 48V
indicates that the power
PoE Splitter
LAN IN PWR DC 48V LAN OUT
PoE Splitter:
Steady green
can supply power.
For more information, please visit our website:
Note:
Set the required voltage
of the non-PoE device
before cable connection.
12V 9V 5V
PWR DC OUT
LAN OUT PWR DC OUT
indicates the PoE Splitter
http://www.tp-link.com
7106506699 REV3.0.0
Non-PoE Device
