Shark Powered Lift-Away NV800ANZ Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

NV800ANZ
Series
INSTRUCTIONS
AUST: 1800 890 840
NZ: 0800 002 999

Advertisement

Table of Contents
loading

Related Manuals for Shark Powered Lift-Away NV800ANZ

Summary of Contents for Shark Powered Lift-Away NV800ANZ

  • Page 1 NV800ANZ Series INSTRUCTIONS AUST: 1800 890 840 NZ: 0800 002 999...
  • Page 2 Power Nozzle: 80W PLEASE READ CAREFULLY AND KEEP FOR FUTURE REFERENCE. This Owner’s Guide is designed to help you get a complete understanding of your new Shark Powered Lift-Away DuoClean. If you have any questions, please call the customer service GMA-501823-EA line at AUST: 1800 890 840 or NZ: 0800 002 999.

  • Page 3: Table Of Contents

    CONTENTS Important Safety Instructions ......3 Getting to Know Your Shark Powered ® Lift-Away DuoClean .

  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS FOR HOUSEHOLD USE ONLY WARNING This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

  • Page 5: Save These Instructions

    35 DO NOT immerse vacuum cleaner in water blockages and keep openings away from or other liquids. face and body. 36 Use extra care when cleaning on stairs. 27 Only use Shark -brand filters and ® accessories (failure to do so will void the warranty).

  • Page 6: Getting To Know Your Shark

    GETTING TO KNOW YOUR SHARK ® POWERED LIFT-AWAY DUOCLEAN ™ ™ WELCOME! Congratulations on your purchase. Use this instruction manual to learn about your new vacuum’s great features. From assembly to use to maintenance, you will find it all in here.
  • Page 7 Wand Release N Z : 0 8 0 0 0 0 2 9 9 9...

  • Page 8: Assembling Your Vacuum

    ASSEMBLING YOUR VACUUM TIP: Push hose clip STEP 1 STEP 2 into back of wand for convenience. TIP: For quick cord access, rotate upper hook down and remove cord. TIP: Use cord clip located on the side of wand to hold cord in place while vacuuming.
  • Page 9 STEP 3 STEP 4 STEP 5 3 Place pod onto wand and 4 Connect hose into back of 5 Place included accessories slide down to connect. pod until you hear a click. their accessory posts. N Z : 0 8 0 0 0 0 2 9 9 9...

  • Page 10: Using Your Vacuum In Upright Mode

    USING YOUR VACUUM IN UPRIGHT MODE WARNING: DO STEP 1 NOT use to vacuum up drywall dust, fireplace ash, or embers. DO NOT use as an attachment to power tools for dust collection. WHAT DOES THE BRUSHROLL INDICATOR LIGHT MEAN? Solid Green The brushrolls are on and working as they should.
  • Page 11 STEP 2 STEP 3 Suction Control 2 The Powered Lift-Away DuoClean 3 Press power button to turn vacuum on to has a ™ 2-speed Slider Switch on the handle. Move start cleaning. Please note the brushrolls the Slider Switch to appropriate speed will not spin unless the wand is reclined.

  • Page 12: Using Your Vacuum In Above-Floor Mode

    USING YOUR VACUUM IN ABOVE-FLOOR MODE THE BENEFITS OF STEP 1 SUCTION CONTROL Suction Control is a way for you to adjust suction power when you are using different tools or vacuuming different surfaces. For example, if you are feeling resistance while vacuuming thick carpet or upholstery, slide Suction Control toward MIN to help...

  • Page 13: Suction Control

    STEP 2 STEP 3 Suction Control 2 Insert desired tool directly onto wand 3 The Suction Control slide, located at the or handle. base of the top handle, offers variable suction based on your needs. Slide toward MIN to minimize suction, and slide toward MAX to maximize suction.

  • Page 14: Using Your Vacuum In Powered Lift-Away ™ Mode

    USING YOUR VACUUM IN POWERED LIFT-AWAY MODE ™ WARNING: Ensure solid footing when using in Lift-Away mode. Using when you don’t have stable footing may result in personal injury. WHAT IS POWERED LIFT-AWAY? Our Powered Lift-Away feature allows you to remove the pod from the nozzle while maintaining the same power you have in upright mode.

  • Page 15: Lift-Away Cleaning

    LIFT-AWAY CLEANING ™ 2 For a convenient way to clean stairs, insert Attach desired accessory directly into handle. You can also attach the accessory handle into motorized floor nozzle. to the wand for extended reach. N Z : 0 8 0 0 0 0 2 9 9 9...

  • Page 16: Compatible Accessories

    COMPATIBLE ACCESSORIES There are a variety of Pet Power Brush accessories that are compatible Designed to remove pet hair and ground-in dirt from with this vacuum series. carpeted stairs and upholstery. Articulating Upholstery Tool The top flap of your box shows Remove pet hair and dust from curtains and other delicate the select accessories that are fabrics and upholstery.
  • Page 17 N Z : 0 8 0 0 0 0 2 9 9 9...

  • Page 18: Maintenance

    MAINTENANCE To keep your vacuum’s suction power optimal, follow STEP 1 STEP 2 these instructions. Make sure unit is off and cord is unplugged. WARNING: To reduce the risk of shock and unintended operation, turn power off and unplug unit before servicing.

  • Page 19: Cleaning The Filters

    STEP 3 FOAM FILTER FILTER FRAME FELT FILTER HEPA CLEANING THE FILTERS Pre-Motor 3 Press top dust-cup empty Post-Motor (HEPA): (foam and felt): latch to access dust To access the HEPA filter, With the dust cup screen and remove built- reach under the grill, removed, take out the up debris as required.

  • Page 20: Cleaning The Brushroll

    MAINTENANCE WARNING: To reduce the risk of shock and unintended operation, turn power off and unplug unit before servicing. TIP: You can also check for blockages in the hose and tubes. Just remove floor nozzle, dust cup and hose and shine a flashlight in the openings.

  • Page 21: Cleaning The Soft Roller

    SOFT ROLLER 4 Reinsert the Soft Roller by sliding it into the Slide the Soft Roller access button up to front of the nozzle until it clicks into place. remove the Soft Roller. CHECKING THE NOZZLE FOR BLOCKAGES 2 Use the onboard hair removal tool to remove any string, carpet fibers or hair that Tilt neck of nozzle back to straighten the may be wrapped around the Soft Roller.

  • Page 22: Troubleshooting Guide

    TROUBLESHOOTING GUIDE WARNING: To reduce the risk of shock and unintended operation, turn power off and unplug unit before servicing. Vacuum is not picking up debris. No suction or light suction. (Refer to Maintenance section for more information.) • Check filters to see if they need cleaning. Follow instructions for rinsing and drying the filters before re-inserting in the vacuum.

  • Page 23: Warranty

    FIVE (5) YEAR LIMITED REPLACEMENT WARRANTY If your product becomes defective due to faulty material or workmanship within a period of 5 years from the date of purchase, we warrant to do the following: • For New Zealand Consumers: We will replace the product with a new product, free of charge, or repair the product at our cost, at our discretion.
  • Page 24 Illustrations may differ from actual product. We are constantly striving to improve our products, therefore the specifications contained herein are subject to change without notice. Shark is a registered trademarks of SharkNinja Operating LLC. DuoClean and Lift-Away are trademarks of SharkNinja Operating LLC. © 2016 SharkNinja Operating LLC NV800ANZ�IB�170410...
