Quick Start Guide
GIGASET HELPLINE: 0845 3670812
Preparing the handset
¤
Insert the batteries the right
way round.
The polarity is indicated in/on
the battery compartment.
¤
a
First insert the battery cover at
the top
a
.
¤
Then press the cover
b
clicks into place.
b
If you need to open the battery cover, for
instance to replace the batteries, place
your fingertip in the cavity on the casing
and pull the battery cover upwards.
Initial charging and discharging of the batteries
The correct charge level can only be displayed if the batteries are first fully charged
and discharged.
¤
Place the handset in the base/charging cradle for
10 hours.
¤
Then remove the handset
from the base/charging cradle
and do not replace it until the
10 h
batteries are fully discharged.
Gigaset C610-C610A, QUG, Grossbritannien,
Pack contents
1
2
3
4
7
6
1
one Gigaset C610A base
6
one battery cover
2
7
one mains adapter
one belt clip
3
one Gigaset C610H handset
8
one user guide
plus one quick start guide
4
one phone cord
5
two batteries
If you have purchased a model
9
with multiple handsets the
package should contain two bat-
teries, a battery cover, a belt clip
and a charging cradle
9
with
mains adapter
J
for each addi-
tional handset.
Setting the date and time
Set the date and time so that the correct date and time can be assigned to incoming
calls, and so that the alarm can be used.
¤
Press the key below
Calls
Time
screen display to open the input
field.
until it
The Date/Time submenu is shown on
Date/Time
the display.
¤
Date:
The active input position flashes.
Enter day, month and year as an
31.01.2011
8-digit number via the keypad,
e.g.
4
Q
Time:
2Q
00:00
for 14/10/2011.
Press the right or left control key to
change the input position and cor-
rect an entry.
¤
Press down on the control key to switch to the
time input field.
Date/Time
¤
Date:
Enter the hours and minutes as
four digit numbers via the keypad,
14.10.2009
e.g. QM
5 for 07:15 am.
Time:
Change the input position with
00:00
the control key if necessary.
A31008-M2325-L101-1-7643
Connecting the base station
¤
First connect
the mains
adapter
1
.
¤
Then connect
the telephone
2
jack
2
and
1
insert the
cables into the
cable ducts.
5
Please note:
u
The mains
adapter must always be connected, as the phone will not operate without a
mains connection.
u
Only use the mains adapter and phone cord supplied. Pin connections on tele-
8
phone cables can vary.
u
The LED display should light up at the base station. If not, please
ensure the power lead is fully inserted.
Connecting the charging cradle (if included)
¤
1
¤
2
J
If you need to disconnect the plug from the charg-
ing cradle, press the release button
nect the plug
4
.
Setting the date and time
Back
Save
¤
§Time§
on the
Date/Time
¿
The display shows Saved. You will hear a con-
firmation tone and the handset will automat-
ically return to idle status.
Saved
Display in idle status
u
Reception signal between the base and handset:
– good to poor: Ð i Ñ Ò
– no reception: | flashes
Green: Eco Mode activated
à : answering machine is activated
u
u
Battery charge status:
– y y { { (empty to full)
– y flashes red: batteries almost empty
– xy x{ x{ (charging)
u
INT 1: Internal name of the handset
If Eco Mode+ is activated, the ¼ icon is displayed in
the top left (see chapter "ECO DECT" of user manual.
To ensure your product is set up correctly please check the
following
1
1
u
Have you used phone cord supplied
u
Have you fully inserted the power cable into base station
u
Have you inserted batteries correctly
u
Have you charged the batteries for 10 hours
u
Have you set up Date/Time
PLEASE NOTE:
For a dial tone press the call button c for approx. 2 seconds. Short press opens
redial list.
Message Indication Key
events:
u
missed calls (if caller ID is enabled for your line numbers will be shown)
u
new messages on the answering machine (also indicated by flashing message
counter on base station)
u
new Text messages (SMS) received
If you have problems setting up or operation this product please call
GIGASET HELPLINE
Connect the flat plug from the mains
0845 3670812
adapter
1
.
Plug the mains adapter into the plug
socket
2
.
4
Issued by
Gigaset Communications GmbH
3
and discon-
Frankenstr. 2a. D-46395 Bocholt
3
Frequently asked questions
Q: There is no dial tone.
A: Press call button for 2 seconds (long press) to obtain dial tone. A short press opens
the redial list.
§Save§
Press the key below
on the display
screen to confirm your entry.
Q: The line is crackling / not clear.
A: Have you used the new line cable provided? Please do not use an old cable.
Q: Message indicator flashing on handset and I cannot retrieve my message.
A: Message indicator will flash to indicate missed call as well as new message or text
message.
Please check it is not indicating a new missed call or text message.
Q: The caller ID is not functioning.
A: Have you subscribed to this service (CLIP) from your provider?
Q: Can I record my own announcement on the answer machine.
A: Yes. Please refer to Chapter
"Operating the answer machine of the Gigaset C610A base station"
of your user manual (p. 47).
¤
i
Ã
V
Q: The display is not clear.
A: The display is protected by a plastic film, please make sure you have removed the
07:15
protective film.
INT 1
14 Oct
Q: The handset is not registered.
A: If your handset is not registered, please refer to Chapter "Registering handsets"
of your user manual (p. 55) to instructions how to register handsets manually.
Calls
SMS
For more QUESTIONS AND ANSWERS please refer to chapter "Service (Customer
Care)" of user manual (p. 69).
Final check list
f
on handset will flash to indicate one or all of the following
© Gigaset Communications GmbH 2011
All rights reserved. Subject to availability.
Rights of modification reserved.
www.gigaset.com
A31008-M2325-L101-1-7643
