OWNER / OPERATOR MANUAL
TRIMMERS / STICK EDGERS
BT2200LDC
BC2200E
WARNING
The engine exhaust from this product
contains chemicals known to the State
of California to cause cancer, birth
defects or other reproductive harm.
BT2200LDC
BC2200E
BC2200LDC
HE2200LDC
BC2200LDC
HE2200LDC
IMPORTANT :
Before operating your RedMax product,
read this manual carefully and completely.
5850-93110 (9809)

Advertisement

Table of Contents
loading

Related Manuals for RedMax BC2200E

Summary of Contents for RedMax BC2200E

  • Page 1 The engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. BT2200LDC BC2200E BC2200LDC HE2200LDC BC2200LDC HE2200LDC IMPORTANT : Before operating your RedMax product, read this manual carefully and completely.

  • Page 3: Table Of Contents

    Thank you for choosing a RedMax trimmer / stick edger. This manual will provide you with full understanding of the necessary instructions for assembly, operation and maintenance of the equipment. Please read this manual carefully before starting operation. For continued safe and reliable operation, use ONLY original RedMax parts and accessories, Adhere to all notes and warnings.

  • Page 4: For Safe Operation

    6. A lw a y s use both hands to hold the unit. 7. Do not use any accessory or attachment other than those bearing the RedMax mark and are recommended for the unit. ■ MAINTAIN YOUR UNIT PROPERLY 1.

  • Page 5: Setup

    BT2200LDC Attach the guard above the clamp and slide it down. Rotate it a half turn to set in place. BC2200E BC2200LDC ■ HE2200LDC 1. Install the blade guard to the gear case with the provided 3 screws.

  • Page 6: Fuel

    FUEL The RedMax engines are lubricated by oil specially formulated for air-cooled 2-cycle gasoline engine use. When RedMax oil is not available, use an anti-oxidant added quality oil formulated for air-cooled 2-cycle engine use. RECOMMENDED MIXING RATIO GASOLINE 32 : OIL 1...

  • Page 7: Operation

    OPERATION ■ STARTING ENGINE WARING!!! Keep the cutting head off the ground and clear of surrounding objects as it will start rotating upon starting of the engine. 1. Press the primer bulb until fuel flows out in the clear tube (5 to 7 times). Lace the choke lever in the full choke position.
  • Page 8 3. You can avoid thrown debris by sweeping in the correct direction, I.e., from your right to the left for BT2200LDC & BC2200E, and from your left to the right for BC2200LDC. 4.Use a slow, deliberate action to cut heavy growth.
  • Page 9 OPERATION ■ METAL BLADE USAGE NOTE : Do not use the Metal Cutting Blade for model BT2200LDC and BC2200E • Always cut by guiding the head from your right to left. • When mowing a wide area, start working from the left side to avoid interference of cut grass.
  • Page 10 OPERATION g. Cut only from your right to your left. h. Keep your path of advance clear of material that has been cut and other debris. 3. How you can maintain the best control: a. Keep a good, firm grip on the unit with both hands.

  • Page 11: Maintenance

    MAINTENANCE I. Bump head for BT2200LDC and BC2200E ■ REPLACING TRIMMING LINE To refill a new trimming line either ; A : Install the prewound reel #153577 or B : Rewind the existing reel. For replacement line, use a diameter of .080 in (2.03 mm).
  • Page 12  10  2. Hold the inner reel in place and screw in the Bump Knob bolt in the correct direction (clockwise BC2200E). B : INSTALLING A PREWOUND REEL 1. Follow the instructions in DISASSEM- BLING THE HEAD. 2. Follow the instructions in INSTALLING THE REEL.
  • Page 13 MAINTENANCE WIND LINE THIS SIDE UP THIS SIDE UP  11 ...
  • Page 14 MAINTENANCE ■ AIR FILTER The air filter, if clogged, will reduce the engine performance. Every 30 days, check and clean the filter element in warm, soapy water as required. Dry completely before installing. If the element is broken or shrunk, replace with a new one.

  • Page 15: Specifications

    Fuel ·························································································Mixture (Gasoline 32 : Oil 1) Fuel tank capacity ···············································································································20 (fl.oz) Transmission·Centrifugal clutch,Flex.driveshaft Reduction ratio ·································No reduction Cutting head rotating direction ·······························································Clockwise (Operator view) ■ BC2200E Overall size (LxWxH) ···························································································67.3x9.7x13.8 (in) Dry weight ·························································································································10.6 (lbs) Engine Type ························································································Air-cooled 2-stroke gasoline Model ·············································································································Zenoah G22L...

  • Page 16: Parts List

    PARTS LIST Fig.1 TRIMMER UNIT FOR BT2200LDC Fig.1 TRIMMER UNIT FOR BT2200LDC Key# Description Curved shaft ass'y Flex.drive shaft Throttle housing ass'y Throttle lever Screw Screw Spring Handle ass'y Handle Clamp Screw Cutting head ass'y Lower clamp ass'y Retaining ring...
  • Page 17 Fig.2 TRIMMER UNIT FOR BC2200E Fig.2 TRIMMER UNIT FOR BC2200E Key# Description Straight shaft ass'y Flex drive shaft Throttle housing ass'y Throttle lever Spring Screw Screw Handle ass'y Handle Clamp Screw Gear box ass'y Guard, Cutting head (include item 14)
  • Page 18 Fig.3 TRIMMER UNIT FOR BC2200LDC Fig.3 TRIMMER UNIT FOR BC2200LDC Key# Description Straight shaft ass'y Flex.drive shaft Gear box ass'y Screw Screw set Blade driver Lower retaining washer Throttle housing ass'y Throttle lever Screw Screw Spring Handle ass'y Handle Clamp...
  • Page 19 Fig.4 STICK EDGER UNIT FOR HE2200LDC Fig.4 STICK EDGER UNIT FOR HE2200LDC Key# Description Curved shaft ass'y Flex drive shaft Throttle housing ass'y Throttle lever Spring Screw Screw Handle bracket ass'y Srew Tube closure Grip J-Handle ass'y Gear box ass'y Screw Driver, blade Blade...
  • Page 20 Fig.5 ENGINE GROUP FOR BT2200LDC. BC2200E. BC2200LDC. HE2200LDC  18 ...
  • Page 21 Fig.5 ENGINE GROUP FOR BT2200LDC. BC2200E. BC2200LDC.HE2200LDC Key# Description Part Number Cylinder Gasket, base Bolt Insulator Gasket, insulator Gasket, carburetor Screw Muffler ass'y Arrester Screw Gasket, muffler Plate, muffler Screw Crankcase comp Gasket, case Bearing 06030-06001 Oil seal Oil seal...

  • Page 22: California Emission Control Warranty Statement

    CALIFORNIA EMISSION CONTROL WARRANTY STATEMENT YOUR WARRANTY RIGHTS AND OBLIGATIONS THE CALIFORNIA AIR RESOURCES BOARD AND KOMATSU ZENOAH Co. ARE PLEASED TO EXPLAIN THE EMISSION CONTROL SYSTEM WARRANTY ON YOUR 1995 AND LATER LAWN AND GARDEN EQUIPMENT ENGINE. IN CALIFORNIA, NEW UTILITY AND LAWN AND GARDEN EQUIPMENT ENGINES MUST BE DESIGNED, BUILT AND EQUIPPED TO MEET THE STATE'S STRINGENT ANTI-SMOG STANDARDS.
  • Page 23 ZENOAH AMERICA INC. AT (770)-381-5147. IMPORTANT: YOU WILL RECEIVE A WARRANTY REGISTRATION CARD AT TIME OF PURCHASE. PLEASE FILL OUT THE CARD AND SEND IT TO RedMax / KOMATSU ZENOAH AMERICA WITHIN SEVEN (7) DAYS. BE SURE TO KEEP A COPY FOR YOUR RECORDS.
  • Page 24 KOMATSU ZENOAH AMERICA INC. 1505 Pavilion Place Suite A Norcross, Georgia 30093 © Printed in the USA...
