Variable Speed This new random orbit sander has been engineered and manufactured to our high standard for dependability, ease of operation and operator safety. When properly cared for, the random orbit sander will give you years of rugged, trouble-free performance.
INTRODUCTION Your random orbit sander has many features for making the use of this product more pleasant and enjoyable. Safety, performance, and dependability have been given top priority in the design of this product making it easy to maintain and operate.
GENERAL SAFETY RULES WARNING: Read and understand all instructions. Failure to follow all instructions listed below, may result in elec- tric shock, fire and/or serious personal injury. SAVE THESE INSTRUCTIONS Work Area ■ Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents.
GENERAL SAFETY RULES Service ■ Tool service must be performed only by qualified repair personnel. Service or maintenance performed by unqualified personnel could result in a risk of injury. SPECIFIC SAFETY RULES Hold tool by insulated gripping surfaces when performing an operation where the cutting tool may contact hidden wiring or its cord.
SYMBOLS Important: Some of the following symbols may be used on your tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the ool better and safer. SYMBOL NAME Volts Amperes Hertz Watt Minutes Alternating Current...
Always use original factory replacement parts when servicing. Electrical Connection The random orbit sander has a precision-built electric motor. It should be connected to a power supply that is 120 volts, 60 Hz, AC only (normal household current). Do not operate this tool on direct current (DC).
PSA (Pressure Sensitive Adhesive) Pad 80-Grit Sandpaper (2 sheets) Operator’s Manual APPLICATIONS You may use the random orbit sander for the purposes listed below: ■ Sanding wood or wood product surfaces ■ Sanding steel surfaces ■ Removing rust from steel surfaces...
Dust Bag The dust bag attaches to the sander and keeps dust to a minimum. Vacuum Adaptor The built-in vacuum adaptor allows you to connect to a 1-1/4 in.
ASSEMBLY WARNING: The sander should never be connected to a power supply when you are assembling parts, making ad- justments, cleaning, performing maintenance, or when the tool is not in use. Disconnecting the tool will prevent accidental starting that could cause se- rious injury.
Page 11
5. Apply a thin layer of lightweight grease to the back of the pad. 6. Align the holes in the pressure sensitive adhesive (PSA) pad with the four screw holes in the sander. 7. Replace the four screws securely. 8. Carefully peel paper backing from the pressure sensi- tive adhesive type sanding disc.
Page 12
See Figure 4. The dust bag provides a dust collection system for the sander. Sanding dust is drawn up through the holes of the sanding disc and collected in the dust bag during sanding. Follow these steps to attach the dust bag.
Turning the Sander On/Off See Figure 6. Follow these steps to turn the sander ON/OFF. ■ Turn on the sander: Push the ON/OFF switch to the left. ■ Turn off the sander: Push the ON/OFF switch to the right. Operating the Sander See Figure 7.
Page 14
Remove your hand from vent area, remove sanding disc, then with your hand removed from vent area, turn sander on and run it free without a load to cool motor. Emptying the Dust Bag See Figure 8.
ADJUSTMENTS Variable Speed Switch See Figure 10. The variable speed feature allows your sander to operate at speeds that can be adjusted by rotating the dial on the variable speed switch from A to F. The dial is conveniently located on the motor housing, allowing operator control of disc speed.
MAINTENANCE WARNING: When servicing use only identical RIDGID® replace- ment parts. Use of any other parts may create a hazard or cause product damage. WARNING: The random orbit sander should never be connected to a power supply when you are assembling parts, making adjustments, cleaning, performing mainte- nance, or when the tool is not in use.
THREE YEAR WARRANTY This warranty covers all defects in workmanship or materials in this RIDGID tool for the three year period from the date of purchase. This warranty is specific to this tool. Warranties for other RIDGID products may vary.
Customer Service Information: For parts or service, contact your nearest RIDGID authorized service center. Be sure to provide all relevant information when you call or visit. For the location of the authorized service center nearest you, please call 1-866-539-1710 or visit us online at www.ridgidwoodworking.com.
