Yamaha ATS-2030 Quick Start Manual

Supplied items

Before assembling and connecting, make sure you have received all of the following items.
If anything is missing, please call 888-892-6242, 8AM to 5PM PST Monday through Friday.
Sound bar (ATS-CU2030)
Wireless subwoofer Remote control
(NS-WSW41)
Placement
© 2014 Yamaha Corporation
ATS-2030 Quick Start Guide
Two AAA batteries Optical cable
(Install the batteries in
1.5 m (4.9 ft)
the remote control.)
(Use when attaching the sound bar to a wall.)
RCA stereo cable Stand × 2
(For sound bar)
1.5 m (4.9 ft)
Mounting template
Owner's Manual
Screw × 2
(For attaching
the stand)
Place the sound bar in front of or below your TV, either with or
without a stand, at least 2'' away from your TV.
Place the subwoofer to the outside of the sound bar. To avoid
echoes from the wall, face the front side of the subwoofer
slightly inward.
The sound bar may also be mounted on a wall, using the
included mounting template and commercially available
screws. Refer to the Owner's Manual for additional mounting
instructions.
NOTE
• Be careful not to stack the sound bar/subwoofer with any other components,
as vibration may cause system disruption in other components.
Continued to the reverse side
Printed in Indonesia
U
Quick Start Guide
(This sheet)
ZM98660
