  • Page 3 Preface Notebook Computer M740TG/M748TG-C/M765TG/W765TG Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 Preface About this Manual This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the M740TG/ M748TG-C/M765TG/W765TG series notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 7: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...

  • Page 8: Power Safety

    Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.

  • Page 9: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
  • Page 10 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. VIII...

  • Page 11: Table Of Contents

    Preface Contents Introduction ..........1-1 Top without Fingerprint (M740TG) ..........A-3 Top without Fingerprint (M748TG-C) .......... A-4 Overview ..................1-1 Bottom (M740TG/M748TG-C) ............. A-5 System Specifications ..............1-2 LCD (M740TG/M748TG-C) ............A-6 External Locator - Top View with LCD Panel Open ......1-4 DVD-Dual Drive (M740TG/M748TG-C) ........A-7 External Locator - Front &...
  • Page 12 Preface VGA N10M-GE1-3 ..............B-18 FingerPrint Board for M74 ............B-50 VGA N10M-GE1-4 ..............B-19 Power Switch Board for M76 ............B-51 VGA N10M-GE1-5 ..............B-20 External ODD Board for W76 ............B-52 VGA N10M-GE1-6 ..............B-21 VGA N10M-GE1-7 ..............B-22 ICH9M 1/4, SATA ............... B-23 ICH9M 2/4, PCI, USB ..............

  • Page 13: Introduction

    Introduction Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the M740TG/M748TG-C/M765TG/W765TG series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about drivers (e.g. VGA & audio) is also found in User’s Manual. That manual is shipped with the computer.

  • Page 14: System Specifications

    Introduction System Specifications Memory Interface Processor 64-bit Wide DDRII (DDR2) Data Channel Three USB 2.0 Ports Intel® Celeron® Processor Two 200 Pin SO-DIMM Socket Supporting One Headphone-Out Jack T3100 (1.9GHz), T3000 (1.8GHz) DDRII (DDR2) at 667MHz/800MHz One Microphone-In Jack 45nm (45 Nanometer) Process Technology, Memory Expandable up to 4GB One S/PDIF-Out Jack 1MB L2 Cache &...
  • Page 15 Introduction Communication Environmental Spec Built-In 56K MDC Modem, V.90 & V.92 Temperature Compliant ° ° Operating: C - 35 Non-Operating: -20°C - 60°C Built-In Gigabit Ethernet LAN Relative Humidity 802.11b/g Wireless LAN Mini-Card Module Operating: 20% - 80% with USB Interface Non-Operating: 10% - 90% Intel®...

  • Page 16: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. Optional Built-In PC Camera 2. LCD 3. Speakers 4. Power Button 5. Hot Key Buttons 6. Keyboard 7. Built-In Microphone 8. Touchpad & Buttons 9. LED Indicators M740TG/M748TG M765TG W765TG...

  • Page 17: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right side Views Figure 2 Front Views 1. LED Power & Communication Indicators Figure 3 Right Side Views 1. S/PDIF-Out Jack 2. Microphone-In Jack 3. Headphone-Out Jack 4. USB 2.0 Port 5. Optical Device Drive Bay 6.

  • Page 18: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. DC-In Jack 2. External Monitor Port 3. RJ-45 LAN Jack 4. Vent/Fan Intake/ Outlet 5. 2 * USB 2.0 Ports 6. ExpressCard Slot 7. 7-in-1 Card Reader Figure 5 Rear View...

  • Page 19: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Battery 2. Bluetooth Module Cover 3. RAM & CPU Bay Cover 4. Vent/Fan Intake/ Outlet 5. Hard Disk Bay Cover M740TG/M748TG-C M765TG  Overheating To prevent your com- puter from overheating make sure nothing...

  • Page 20: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. Transformer 2. RTL8111C 3. ExpressCard Connector 4. KBC ITE IT8502E-J 1 - 8 Mainboard Overview - Top (Key Parts)

  • Page 21: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. CPU Socket (no CPU installed) 2. North Bridge 3. Memory Slots DDR2 SO-DIMM 4. ICS 9LPR363EGLF 5. Card Reader Socket 6. South Bridge 7. Audio Codec ALC662GR 8.

  • Page 22: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. USB Port 2. Inverter Connector 3. Speaker Connector 4. LCD Cable Connector 5. Power Board Connector 6. Keyboard Cable Connector 7. Audio Board Connector 8. Microphone Cable Connector 9.

  • Page 23: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. BT Cable Connector 2. Multi Board Connector 3. CD-ROM Connector 4. HDD Connector 5. CMOS Bat. Connector 6. CPU Fan Cable Connector 7. DC-In Jack Mainboard Overview - Bottom (Connectors) 1 - 11...
  • Page 24 Introduction 1 - 12...

  • Page 25: Disassembly

    Disassembly Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the M740TG/M748TG-C/M765TG/W765TG series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart. The overall design pictured in this manual may appear slightly different from your model design (these designs are sub- ject to change and up-grade without notice), however the disassembly procedures illustrated should still be correct.

  • Page 26: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 27: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 28: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the Wireless LAN Module: 1. Remove the battery page 2 - 5 1.

  • Page 29: Removing The Battery

    Disassembly Removing the Battery 1. Turn the computer off, and turn it over. Figure 1 2. Slide the latch in the direction of the arrow. Battery Removal 3. Slide the latch in the direction of the arrow, and hold it in place. 4.

  • Page 30: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm Figure 2 (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in HDD Assembly Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 31 Disassembly For M740TG/M748TG-C computers: Figure 3 4. Grip the tab and slide the hard disk in the direction of arrow HDD Assembly 5. Lift the hard disk out of the bay Removal (cont’d.) 6. Remove the screw and the adhesive cover from the hard disk 7.
  • Page 32 Disassembly For M765TG/W765TG computers: Figure 4 8. Grip the tab and slide the hard disk in the direction of arrow HDD Assembly 9. Lift the hard disk out of the bay Removal (cont’d.) 10. Remove the screws & and the adhesive cover from the hard disk 11.

  • Page 33: Removing The Optical (Cd/Dvd) Device

    Disassembly Removing the Optical (CD/DVD) Device Figure 5 Optical Device 1. Turn off the computer, and remove the battery (page 2 - Removal 2. M740TG/M748TG-C: (see over for M765TG/W765TG) Locate the component bay cover and remove screws a. Remove the screws. 3.
  • Page 34 Disassembly Figure 6 8. M765TG/W765TG: Locate the hard disk bay cover and remove screws & Optical Device 9. Remove the hard disk bay cover Removal (cont’d.) 10. Remove the screw at point , and use a screwdriver to carefully push out the optical device at point 11.

  • Page 35: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 7 The computer has two memory sockets for 200 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting RAM Module DDR2 667/800MHz. The main memory can be expanded up to 4GB. The SO-DIMM modules supported are 1024MB, Removal and 2048MB and DDRII Modules.
  • Page 36 Disassembly 5. Gently pull the two release latches ( & on the sides of the memory socket in the direction indicated by the Figure 8 arrows (Figure 8c). RAM Module Removal (cont’d.) c. Pull release latch(es). d. Remove the module(s). e.

  • Page 37: Removing The Inverter Board

    Disassembly Removing the Inverter Board Figure 9 Inverter Board 1. Turn off the computer, and remove the battery (page 2 - Removal 2. Remove any rubber covers, screws (Figure 9a), then run your finger around the middle of the frame to carefully unsnap the LCD front panel module from the back.

  • Page 38: Removing And Installing The Processor

    Disassembly Removing and Installing the Processor Processor Removal Procedure Figure 10 Processor Removal 1. Turn off the computer, remove the battery (page 2 - 5) and the component bay cover (page 2 - 11). 2. The CPU heat sink will be visible at point on the mainboard.
  • Page 39 Disassembly 5. Turn the release latch towards the unlock symbol , to release the CPU (Figure 11a). Figure 11 6. Carefully (it may be hot) lift the CPU up out of the socket (Figure 11b). Processor Removal 7. See page 2 - 16 for information on inserting a new CPU.
  • Page 40 Disassembly Processor Installation Procedure Figure 12 Processor 1. Insert the CPU , pay careful attention to the pin alignment, it will fit only one way (DO NOT FORCE IT!), and turn Installation the release latch towards the lock symbol (Figure 12b).

  • Page 41: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 13 Wireless LAN 1. Turn off the computer, remove the battery (page 2 - 5) and the component bay cover (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard.

  • Page 42: Removing The Bluetooth Module

    Disassembly Removing the Bluetooth Module Figure 14 Bluetooth Module 1. Turn off the computer, remove the battery (page 2 - Removal 2. Locate the Bluetooth bay cover, and remove the screw and cover 3. Remove the screw and turn the module over. a.

  • Page 43: Removing The Keyboard

    Disassembly Removing the Keyboard 1. Turn off the computer, and remove the battery (page 2 - Figure 15 2. Press the four keyboard latches at the top of the keyboard to elevate the keyboard from its normal position (you Keyboard Removal may need to use a small screwdriver to do this).

  • Page 44: Removing The Modem

    Disassembly Removing the Modem Figure 16 1. Turn off the computer, remove the battery (page 2 - 5), HDD (page 2 - 6), component bay cover (page 2 - 11), Modem Removal optical device (page 2 - 9), CPU (page 2 - 14), bluetooth (page 2 - 18) and keyboard...
  • Page 45 Disassembly 5. Carefully lift the top case up and off the computer (Figure 17d). Figure 17 6. Remove screws (Figure 17e) from the computer. Modem Removal 7. Remove screws (Figure 17f) from the modem module. (cont’d.) 8. Lift the modem up and separate the modem from the connector 9.
  • Page 46 Disassembly 2 - 22...

  • Page 47: Part Lists

    Part Lists Appendix A: Part Lists This appendix breaks down the M740TG/M748TG-C/M765TG/W765TG series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 48: Part List Illustration Location

    Part Lists Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A- 1 Part List Illustration Location Parts M740TG M748TG-C M765TG W765TG Top without Fingerprint page A - 3 page A - 4 page A - 8 page A - 12 Bottom...

  • Page 49: Top Without Fingerprint (M740Tg

    Part Lists Top without Fingerprint (M740TG) Figure A - 1 Top without Fingerprint (M740TG) 白色 (無鉛) 無鉛 無電鍍 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 Top without Fingerprint (M740TG) A - 3...

  • Page 50: Top Without Fingerprint (M748Tg-C

    Part Lists Top without Fingerprint (M748TG-C) Figure A - 2 Top without Fingerprint (M748TG-C) 黑色 (無鉛) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 A - 4 Top without Fingerprint (M748TG-C)

  • Page 51: Bottom (M740Tg/M748Tg-C

    Part Lists Bottom (M740TG/M748TG-C) 無鉛 無鉛 無鉛 無鉛 無鉛 日東 無鉛 無鉛 無鉛 無鉛 Figure A - 3 無鉛 無鉛 海華 無鉛 Bottom (M740TG/ 無鉛 無鉛 M748TG-C) (富士弘)無鉛 無鉛 變更 (鼎緯) 區加長 無鉛 無鉛 無鉛 日東 無鉛 無鉛 無鉛 無鉛 無鉛...

  • Page 52: Lcd (M740Tg/M748Tg-C

    Part Lists LCD (M740TG/M748TG-C) Figure A - 4 LCD (M740TG/ M748TG-C) 無鉛 無鉛 (世華)無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鋁箔 無鉛 精乘 無鉛 無鉛 無鉛 地線上移 無鉛 無鉛 無鉛 精乘 無鉛 無鉛 中性 電鑄薄膜鍍亮鉻 無鉛 無鉛 無鉛 無鉛...

  • Page 53: Dvd-Dual Drive (M740Tg/M748Tg-C

    Part Lists DVD-Dual Drive (M740TG/M748TG-C) Figure A - 5 DVD-Dual Drive (M740TG/ M748TG-C) *(非耐落) 無鉛 (志精) 無鉛 內縮 無鉛 （設變)無鉛 DVD-Dual Drive (M740TG/M748TG-C) A - 7...

  • Page 54: Top Without Fingerprint (M765Tg

    Part Lists Top without Fingerprint (M765TG) Figure A - 6 Top without Fingerprint (M765TG) 黑色 無鉛 無鉛 黑色 無鉛 無鉛 無鉛 (設變) (黑色 未遮噴 無鉛 無鉛 無鉛 無鉛(背膠變更) 無鉛 無鉛 無鉛 無鉛 非耐落 無鉛 無鉛 無鉛 A - 8 Top without Fingerprint (M765TG)

  • Page 55: Bottom (M765Tg

    Part Lists Bottom (M765TG) 無鉛 導電布 無鉛 無鉛 無鉛 無鉛 導電布 無鉛 無鉛 無鉛 導電布 無鉛 日東 無鉛 Figure A - 7 無鉛 無鉛 Bottom (M765TG) 無鉛 日東 無鉛 無鉛 變更 無鉛 無鉛 海華 無鉛 非耐落 無鉛 (富士弘)無鉛 無鉛 無鉛 無鉛...

  • Page 56: Lcd (M765Tg

    Part Lists LCD (M765TG) Figure A - 8 LCD (M765TG) 無鉛 無鉛 錦承 無鉛 (長騰)無鉛 無鉛 無鉛 無鉛 (非耐落) 無鉛 (志精)無鉛 頭徑 頭厚 號穴 鍍白鎳 頭 無鉛 無鉛 無鉛 無鉛 (志精)無鉛 無鉛 無鉛 精乘 無鉛 黑色 惠貿 無鉛 無鉛 (黑色) (無鉛) 無鉛...

  • Page 57: Dvd-Dual Drive (M765Tg

    Part Lists DVD-Dual Drive (M765TG) Figure A - 9 DVD-Dual Drive (M765TG) *(非耐落) 無鉛 (志精) 無鉛 無鉛 黑色 (設變)無鉛 (祥和)無鉛 DVD-Dual Drive (M765TG) A - 11...

  • Page 58: Top Without Fingerprint (W765Tg

    Part Lists Top without Fingerprint (W765TG) Figure A - 10 Top without Fingerprint (W765TG) 無鉛 無鉛 (黑色) 無鉛 無鉛 無鉛 無鉛 修模 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 藍天 互億 無鉛 (非耐落) 無鉛 無鉛 無鉛 (非耐落) 無鉛 無鉛 無鉛 A - 12 Top without Fingerprint (W765TG)

  • Page 59: Bottom (W765Tg

    Part Lists Bottom (W765TG) 無鉛 導電布 無鉛 無鉛 無鉛 無鉛 Figure A - 11 導電布 無鉛 無鉛 Bottom (W765TG) 無鉛 導電布 無鉛 日東 無鉛 無鉛 無鉛 無鉛 日東 無鉛 無鉛 變更 (鼎緯)無鉛 無鉛 海華 無鉛 非耐落 無鉛 (富士弘)無鉛 無鉛 無鉛 無鉛...

  • Page 60: Lcd (W765Tg

    Part Lists LCD (W765TG) Figure A - 12 LCD (W765TG) (富士弘)無鉛 (黑色亮面) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 頭徑 頭厚 號穴 鍍白鎳 頭 無鉛 無鉛 (非耐落) 無鉛 (新日興) 無鉛 無鉛 無鉛 無鉛 (華力)無鉛 (新日興) 無鉛 惠貿 無鉛 膠 惠貿 無鉛 (咬花) (變形量OK)無鉛...

  • Page 61: Dvd-Dual Drive (W765Tg

    Part Lists DVD-Dual Drive (W765TG) Figure A - 13 DVD-Dual Drive (W765TG) *(非耐落) 無鉛 (志精) 無鉛 無鉛 黑色 無鉛 (太乙)無鉛 DVD-Dual Drive (W765TG) A - 15...
  • Page 62 Part Lists A - 16...

  • Page 63: Schematic Diagrams

    Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the M740TG/M748TG-C/M765TG/W765TG notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Table B - 1 Schematic System Block Diagram - Page B - 2 VGA N10M-GE1-5 - Page B - 20...
  • Page 64 Schematic Diagrams System Block Diagram AC-IN,CHARGER CLEVO M7X0T(G)/M7X0TUN/W760T(G)/W760TUN 3VS, 5VS System Block Diagram MULTI I/O BOARD SPK_R, RJ-11, LED POWER GPU, NVVDD 14.318 MHz POWER KEY,CCD,LID Colck Generator Intel Penryn ICS9LPR363 Memory Termination VDD3,VDD5,3.3V,5V, AUDIO BOARD PROCESSOR 3.3VS,5VS,3.3VM, PHONE JACK, USB 478pins uFCBGA 1.05VS...
  • Page 65 Schematic Diagrams Clock Generator Layout no te: CLOCK GENERATOR Insatlled : Diffe rential clock 3. 3 V S C L K _ I C H 14 C 4 32 *1 0 P _ 5 0V _0 4 level is higher 3.

  • Page 66: Penryn (Socket-P) Cpu 1/2

    Schematic Diagrams Penryn (Socket-P) CPU 1/2 U 2 2 A H _A # [ 3 5 : 3 ] H _ A #3 A [ 3 ] # A D S # H _ A D S # H _ A #4 U 2 2 B A [ 4 ] # B N R #...

  • Page 67: Penryn (Socket-P) Cpu 2/2

    Schematic Diagrams Penryn (Socket-P) CPU 2/2 PLACE NEAR CPU V C O R E U 2 2 D C 2 0 7 C 2 0 9 C 6 8 1 C 64 3 C 21 0 C 6 82 C 6 09 C 6 20 C 2 0 8 C 8 7...

  • Page 68: Cantiga 1/7, Host

    Schematic Diagrams CANTIGA 1/7, Host U23A H _A#[3 5 :3] 3 H _A #3 H _D # [63: 0 ] H _A #_ 3 H_D #0 H _A #4 C1 5 H _D # _0 H _A #_ 4 H_D #1 H _A #5 H _D # _1 H _A #_ 5...

  • Page 69: Cantiga 2/7, Graphics

    Schematic Diagrams CANTIGA 2/7, Graphics ? ? ? ? D ISA BL E :L _C TR _C LK / LC TR_ DA TA 1 . 0 5 V M _P E G 3. 3V S L_ DDC _C LK / L_ DD C_ DA TA N O C ON NE CT L 1 1 Z 0 6 01 U 2 3 C...

  • Page 70: Cantiga 3/7

    Schematic Diagrams CANTIGA 3/7 U 2 3 B A P 24 S A _ C K _ 0 M _C L K _ D D R 0 1 2 1 . 8V D MI X 2 se le ct L ow = DM I x 2 A T 2 1 M _C L K _ D D R 1 1 2 S A _ C K _ 1...

  • Page 71: Cantiga 4/7

    Schematic Diagrams CANTIGA 4/7 U 2 3 E M _B _D Q[ 6 3 : 0 ] U 2 3 D M _ B _ D Q 0 A K 4 7 B C 1 6 M _ A _ D Q [ 6 3: 0 ] S B _ D Q _ 0 S B _B S _0 M _ B _ B S 0 # 1 3...

  • Page 72: Cantiga 5/7

    Schematic Diagrams CANTIGA 5/7 U 2 3 G 1 . 8 V V GF X _ C OR E U 2 3 F 1 . 0 5V S A P 33 W 2 8 V C C _ S M _1 V C C _A X G_ N C T F _ 1 A N 33 V 2 8...

  • Page 73: Cantiga 6/7

    Schematic Diagrams CANTIGA 6/7 ? ? ? ? DISABLE: VCC A_CRT_DAC /VCCA_DAC _BG /VCCA_DPLLA C 8 5 9 C 6 7 8 C 6 8 3 R 4 5 5 1 . 0 5 V S /VCCA_DPL LB ? ? 4 .

  • Page 74: Cantiga 7/7

    Schematic Diagrams CANTIGA 7/7 U 2 3I U 2 3J AU 48 A M36 B G2 1 AH 8 V SS _ 1 V SS _1 0 0 V SS _ 1 99 VS S_ 2 97 AR 48 A E3 6 L 1 2 V SS _ 2 V SS _1 0 1...

  • Page 75: Ddrii So-Dimm - 0

    Schematic Diagrams DDRII SO-DIMM - 0 SO-DIMM 0 +VTT_MEM RESISTORS V T T _M E M M _ C K E 0 C 3 9 7 . 1 U _ 1 0 V _ X7 R _ 04 M _ A _ B S 2 # R N 1 J _D I M M_ 1 A M _ C K E 1...

  • Page 76: Ddrii So-Dimm - 1

    Schematic Diagrams DDRII SO-DIMM - 1 SO-DIMM 1 +VTT_MEM RESIS TORS V TT _ ME M M_ B _ A 9 R N 9 C 47 7 *. 1 U _1 0 V _ X 7R _ 0 4 J _ D I MM _2 A M_ B _ B S 2 # 8 P 4 R X 5 6 _ 04 M_ B _ A [ 1 4 : 0]...

  • Page 77: Panel, Inverter, Crt

    Schematic Diagrams Panel, Inverter, CRT 1 . 8V 1. 8V FOR INTEGRAPHIC P ANEL L V D S LN 0 R N 4 7 L V D S - L0N 1 011 ? ? FO R EXT -VG A ONL Y L V D S LP 0 4 P 2R X 0 _04 _- U L V D S - L0P...

  • Page 78: Vga N10M-Ge1-1

    Schematic Diagrams VGA N10M-GE1-1 1. 1 VS 60 0m A G 1A P B G A 533- 0 8MM FOR HY BR ID 3 . 3 V C O M MO N 1/ 13 PC I _EX PR ES S PE X_I O VD D PE X_I O VD D C 17 5...

  • Page 79: Vga N10M-Ge1-2

    Schematic Diagrams VGA N10M-GE1-2 G 1 B P B G A 53 3 - 08M M C O MM O N FB A D [ 0 . . 6 3] 2/ 1 3 F R AM E _B UF FE R 1 7, 1 8 F B AD [ 0 .

  • Page 80: Vga N10M-Ge1-3

    Schematic Diagrams VGA N10M-GE1-3 F B A _C MD [ 0 . . 2 7] 16 , 1 8 F B A _ C MD [ 0 . . 27 ] F B V D D Q F B V D D Q B GA 1 B G A 2 F B A _ C M D 1 5...
  • Page 81 Schematic Diagrams VGA N10M-GE1-4 F B A _ C MD [ 0. . 27 ] F B V D D Q 1 6 , 1 7 F B A _ C M D [ 0 . . 2 7] F B V D D Q B GA 4 B G A 3 F B A _C MD 15...
  • Page 82 Schematic Diagrams VGA N10M-GE1-5 DAC A G 1C V GA _3. 3 VS P B G A 53 3- 08MM C O MMO N 150 mA 3 /1 3 DAC A A G2 DACA_ VDD DA CA _VRE F DACA_ VREF DA CA _RSE T AE 1 A D2...

  • Page 83: Vga N10M-Ge1-6

    Schematic Diagrams VGA N10M-GE1-6 G 1 F G 1J P B G A 533- 0 8MM P B G A 53 3 - 08M M C O MM O N C O MM O N 6/ 1 3 I F PA B 1 3/ 13 G N D _N C I FP A_ TX D 0 N V _ LV D S -L0 N 1 4...

  • Page 84: Vga N10M-Ge1-7

    Schematic Diagrams VGA N10M-GE1-7 G 1M V GA _3 . 3V S P B G A 533- 0 8M M C O M MO N V GA _3 . 3V S 9/ 13 I 2 C _G P I O _T HE R M _JTA G V GA_ 3.

  • Page 85: Ich9M 1/4, Sata

    Schematic Diagrams ICH9M 1/4, SATA R T C V C C 20m ils C 7 8 5 1 5 P _5 0 V _ 04 C 8 3 1 R 51 7 3 2 . 76 8 K H z 20m ils 1U _ 6.

  • Page 86: Ich9M 4/4

    Schematic Diagrams ICH9M 2/4, PCI, USB U 2 5 D N 2 9 V 2 7 P C I E _ R X N 1 _ W L A N P E R N 1 D M I 0 R X N D M I _ R X N 0 7 N 2 8 V 2 6...
  • Page 87 Schematic Diagrams ICH9M 3/4 3 . 3 V 3 . 3V S 2 , 1 2, 1 3 I C H _ S MB C LK 0 R 25 9 10 K _ 0 4 P C I E _W A K E # DDR 2, CLK GEN d GP U _P R S N T # R 2 49...
  • Page 88 Schematic Diagrams ICH9M 4/4 R T C V C C U 2 5 F U 2 5 E A 2 3 A 1 5 1 . 0 5V S A A 2 6 Layout note: V C C R TC V C C 1 _ 05 [ 1 ] V S S [ 1 ] V S S [ 1 0 7 ]...

  • Page 89: New Card, Mini Pcie

    Schematic Diagrams New Card, Mini PCIE NEW CARD 3 . 3 V S C 80 1 *. 1 U _ 1 6V _ 0 4 B U F _ P L T _R S T# 3 . 3V U 3 1 U 2 7 J _ N E W 1 C 8 43...

  • Page 90: G, Powergood

    Schematic Diagrams 3G, Powergood 2 0 mi l C697 220U_4V_D2 C179 .1U_16 V _0 4 J_3G1 24,2 6,31 PCIE _ W AKE # 3. 3V S WA KE# 3.3VAUX _0 COEX 1 1.5V_0 1. 5V S UIM_PWR COEX 2 UIM _ P WR UIM_DATA UIM_DA TA Z2701...

  • Page 91: Usb, Fan, Tp, Fp, Multi Con

    Schematic Diagrams USB, Fan, TP, FP, Multi CON FAN CONTROL USB PORT*2 5 V S 5 V S _ F A N 5 V S L 26 H C B 16 0 8 K F -1 21 T 2 5_ 0 6 C 3 8 6 C 3 9 0 U S B V C C 0 1...

  • Page 92: Card Reader

    Schematic Diagrams Card Reader 3.3V S 3.3VS S D_C D# M DIO 7 R 559 4.7K _04 R52 5 10K _04 M D IO12 R540 200K _04 R 558 10K _04 M S _INS # M D IO14 R561 200K _04 V CC _CA RD SD WP R5 24...

  • Page 93: Sata Odd, Led, Hotkey, Lid Sw

    Schematic Diagrams SATA ODD, LED, Hotkey, LID SW V I N HOT KEY SATA ODD M7 40 TU U SE R 61 0 J _ OD D 1 MAIL I NTER NET SI LENT 1 0 0K _ 0 4 S W 1 S W 2 S W 3...

  • Page 94: Pci-E Lan Rtl8111C

    Schematic Diagrams PCI-E LAN RTL8111C F OR 8103E USE o nly C344, R162 FOR RTL8103 E USE R6 25 FOR 8103 E USE onl y C377,C363,C3 82,C3 39,C 358 R EMOVE :C331,C2 58,C 315,C 302,C347, C320,C327, R163 LAN (RTL8111C) (Pins-1 5,21, 43,4 9,58) R 6 2 5 *0 _ 0 6 L A N V D D 1 8...

  • Page 95: Audio Codec Alc662

    Schematic Diagrams Audio Codec ALC662 CODEC ( ALC662-GR) REMOVE- R546 USE-R545 1. 5VS: FO R MO NTEV INA PLAT FOR M GMC H HD _AUD IO U SED P IN 25 ,PI N3 8 ? 1? 1 0u F/ .1u F D 1 4 * S C S 5 5 1V -30 _ A 3 .

  • Page 96: Audio Amp

    Schematic Diagrams Audio AMP AUDIO AMP 5 V S L 64 5 V S _ A M P _ C P H C B 1 0 05 K F - 12 1 T 2 0 5 V S _A M P 40m ils L 63 5 V S _ A M P...

  • Page 97: Kbc-Ite It8512E

    Schematic Diagrams KBC-ITE IT8512E K B C _ A V D D L 3 0 B K P 10 0 5H S 1 21 _ 0 4 R 5 68 * 10 K _ 04 W D T _E N V D D 3 V D D 3 C 4 8 2...

  • Page 98: 3.3V, 5Vs, 3.3Vs, 1.05Vs

    Schematic Diagrams 5V, 3.3V, 5VS, 3.3VS, 1.05VS P D 7 S C S 3 5 5 V V I N 1 V D D 3 V I N PMOS 150mA P D 6 S Y S 5 V S C S 3 5 5 V P C 73 Q 21 A O3 4 09...

  • Page 99: Power 3.3V/5V

    Schematic Diagrams Power 3.3V/5V V I N P C 2 0 2 S Y S 5 V LG A T E 1 P D 2 5 S C S 35 5 V Z 3 6 24 P C 2 1 5 P C 2 1 7 P C 2 18 .

  • Page 100: Power 1.5Vs/1.05Vs

    Schematic Diagrams Power 1.5VS/1.05VS V I N PR 148 EN _1.05VM P D17 100K_ 1%_ 04 P Q42 P C168 F M 0540-N S US B 2N 7002W P R14 5 5.1K _1% _04 .1U_ 10V_X 7 R_04 P Q40 A O44 74 1.05VS P C169...

  • Page 101: Power 1.8V/0.9V

    Schematic Diagrams Power 1.8V/0.9V V I N 3. 3V V D D Q P R 6 6 P R 6 8 P D 9 P R 71 1. 5 M _ 04 1 0 _ 0 6 1 0 0K _0 4 F M0 5 4 0-N P U 3 Z 3 80 1...

  • Page 102: Power Gpu/Nvvdd

    Schematic Diagrams Power GPU/NVVDD V I N P C 6 1 P C 13 9 P D 5 GP U *F M 0 54 0 - N _ -U P J 26 * 1 U _ 25 V _ 0 8 *1 U _ 2 5V _ 0 8_ -U 1 .

  • Page 103: Ac-In, Charger

    Schematic Diagrams AC-IN, Charger P Q 2 5 * A M4 8 35 P DC_JACK V I N Ch ar ge C ur re nt 2 .0 A P Q 2 A M 4 83 5 P Ch ar ge V ol ta ge 1 6. 8V J _D C -J A C K 1 P L 1 To ta l Po we r 60 W...

  • Page 104: Vcore

    Schematic Diagrams VCORE V I N V -R C 1 P C 4 4 P D 4 1U _ 25 V _ 0 8 F M 05 4 0 - N P R 4 8 V I N B S T 1 1 0 _ 06 P C 1 0 P C 7...

  • Page 105: Nvvdd

    Schematic Diagrams NVVDD FOR NV VGA V I N S Y S 5 V Sheet 42 of 51 N V _ 3 . 3 V S P R 9 P R 8 P R 7 P D 1 1 NVVDD * 1 00 K _0 4 _ + U * 10 0 K _ 0 4 _ + U *1 0 K _ 0 4 _ + U...

  • Page 106: External Odd Board For M76

    Schematic Diagrams External ODD Board for M76 ODD BOARD OJ _ OD D1 OJ _OD D 2 Z 440 1 Z 440 2 Z 440 3 Z 440 4 OGN D OGN D Sheet 43 of 51 Z 440 5 O_ 5 VS O_5 VS External ODD...

  • Page 107: Click & Finger Board For M76

    S N 74 LV C 1G1 23 D C T C GN D C GN D C GN D C GN D C GN D C GN D CLEVO CO. 藍天電腦 Click & Finger Board for M76 B - 45...

  • Page 108: Multi Function Board

    Schematic Diagrams Multi Function Board M_ 5 V M5 V _ C C D SPEAKER CONNECTOR MULTI I/O CONN M C 9 MC 10 1 U _6 . 3 V _ 04 1U _ 6. 3 V _ 0 4 M GN D M GN D M _5 V...

  • Page 109: Audio Board

    Schematic Diagrams Audio Board USB PORT A _U S B V C C A L 5 A _U S B V C C 2 H C B 1 6 0 8K F -12 1 T 25 60 mil A _ U S B V C C A C 1 A C 7 A _5 V...

  • Page 110: Finger Sensor Board For M76

    Schematic Diagrams Finger Sensor Board for M76 FESD _ RI NG EXT_R IN G2 FG RI D 0/ SENS E C RI DO RI NG FGN D FMUXO UT MU X O UT Sheet 47 of 51 FAV DD AVDD FMCS MC S Finger Sensor...

  • Page 111: Power Switch Board For M74

    Schematic Diagrams Power Switch Board for M74 POWER SW & POWER LED FOR M74 POWER S M_3. 3V S SWITCH 20mil POWER BUTTON S MS W 1 S MR 1 T J G-533-S -T /R 22 0_04 SM _B TN # Sheet 48 of 51 S M_3.
  • Page 112 Schematic Diagrams FingerPrint Board for M74 F I N G E R B O A R D F O R M 7 4 T CS 4B U ns tu ff F C C T 3 . 3 V _ F F C C T3 .
  • Page 113 Schematic Diagrams Power Switch Board for M76 POWER SW & POWER LED FOR M76 POWER SH _3. 3V S SWITCH POWER BUTTON 2 0mil S H S W 1 S H R 1 T J G-533-S -T /R 220_0 4 Sheet 50 of 51 SH _B TN # 20mil...
  • Page 114 Schematic Diagrams External ODD Board for W76 ODD BOARD FOR W76 WJ _ ODD 1 W J_ODD 2 Z 52 0 1 Z 52 0 2 Z 52 0 3 Z 52 0 4 Sheet 51 of 51 W GN D W GND Z 52 0 5 External ODD...
