(Appendix 1)
Detailed Specifications of Webthru SWC 306
1. General
Hardware
CPU
Flash memory
RAM
ROM
OS
Video Channel
Image Resolution
Image Compression
Algorithm
Rate
Performance
Transfer Rate
Decoding Rate
Local Compression rate Max. 30fps/1Ch, 5fps/6Ch
Security
Alarms and I/O
MISC. function
Power Supply
2. Network
Browser
Connector
Installation
Protocols supported
S/W Upgrade
32bit RISC Embedded processor
8MB
16MB
64KB
Embedded Linux
NTSC or PAL video format are supported
6Ch. External Video Inputs
720X486, 720X243, 360X243, 180X121, 90X60
Wavelet
20:1 ~ 300:1
Max. 120fps (With 3KB image)
Max. 30fps(NTSC) / 25 fps(PAL) (on 360X243)
2 ~ 30fps
Password Based User Authentication
IP-filtering (Secure Mode)
Image Encryption
Motion detection
Sends e-mail automatically
Sends the image files through FTP automatically
Software-controlled 6-alarm input
6 Digital Input (Coupler), 6 Digital Output (Relay)
High quality image area setting
Image quality control (10 Levels)
Periodic sending of images through E-Mail or FTP
Gray/Progressive/Single-Shot/Channel Rotate Mode
User customized home page publishing supported by FTP
Audio supported through RS232 port
DC 12V, 1.0A via external power supply
MS Internet Explorer V. 5.0 or higher
JAVA Applet for non PC User (MAC or Unix)
Two 10 Based-T Ethernet
(Network, Loop → Stackable upto 3 boxes only with 1 IP)
Assign IP address using setup program or ARP/RARP protocols
TCP/IP, HTTP, ARP, RARP, ICMP, DHCP, FTP, SMTP, PPP and PPPoE
Flash memory allows central remote software upgrades over network
using FTP or private "Webthru Upgrade" program
32
Webthru SWC 306 User's Guide
