Vulcan-Hart ARC SAFE 63749 Owner's Manual & Safety Instructions

Vulcan-Hart ARC SAFE 63749 Owner's Manual & Safety Instructions

Auto darkening welding helmet

Advertisement

Owner's Manual & Safety Instructions
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
©
Copyright
2017 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
Visit our website at: http://www.harborfreight.com
Email our technical support at: productsupport@harborfreight.com
®
. All rights reserved.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
17f
63749

Advertisement

Table of Contents
loading

Summary of Contents for Vulcan-Hart ARC SAFE 63749

  • Page 1 Owner’s Manual & Safety Instructions Save This Manual Keep this manual for the safety warnings and precautions, assembly, operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the back of the manual near the assembly diagram (or month and year of purchase if product has no number). Keep this manual and the receipt in a safe and dry place for future reference.
  • Page 2: Important Safety Information

    Table of contents Safety ............2 Maintenance and Servicing ......9 Specifications ..........4 Parts List and Diagram ......11 Operation ............ 6 Warranty ............ 12 WARNING SyMBOLS AND DEFINITIONS This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
  • Page 3 13. This helmet provides protection for intended WARNING purposes only. There are certain applications for which this helmet was designed. Do not modify this helmet and do not use this helmet for a purpose for which it was not intended: a.
  • Page 4: Specifications

    Specifications Description Auto-Darkening Welding Helmet Power Source Solar powered cell with battery assistance (replaceable 3V CR2450 lithium battery) Operating Temperature 14° to 131° F Resting Shade Shade #  3 Shade Range 5 to 8 – 9 to 13 variable UV/IR Protection Up to DIN 16 at all times Lens Type ANSI Z87.1-2010 approved...
  • Page 5 Shade Guide chart Guide for Shade Numbers Shade numbers are given as a guide only and may be varied to suit individual needs. MINIMUM SUGGESTED ARc cURRENT pROcESS ELEcTRODE SIZE pROTEcTIVE SHADE NO. (Amperes) SHADE (comfort) Less than 3/32" (2.4  m m) Less than 60 —...
  • Page 6: Before Welding

    Operating Instructions Read the ENTIRE IMpORTANT SAFETy INFORMATION section at the beginning of this manual including all text under subheadings therein before set up or use of this product. Function The Auto-Darkening Welding Helmet is designed to protect the eyes and face from sparks, splatter, and harmful radiation under normal welding conditions.
  • Page 7 controls Sensitivity Shade control control Knob Knob Mode Switch Shade Range BATTERY Switch Time Delay Replace Test control Battery Button Knob Indicator Figure B Mode Selection and Shade Number 1. Use the Mode Switch to select the mode of 2. Using the Shade Guide Chart on page 5, operation.
  • Page 8: Adjusting Headband

    Time Delay and Sensitivity 1. At the moment the welding operation is started, the filter screen automatically changes from clear Time Delay to dark. The operator can vary the amount of time control Knob it takes the filter to return to a clear state after Adjusts the speed welding stops using the Time Delay Control Knob.
  • Page 9: Maintenance

    Maintenance TO pREVENT SERIOUS INJURy FROM TOOL FAILURE: Do not use damaged equipment. If damage or abnormal operation occurs, have the problem corrected before further use. BEFORE EAcH USE, inspect the general condition of the tool. check for loose hardware, misalignment or binding of moving parts, cracked or broken parts, damaged electrical wiring, and any other condition that may affect its safe operation.
  • Page 10: Battery Installation Or Replacement

    Filter Lens Replacement 1. Squeeze the Lens Holder (F) latches inside the Helmet at the base of the Lens Holder together Auto- and pull the bottom of the Lens Holder towards the Darkening inside of the Helmet to remove. Refer to Figure G. Filter (D) 2.
  • Page 11: Please Read The Following Carefully

    parts List and Diagram pLEASE READ THE FOLLOWING cAREFULLy THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER NOR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT.
  • Page 12: Limited 90-Day Warranty

    Limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
