AVE digi-2K User Manual

digi – 2K
Digital amplifier with switching power supply

User Manual

Thank you for choosing the digital power amplifier digi – 1K from AVE.
Due to its flexibility the amplifier can be optimally adapted to all acoustic environments.

Technical features

Digital Hifi amplifier with switching power supply 2 x 150/240 W.
Latest SMD-technique
Convincing sound- and impulse behavior
It can be switched internally between 50 / 70 /100 V and 4 Ohm.
Protection circuit for direct current voltage short, thermal overcharge, open output
High performance switch power supply
Input: XLR
Output: Terminal clamp
Dimensions: 480 x 44 x 330 mm (390 mm with connector)
Weight: 6,4 kg / 7,6 kg
Description
The AVE models digi - 2K 2 x 150 and 2 x 240 W are digital amplifiers of class D with a
sinus-capacity of 150 alternatively 240 Watt per channel,
available in 50 / 70 / 100 V and 4 Ohm.
The units fulfill professional demands to reliability, flexibility and sound. They are applicable
alone or additionally to an existing unit.
The Clip-protection circuit offers an optimized security and quality in each situation and a
first-class handling of high-grade components.
Thanks to their flexibility the amplifiers can be adapted perfectly to all acoustic
surroundings.
The units can be interconnected with further final amplifiers.
We grant 2 years guarantee on this device.
Technical modifications are reserved
user manual digi-2K
Vertriebs-
Entwicklungsgesellschaft
mbH
page 1
