Matrix 450™ + LT-03X
QUICK REFERENCE GUIDE
This manual illustrates a Stand Alone application. For other types of
installations, such as ID-NET™, and for a complete reader configuration using
the VisiSet™ configuration program, refer to the Matrix 450™ Reference
Manual available on the mini-DVD and also downloadable from the Web at
NOTE
www.automation.datalogic.com.
821000250
Advertisement
Table of Contents
Related Manuals for Datalogic Matrix 450
Summary of Contents for Datalogic Matrix 450
- Page 1 This manual illustrates a Stand Alone application. For other types of installations, such as ID-NET™, and for a complete reader configuration using the VisiSet™ configuration program, refer to the Matrix 450™ Reference Manual available on the mini-DVD and also downloadable from the Web at NOTE www.automation.datalogic.com.
-
Page 2: Services And Support
- Material Return Authorization LEGAL NOTICES © 2012 Datalogic Automation S.r.l. ALL RIGHTS RESERVED. Protected to the fullest extent under U.S. and international laws. Copying, or altering of this document is prohibited without express written consent from Datalogic Automation S.r.l. -
Page 3: Step 1 - Assemble The Reader
MATRIX 450™ QUICK REFERENCE GUIDE STEP 1 – ASSEMBLE THE READER The first step to perform is to assemble the accessories that make up the Matrix 450™ reader. The lens and lighting system or external illuminator must be used. This procedure shows an LT-03x lighting system. -
Page 4: Required Accessories
Figure 2 – Assembling Matrix 450™ to LT-03x The mating bracket can be mounted in the reverse direction to create a compact version of the Matrix 450™ + LT-03x assembly. The compact assembly however will reduce access to the lens for the focusing procedure. -
Page 5: Step 2 - Connect The System
In the typical standalone layout shown in the figure below a serial host is connected to the Matrix 450™ + LT-03x. The reader operates in One Shot or Phase Mode and can use an external trigger to signal image acquisition. - Page 6 Matrix 450™ configuration) Matrix 450™ Standalone Layout to Ethernet Host Matrix 450™ + LT-03x can also be used in an ID-NET™ Master/Slave configuration. See the Matrix 450™ Reference Manual for details, including power supply recommendations. If using separate power sources for LT-03x and Matrix 450™, make sure that LT-03x is powered up before Matrix 450™...
- Page 7 MATRIX 450™ QUICK REFERENCE GUIDE CBX100/CBX500 Pinout for Matrix 450™ The table below gives the pinout of the CBX100/CBX500 terminal block connectors. Use this pinout when the Matrix 450™ reader is connected by means of the CBX100/CBX500: CBX100/500 Terminal Block Connectors Input Power...
-
Page 8: Step 3 - Mount And Position The Reader
MATRIX 450™ QUICK REFERENCE GUIDE STEP 3 – MOUNT AND POSITION THE READER To mount the Matrix 450™ + LT-03x assembly, use the L-shaped mounting bracket to obtain the most suitable position for the reader. The most common mounting configurations are shown in the figure below. Other mounting solutions are provided in the Matrix 450™... -
Page 9: Step 4 - Focus The Reader
MATRIX 450™ QUICK REFERENCE GUIDE STEP 4 – FOCUS THE READER Matrix 450™ provides a built-in tool called Blue Diamonds™ to aid focusing the reader. The Blue Diamonds™ are accessed through the X-PRESS™ Interface. Remove the lens cover in order to focus the reader. -
Page 10: Step 5 - Calibrate Image Density
Replace the lens cover, screwing it tightly to the base. STEP 5 – CALIBRATE IMAGE DENSITY In order to function correctly to the fullest extent of its capabilities, Matrix 450™ must acquire information regarding image density or PPI (pixels per inch). This calibration takes place through the X-PRESS™... - Page 11 If the calibration cannot be reached after a timeout of about 5 (five) seconds Matrix 450™ will exit without saving the parameters to memory, the Setup LED will not remain on continuously but it will just stop blinking. In this case Matrix 450™ emits a long low pitched beep.
-
Page 12: Step 6 - X-Press™ Configuration
If the calibration cannot be reached after a timeout of about 5 (five) seconds Matrix 450™ will exit without saving the parameters to memory, the Setup LED will not remain on continuously but it will just stop blinking. In this case Matrix 450™ emits a long low pitched beep. - Page 13 If the autolearning cannot be reached after a timeout of about 3 (three) minutes Matrix 450™ will exit without saving the parameters to memory, the Learn LED will not remain on continuously but it will just stop blinking. In this case Matrix 450™ emits a long low pitched beep.
-
Page 14: Step 7 - Installing Visiset™ Configuration Program
MATRIX 450™ QUICK REFERENCE GUIDE STEP 7 – INSTALLING VISISET™ CONFIGURATION PROGRAM ™ VisiSet is a Datalogic reader configuration tool providing several important advantages: Setup Wizard for rapid configuration and new users; Defined configuration directly stored in the reader;... -
Page 15: Step 8 - Configuration Using Setup Wizard
MATRIX 450™ QUICK REFERENCE GUIDE STEP 8 – CONFIGURATION USING SETUP WIZARD The Setup Wizard option is advised for rapid configuration or for new users. It allows reader configuration in a few easy steps. Select the Setup Wizard button from the Main menu. - Page 16 MATRIX 450™ QUICK REFERENCE GUIDE Press the "Positioning" button. The reader continuously acquires images and gives visual feedback in the view image window. Move the Focusing Pattern to center it on the X-axis reference line at the center of the FOV and on the four delimiters (red points) in the acquired images which indicate the region in which the calibration algorithm is active.
- Page 17 MATRIX 450™ QUICK REFERENCE GUIDE Press the "Fine Focusing" button to activate the Fine Focusing Tool. The reader continuously acquires images and gives visual feedback on the focusing quality in the Focusing Tool window. In the Focusing Tool window, use the Zoom feature to make Fine Tuning easier.
- Page 18 Select a Code Setting Mode choice and press the "Code Setting" button. This step performs image density calibration in order for Matrix 450™ to function correctly and to the fullest extent of its capabilities. The Setup Result section of the Setup Wizard...
- Page 19 MATRIX 450™ QUICK REFERENCE GUIDE Substitute the Focusing and PPI Setup Chart with the application specific code, placing it in front of the reader at the same reading distance, then repeat step 6a and 6b. Setup Result Select a Saving Options choice and press the "Save"...
-
Page 20: Step 9 - Test Mode
MATRIX 450™ QUICK REFERENCE GUIDE STEP 9 – TEST MODE Use a code suitable to your application to test the reading performance of the system. Enter the Test function by pressing and holding the X-PRESS™ push button until the Test LED is on. -
Page 21: Advanced Reader Configuration
ADVANCED READER CONFIGURATION For further details on advanced product configuration, refer to the complete Reference Manual and the Matrix 450™ Help On Line on the installation Mini-DVD. The following are alternative or advanced reader configuration methods: Advanced Configuration Using VisiSet™... - Page 22 MATRIX 450™ QUICK REFERENCE GUIDE APPENDIX X-PRESS™ is the intuitive Human Machine Interface designed to improve ease of installation and maintenance. Status information is clearly presented by means of the five colored LEDs, whereas the single push button gives immediate access to the following relevant functions: Learn to self-detect and auto-configure for ...
- Page 23 Data Matrix ECC 200 (2D code) from the Test Charts provided with the reader. Testing should be performed with the actual Matrix 450™ + LT-03x assembly using application codes in order to evaluate whether maximizing application performance requires adjustments to the HW/SW configuration with respect to the Reference Conditions given under each diagram.
- Page 24 MATRIX 450™ QUICK REFERENCE GUIDE Matrix 450™ + LNS-1216 Code 1D 0.38 mm (15 mils) Code 1D 0.50 mm (20 mils) (cm) 140 150 (in) Reading Distance CONDITIONS: Hardware Settings Code Symbology Code 128 Code Resolution 0.38 mm (15 mils) 0.50 mm (20 mils)
- Page 25 MATRIX 450™ QUICK REFERENCE GUIDE Matrix 450™ + LNS-1225 Code 1D 0.33 mm (13 mils) Code 1D 0.38 mm (15 mils) (cm) 175 180 210 215 (in) Reading Distance CONDITIONS: Hardware Settings Code Symbology Code 128 Code Resolution 0.33 mm (13 mils) 0.38 mm (15 mils)
- Page 26 MATRIX 450™ QUICK REFERENCE GUIDE Matrix 450™ + LNS-1225 Code 1D 0.30 mm (12 mils) Code 2D 0.61 mm (24 mils) (cm) 160 165 (in) Reading Distance CONDITIONS: Hardware Settings Code Symbology Code 128 Data Matrix ECC 200 Code Resolution 0.30 mm (12 mils)
- Page 27 MATRIX 450™ QUICK REFERENCE GUIDE Matrix 450™ + LNS-1235 Code 1D 0.25 mm (10 mils) Code 1D 0.30 mm (12 mils) (cm) (in) Reading Distance CONDITIONS: Hardware Settings Code Symbology Code 128 Code Resolution 0.25 mm (10 mils) 0.30 mm (12 mils)
-
Page 28: Mechanical Dimensions
MATRIX 450™ QUICK REFERENCE GUIDE MECHANICAL DIMENSIONS [7.95] 22.5 [0.89] [0.35] [1.77] [2.17] [0.20] [4.92] [5.61] M 5 x 8 n°3 compact assembly [7.05] [7.95] [0.20] [5.91] [3.54] standard assembly [1.18] Figure 18 – Matrix 450™ + LT-03x + L-Bracket Overall Dimensions... -
Page 29: Technical Features
High ambient temperature applications should use metal mounting bracket for heat dissipation. When operating in high vibration environments use two L-shaped mounting brackets and mount the anti-vibration kit for C-mount lenses, see "Accessories" in the Matrix 450™ Reference Manual. Requires correct connection to IP67 cables with seals and Lens Cover mounting. -
Page 30: Physical Features
MATRIX 450™ QUICK REFERENCE GUIDE PHYSICAL FEATURES Dimensions 123 x 64 x 143 mm (4.8 x 2.5 x 5.6 in) Matrix 450™ Matrix 450™ + LT-03x 202 x 213 x 179 mm (8.0 x 8.4 x 7.1 in) Weight (with lens and LT-03x) 3000 g. -
