- Page 1 August Smart Lock Installation Guide...
- Page 2 August Installation Guide...
- Page 3 Welcome! This guide will get you up and running with your August Smart Lock. Installation generally takes less than 15 minutes. If you have any trouble, please check our support section (august.com/support), contact our installer network (august.com/installers) or call 844-AUGUST1 (284-8781) for help.
- Page 4 Preparation Make sure your existing deadbolt is compatible with the August Smart Lock. Only standard deadbolts are supported. Use our compatability assistant to double-check. august.com/compatibility TOOLS NEEDED You will need a standard phillips screwdriver. Alternately, we have an installer network available in major cities, who can help with installation.
- Page 5 Compatibility Standard Deadbolt is mounted and operates independently of the door handle Integrated Mortise Lock & Handle An integrated Cylinder Handle and lock door handle Mounted on thumb-latch are and deadbolt the inside, on both mounted in a single top of the together on a metal unit door and...
-
Page 6: Package Contents
Package Contents 1 Adhesive Strip (Inside Envelope) 1 August Smart Lock (4 AA Batteries pre-installed) August Installation Guide... - Page 7 3 Adapters 3 Mounting Plates...
-
Page 8: Installation Overview
Installation Overview Before Installation Key Hole Deadbolt Tail Piece Thumb-latch Screws August Installation Guide... -
Page 9: After Installation
After Installation Key Hole Deadbolt Tail Piece Mounting Plate Screws Tail Piece Adapter August Smart Lock & Faceplate... - Page 10 Prepare existing deadbolt. Affix the supplied adhesive strip over the key hole, securing it to the exterior side of your door. This should hold the keyhole in place when you remove the thumb-latch on the inside of the door. August Installation Guide...
- Page 12 Remove the screws entirely from the deadbolt and keep them to assist in the next step. Your thumb-latch may include an additional back plate underneath it. If so, remove the back plate. Use the back plate and the longer screws for the next step. August Installation Guide...
- Page 14 If you know the brand of your deadbolt, please select the correct mounting plate and adapter from the Compatibility Chart and go to Step 4 (page 18). If not, go to Step 3a (page 16) to find the correct mounting plate and adapter. August Installation Guide...
- Page 15 844-AUGUST1 (284-8781) and we will walk you through installation. Compatible only with non-mortise, standard Omnia deadbolts. Commercial grade Schlage B560 deadbolts require supplemental screws. If your Schlage screws are too short please contact us at support@august.com...
- Page 16 Slide the mounting plates onto the screws one at a time until you find a mounting plate that allows the screws to fit straight through the holes. August Installation Guide...
- Page 17 NOT COMPATIBLE COMPATIBLE Having trouble selecting the right mounting plate? Try august.com/installation or call August customer support at 844-AUGUST1 (284-8781)
- Page 18 Step 4: Position the mounting plate. Remove the screws from the thumb-latch and use them to install the mounting plate over the existing deadbolt tail piece. Do not fully tighten the screws. August Installation Guide...
- Page 20 Place the correct adapter onto the tail piece with the small nub pointing up, and tighten the two screws. (Do not over-tighten.) Having trouble selecting the right adapter? Call August customer support at 844-AUGUST1 (284-8781) August Installation Guide...
- Page 21 Front View Deadbolt Tail Piece Adapter Alignment...
- Page 22 Step 6: Attach the August Smart Lock. Position the August Smart Lock with the curved notch at the top. Pull out both side wing latches. Slide August Smart Lock over adapter and tail piece and attach to mounting plate. Make sure the back of the lock is flush with the door.
- Page 24 Remove the two plastic tabs from the battery contacts. Make sure batteries are properly seated in the battery compartment. Align faceplate hooks with the August Smart Lock. The faceplate will lock into place with the logo at the bottom. August Installation Guide...
- Page 26 Step 8: Install August App Download the app from august.com/app The App will then bring you through the necessary profiling and calibration processes. August Installation Guide...
- Page 28 Questions? If you have any questions or difficulty, visit august.com/support, call 844-AUGUST1 284-8781 or email questions to support@august.com 1006-0000-A Rev5 ©2014 August Home Inc. August Installation Guide...
- Page 29 Terms and Conditons...
-
Page 30: Limited Warranty Statement
August authorized distribution facility identified by the CSR. Failure to return any of the accessories may result in a delay and/or result in a credit to August or an invoice for the missing accessories. - Page 31 FCC: 2AB6UASL01 IC: 12163A-ASL01 REGULATORY COMPLIANCE INFORMATION The August Smart Lock (ASL-01) is subject to the Federal Communications Commission (FCC) and Industry Canada (IC) rules. NOTICE: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
- Page 32 August Home Inc. Model: ASL-01 FCC: 2AB6UASL01 IC: 12163A-ASL01 Specifications Model Name: August ASL-01 Description: BLE Automatic Smart Lock Model Number: ASL-01 Standards: Bluetooth Specification v4.0 (BLE), 2.4GHz ISM band (2402MHz to 2480MHz), Channels: 40 x 2.0MHz channels Data rate & Modulation: 1Mbps, GFSK, 250 kHz deviation.
