Service
Manual
SECTION
1. TECHNICAL SPECIFICATIONS .............................................................................. 1
2. SERVICE MODE ...................................................................................................... 2
3. BLOCK DIAGRAM .................................................................................................... 3
4. SCHEMATIC DIAGRAM ........................................................................................... 5
5. PARTS LOCATION ................................................................................................ 13
6. IC DATA .................................................................................................................. 18
7. EXPLODED VIEW AND PARTS LIST .................................................................... 25
8. ELECTRICAL PARTS LIST .................................................................................... 28
Please use this service manual with referring to the user guide ( D.F.U. ) without fail.
Printed on 100% Recycled Paper
Printed in Japan
TABLE OF CONTENTS
ED-5.1
ED-5.1F
Stereo CD System
PAGE
05AW855010 MIT
First Issue 2001.10
PW
R
Advertisement
Related Manuals for Marantz ED-5.1F PW
Summary of Contents for Marantz ED-5.1F PW
-
Page 1: Table Of Contents
Service ED-5.1F Manual Stereo CD System TABLE OF CONTENTS SECTION PAGE 1. TECHNICAL SPECIFICATIONS ................1 2. SERVICE MODE ...................... 2 3. BLOCK DIAGRAM ....................3 4. SCHEMATIC DIAGRAM ................... 5 5. PARTS LOCATION ....................13 6. IC DATA ........................18 7. - Page 2 MARANTZ Parts for your equipment are generally available to our National Marantz Subsidiary or Agent. ORDERING PARTS : Parts can be ordered either by mail or by Fax.. In both cases, the correct part number has to be specified.
-
Page 3: Technical Specifications
1. TECHNICAL SPECIFICATIONS CD Player Section D/A conversion ............................1 bit DAC Wow & flutter ..........................Precision of quartz Horn Section Speaker ............................ 5.0 cm (8 ohms) x 2 Dynamic type Output jack ..........................3.5 mm 4P mini-jack Dimensions (W x H x D) ....................172 x 290 x 170 mm x 2 Weight .............................. -
Page 4: Service Mode
2. SERVICE MODE Player Service Mode Stop No Disc NEXT PREV STOP PLAY Service Mode b-0000 0000 Buil d Software Buil d LCD Test PLAY CD Test CD Test Laser Test Spind le Test Pickup Test Service Mode STOP Reset CD Test PLAY LCD Test... -
Page 5: Block Diagram
3. BLOCK DIAGRAM... -
Page 6: Schematic Diagram
4. SCHEMATIC DIAGRAM... - Page 9 L CH AMP R CH AMP Q701 Q703 JJ30 TDA7056A TDA7056A J701 MUTE SENC RMCH LMCH CD UNIT 12.4V 12.4V L CH JJ11 J704 Q704 (8 OHM) DTC114TS N001 JJ12 R CH +5.6V R701 SP UNI T R702 JJ11 GND GND U029 (8 OHM) L CH...
- Page 10 5. PARTS LOCATION (Component Side) QU04 PS01...
-
Page 11: Parts Location
PARTS LOCATION (Solder Side) Q407 Q410 Q203 Q406 Q409 Q204 Q405 QU03 Q408 QU01 QU03 QU02 Q404 Q252 Q401 Q251 Q402 Q202 Q403 Q201 Q411 QU06 PS01... -
Page 12: Ic Data
6. IC DATA Q251/252:TDA7073A Block Diagram P701 QU01 Q803 Q721 Q704 Q802 Q806 Q801 Q703 Q701 Q702 Pinning Pin Configuration PV01... - Page 13 Q301/303:TDA7506 Block Diagram Pinning...
- Page 14 Q201:SAA7372 Block Diagram...
- Page 16 Q402/403/404:TDA1308 Block Diagram Pinning Pin Configuration...
- Page 17 QU01:TMP87CM21 Pin Assignment Name Function Purpose 25 P30 5Bits I/O Port 26 P31 5Bits I/O Port PLAY 27 P32 5Bits I/O Port STOP 28 P33 5Bits I/O Port NEXT 29 P34 5Bits I/O Port PREV 30 P50/AIN0 8Bits Programmable I/O Port CD Module SILD 31 P51/AIN1 8Bits Programmable I/O Port...
-
Page 18: Exploded View And Parts List
8. EXPLODED VIEW AND PARTS LIST 0 1 1 B T O P C A S E A A S S Y . 0 0 2 B 0 0 0 B 0 0 5 B 0 0 1 B 0 1 1 G ( 0 1 3 B ) x 2 ( 0 0 6 B ) ( 0 1 5 B ) - Page 19 QK00502090 SPEAKER, 5CM 8Ω 5W W001 A.C MAINS CORD YC01900270 NOT STANDARD SPARE PARTS 001S PACKING CASE, 352K801110 ED-5 (1 COLOR) 002S CUSHION, L&R 352K809010 NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
-
Page 20: Electrical Parts List
8. ELECTRICAL PARTS LIST NOTE ON SAFETY FOR FUSIBLE RESISTOR : ASSIGNMENT OF COMMON PARTS CODES. RESISTORS The suppliers and their type numbers of fusible resistors : 1) GD05 × × × 140, Carbon film fixed resistor, ±5% 1/4W are as follows; : 2) GD05 ×... - Page 21 4822 126 11759 CER.CHIP, 100pF ±5% 50V DD95101300 R209 4822 051 30105 CHIP RES., 1MΩ ±5% 1/16W NN05105610 C217 4822 126 11687 CER.CHIP, 0.1µF DK98104200 NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
- Page 22 4822 051 30223 CHIP RES., 22kΩ ±5% 1/16W NN05223610 LU02 4822 157 10313 HF50ACC453215 FN31020010 R460 4822 051 30223 CHIP RES., 22kΩ ±5% 1/16W NN05223610 NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
- Page 23 9965 000 01893 CER.VIB., CSTCC8.46M FQ08464020 GOH6TC 8.46MHz ±5% XU01 4822 242 80349 CER.VIB., 8.0MHz FQ08004030 TYPE(EF0 V) TAPING PV01-VOLUME CIRCUIT BOARD PV01-RESISTORS RV01 RK01040750 VAR., 100kΩ NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
