Summary of Contents for August Smart Lock Pro
- Page 1 August Smart Lock Pro Installation Guide...
-
Page 2: Inside The Box
Inside the Box August Smart Lock Pro Mounting Plate 3 Adapters Adhesive Strip What you need Phillips Screwdriver Before starting, we recommend confirming your deadbolt at august.com/compatibility... - Page 3 1. Prepare your existing deadbolt Use the supplied adhesive strip to hold the keyed side of the lock in place. 2. Remove your existing thumbturn Unscrew and remove the screws from your existing deadbolt thumbturn. If there is an additional back plate, remove that as well. Be sure to unlock your deadbolt before removing the thumbturn entirely.
-
Page 4: Attach The Mounting Plate
3. Prepare the mounting plate The included mounting plate has two adjustable screw-holes that can be repositioned as needed. Remove the screws from the thumbturn and insert them into the front of the mounting plate. 4. Attach the mounting plate Tighten the screws by hand until the mounting plate is secured against the door. - Page 5 5. Choose your adapter Select your adapter from the Compatibility Chart above. If your lock brand is not in the chart, slide each adapter onto the tailpiece to find the right one. The correct adapter will have the small nub pointing up. NOTE: The adapters can be placed in the mounting plate backwards.
- Page 6 Slide the August Smart Lock Pro over the tailpiece and attach it to the mounting plate. Make sure the back of the lock is flush with the door. To secure the August Smart Lock Pro, clamp down both side wing latches to the mounting plate...
- Page 7 9. Remove the faceplate Press down on the August logo located at the bottom of the face plate. Grab the top of the faceplate and remove it. 10. Remove the battery tab While holding the batteries in place, remove the plastic battery isolation tab. Make...
- Page 8 11. Replace the faceplate Place the faceplate back onto the August Smart Lock Pro, with the August logo at the bottom. 12. Install DoorSense™ DoorSense™ enables your lock to know when the door is open and closed. For instructions on installing DoorSense™, please visit the link below:...
- Page 9 13. Use the August Home app to complete setup Download and install the August Home app. Select "Get Started" from the home screen, or, if already logged in to the app, select "Set Up a Lock" from the main menu.
