- Page 1 MULTIMEDIA PROJECTOR WX6000 / SX6000 User Commands Revision 1 © 2012 CANON INC. YT1-1451-000...
-
Page 2: Table Of Contents
WX6000 / SX6000 User Commands Table of Contents 1. Overview ......................... 1 2. Communication Specifications ................. 2 Communication Specifications ........................2 Usable Character Codes ..........................3 Communication System (Serial) ......................... 4 Communication System (LAN) ........................4 Commands ..............................5 Other ................................7 3. - Page 3 WX6000 / SX6000 User Commands DZOOM_RAT ..........................36 ERR ............................37 FINE_GAMMA_R ........................38 FINE_GAMMA_G ........................39 FINE_GAMMA_B ........................40 FLTWRN ........................... 41 FREEZE ............................ 42 GAMMA ............................ 43 HDMI_IN ..........................44 HDMI_OVSCAN ........................45 HUE ............................46 IMAGE ............................47 IMAGEFLIP ..........................
-
Page 4: Overview
WX6000 / SX6000 User Commands 1. Overview These specifications describe the methods of controlling both the Projector WX6000 / SX6000 from the PC over an RS-232C connection or LAN. Virtually all operations possible with the remote control can be controlled from the PC. -
Page 5: Communication Specifications
WX6000 / SX6000 User Commands 2. Communication Specifications Communication Specifications The projector can be controlled via RS-232C or LAN connection. PC - Projector connection configuration 9pin RS-232C COM PORT LAN PORT SERVICE PORT Network Connection LAN PORT PROJECTOR Item Specifications... -
Page 6: Usable Character Codes
WX6000 / SX6000 User Commands Usable Character Codes Use ASCII codes in the red and blue areas. No distinction is made between double-byte characters and single-byte characters. Do not use double-byte or triple-byte characters. They will all be recognized as single-byte characters. -
Page 7: Communication System (Serial)
WX6000 / SX6000 User Commands Communication System (Serial) Item Specifications Communication system RS-232-C Start-stop synchronization Semi-duplex communication Transmission speed 19.2 Kbps Character length 8 bits / character Stop bit 2 bits Parity None Transmission format Variable-length records with terminals as delimiters Maximum transmission Maximum of 256 characters (bytes) including delimiters. -
Page 8: Commands
WX6000 / SX6000 User Commands Commands Transmissions sent from the PC to the projector. Transmission format △<Command character strings> △<Delimiter> <Command character strings> Character strings consisting of 0 or more alphanumeric characters. <Delimiters> One of CR (0Dh), LF (0Ah), CR+LF (0Dh+0Ah), Null (00h) Type Possibilities of responses from the projector ■: possible, □: not possible... - Page 9 WX6000 / SX6000 User Commands Response Transmissions sent from the Projector to the PC in response to commands from the PC. Transmission format <Response character string> <Delimiter> <Response character string> Character strings consisting of one or more ASCII characters. The first two characters are always one lowercase letter and a : (colon).
-
Page 10: Other
WX6000 / SX6000 User Commands Other Transmission recognition On the receiving side (the Projector), the data that is able to be received within the character interval of Tc is held, and the transmission is considered received when the delimiter is received. -
Page 11: Communication Flow
WX6000 / SX6000 User Commands 3. Communication Flow Transmission sent At the PC, the transmission is sent within character intervals of Tc (character interval timeout). Transmission received At the Projector, the data that is able to be received within the character interval of Tc is held, and the transmission is considered received when the delimiter is received. -
Page 12: Command System
WX6000 / SX6000 User Commands 4. Command System - 9 -... - Page 13 WX6000 / SX6000 User Commands - 10 -...
-
Page 14: Command List
WX6000 / SX6000 User Commands 5. Command List Item Commands Description 6AXADJ 6-axis adjustment ON/OFF 6AXR-Y 6-axis correction R-Y hue/saturation settings AMBADJ Ambient light correction adjustment ON/OFF AMBLEVEL Ambient light level settings AMBTYPE Ambient light type settings ASELA1 Analog PC-1 audio terminal selection... - Page 15 WX6000 / SX6000 User Commands Commands Description Item KREP Key repeat LAMP Lamp output setting LAMPCOUNTER Lamp ON time inquiry LMPWRN Lamp warning indication at startup MAIN Side control operation emulation MEMCADJ Memory color adjustment MODE Control mode switch MUTE...
-
Page 16: Details Of Commands
WX6000 / SX6000 User Commands 6. Details of Commands Descriptions of each command are provided starting from the next page. The command descriptions have the format shown below. Alphabetic command name This briefly describes the command function. Format This indicates the command format. -
Page 17: 6Axadj
WX6000 / SX6000 User Commands 6AXADJ 6-axis adjustment ON / OFF Format 6AXADJ=<6-axis adjustment parameter ID> GET□6AXADJ ?△6AXADJ <6-axis adjustment parameter:ID> This sets the 6-axis adjustment to ON. This sets the 6-axis adjustment to OFF. Environment Power Input D-RGB A-RGB... -
Page 18: 6Axr-Y
WX6000 / SX6000 User Commands 6AXR-Y 6-axis correction R-Y hue / saturation settings Format 6AXR=<R hue:Number>▽<R saturation:Number>▽<R brightness:Number> 6AXG=<G hue:Number>▽<G saturation:Number>▽<G brightness:Number> 6AXB=<B hue:Number>▽<B saturation:Number>▽<B brightness:Number> 6AXC=<C hue:Number>▽<C saturation:Number>▽<C brightness:Number> 6AXM=<M hue:Number>▽<M saturation:Number>▽<M brightness:Number> 6AXY=<Y hue:Number>▽<Y saturation:Number>▽<Y brightness:Number> GET□6AXR ?△6AXR GET□6AXG... -
Page 19: Ambadj
WX6000 / SX6000 User Commands AMBADJ Ambient light correction adjustment ON / OFF Format AMBADJ=<Ambient light correction adjustment parameter:ID> GET□AMBADJ ?△AMBADJ <Ambient light correction adjustment parameter:ID> This sets the ambient light correction adjustment to ON. This sets the ambient light correction adjustment to OFF. -
Page 20: Amblevel
WX6000 / SX6000 User Commands AMBLEVEL Ambient light level settings Format AMBLEVEL=<Ambient light level settings parameter:ID> GET□AMBLEVEL ?△AMBLEVEL <Ambient light level settings parameter:ID> WEAK This sets the ambient light level to WEAK. MIDDLE This sets the ambient light level to MIDDLE. -
Page 21: Ambtype
WX6000 / SX6000 User Commands AMBTYPE Ambient light type settings Format AMBTYPE=<Ambient light type settings parameter:ID> GET□AMBTYPE ?△AMBTYPE <Ambient light type settings parameter:ID> This sets the ambient light type to Tungsten. This sets the ambient light type to Fluorescent. FL_H This sets the ambient light type to Fluorescent H. -
Page 22: Asela1
WX6000 / SX6000 User Commands ASELA1 Analog PC-1 audio terminal selection Format ASELA1=<Analog PC-1 audio terminal selection: ID> GET□ASELA1 ?△ASELA1 <Analog PC-1 Audio terminal selection parameter: ID> Audio In 1 Audio In 2 Turned off Environment Power Input D-RGB A-RGB... -
Page 23: Asela2
WX6000 / SX6000 User Commands ASELA2 Analog PC-2 Audio terminal selection Format ASELA2=<Analog PC-2 audio terminal selection: ID> GET□ASELA2 ?△ASELA2 <Analog PC-2 audio terminal selection: ID> Audio In 2 Audio In 2 Turned off Environment Power Input D-RGB A-RGB COMP... -
Page 24: Aselc
WX6000 / SX6000 User Commands ASELC Component audio terminal selection Format ASELC=<Component audio terminal selection parameter: ID> GET□ASELC ?△ASELC <Component audio terminal selection parameter: ID> Audio In 1 Audio In 2 Turned off Environment Power Input D-RGB A-RGB COMP HDMI... -
Page 25: Aseld
WX6000 / SX6000 User Commands ASELD Digital PC audio terminal selection Format ASELD=<Digital PC audio terminal selection parameter: ID> GET□ASELD ?△ASELD <Digital PC audio terminal selection parameter: ID> Audio In 1 Audio In 2 Turned off Environment Power Input D-RGB... -
Page 26: Aselh
WX6000 / SX6000 User Commands ASELH HDMI audio terminal selection Format ASELH=<HDMI audio terminal selection parameter: ID> GET□ASELH ?△ASELH <HDMI audio terminal selection parameter: ID> HDMI audio Audio In 1 Audio In 2 Turned off Environment Power Input D-RGB A-RGB... -
Page 27: Aspect
WX6000 / SX6000 User Commands ASPECT Screen settings Format ASPECT=<Screen setting parameters: ID> GET□ASPECT ?△ASPECT <Screen setting parameters:ID> AUTO Auto 16:9 16:9 16:10 16:10 ZOOM Zoom TRUE Real Environment Power Input Parameter D-RGB A-RGB COMP HDMI None ○ ○ ○... - Page 28 WX6000 / SX6000 User Commands Example Setting This sets the screen size to 16:9. > ASPECT=16:9 < i:OK Reference > GET ASPECT or ?ASPECT This retrieves the screen size. < g:ASPECT=TRUE *Commands are indicated by ">", and responses are indicated by "<".
-
Page 29: Autopc
WX6000 / SX6000 User Commands AUTOPC Auto PC Format AUTOPC△ Environment Power Input D-RGB A-RGB COMP HDMI None Response "i:OK" is returned if the control was executed properly. For details on other responses, refer to the "Error List". Description This executes Auto PC. -
Page 30: Autosetexe
WX6000 / SX6000 User Commands AUTOSETEXE Auto setup Format AUTOSETEXE□<Auto set parameter:ID> <Auto set parameter:ID> INPUT Automatic signal sensing execution Environment Power Input D-RGB A-RGB COMP HDMI None Response i:OK” is returned when the automatic processing was completed successfully. For details on other responses, refer to the "Error List". -
Page 31: Avol
WX6000 / SX6000 User Commands AVOL Audio volume adjustment Format AVOL=<Audio volume level:Number> GET□AVOL ?△AVOL Setting values for <Audio volume level:Number> are 0 to 20. Environment Power Input D-RGB A-RGB COMP HDMI None Response "i:OK" is returned if the parameter was set properly. -
Page 32: Blank
WX6000 / SX6000 User Commands BLANK BLANK function Format BLANK=<BLANK parameter:ID> GET□BLANK ?△BLANK <BLANK parameter:ID> BLANK ON BLANK OFF Environment Power Input D-RGB A-RGB COMP HDMI None Response "i:OK" is returned if the parameter was set properly. For ' ' or '... -
Page 33: Bri
WX6000 / SX6000 User Commands Brightness setting Format BRI=<Brightness setting:Number> GET□BRI ?△BRI Setting values for <Brightness setting:Number> are -20 to 20. Environment Power Input D-RGB A-RGB COMP HDMI None Response "i:OK" is returned if the parameter was set properly. For '... -
Page 34: Color_Temp
WX6000 / SX6000 User Commands COLOR_TEMP Color temperature setting Format COLOR_TEMP=<Color temperature setting:Number> GET□COLOR_TEMP ?△COLOR_TEMP Setting values for <Color temperature setting:Number> are -17 to 21. Environment Power Input D-RGB A-RGB COMP HDMI None Response "i:OK" is returned if color temperature was set properly. -
Page 35: Comver
WX6000 / SX6000 User Commands COMVER User command version inquiry Format GET□COMVER ?△COMVER Environment Power Input D-RGB A-RGB COMP HDMI None Response Returns the user command version as g:COMVER="<User command version:Character string>" For details on other responses, refer to the "Error List". -
Page 36: Cont
WX6000 / SX6000 User Commands CONT Contrast setting Format CONT=<Contrast setting:Number> GET□CONT ?△CONT Setting values for <Contrast setting:Number> are -20 to 20. Environment Power Input D-RGB A-RGB COMP HDMI None Response "i:OK" is returned if the parameter was set properly. -
Page 37: Dgamma
WX6000 / SX6000 User Commands DGAMMA Dynamic gamma Format DGAMMA=<Dynamic gamma setting parameter:ID> GET□DGAMMA ?△DGAMMA <Dynamic gamma setting parameter:ID> WEAK Weak MIDDLE Middle STRONG Strong Environment Power Input D-RGB A-RGB COMP HDMI None Response "i:OK" is returned if the parameter was set properly. -
Page 38: Dzoom_Pos
WX6000 / SX6000 User Commands DZOOM_POS DZOOM position setting Format DZOOM_POS=<DZOOM position X:Number>,<DZOOM position Y:Number> GET□DZOOM_POS ?△DZOOM_POS <DZOOM position X / Y:Number> is a signed integer indicating the central position of the enlarged input image. Environment Power Input D-RGB A-RGB... -
Page 39: Dzoom_Rat
WX6000 / SX6000 User Commands DZOOM_RAT DZOOM ratio setting Format DZOOM_RAT=<DZOOM ratio parameter:ID> GET□DZOOM_RAT ?△DZOOM_RAT <DZOOM ratio parameter:ID> same size (DZOOM disabled) 1.5x Environment Power Input D-RGB A-RGB COMP HDMI None Response "i:OK" is returned if DZOOM ratio was set properly. -
Page 40: Err
WX6000 / SX6000 User Commands Error information inquiry Format GET□ERR ?△ERR Environment Power Input D-RGB A-RGB COMP HDMI None Response Returns the current error information as 'g:ERR=<ErrorID:Character string>' For details on other responses, refer to the "Error List". <ErrorID:Character string>... -
Page 41: Fine_Gamma_R
WX6000 / SX6000 User Commands FINE_GAMMA_R Fine gamma (R) adjustment Format FINE_GAMMA_R=<Fine gamma (R) adjustment point 1 adjustment value:Number>, <Fine gamma (R) adjustment point 2 adjustment value:Number>, ・・・,<Fine gamma (R) adjustment point n adjustment value:Number> GET□FINE_GAMMA_R ?△FINE_GAMMA_R Adjustment values for <Fine gamma (R) adjustment point n adjustment value:Number> are 0 to 1024. -
Page 42: Fine_Gamma_G
WX6000 / SX6000 User Commands FINE_GAMMA_G Fine gamma (G) adjustment Format FINE_GAMMA_G=<Fine gamma (G) adjustment point 1 adjustment value:Number>, <Fine gamma (G) adjustment point 2 adjustment value:Number>, ・・・,<Fine gamma (G) adjustment point n adjustment value:Number> GET□FINE_GAMMA_G ?△FINE_GAMMA_G Adjustment values for <Fine gamma (G) adjustment point n adjustment value:Number> are 0 to 1024. -
Page 43: Fine_Gamma_B
WX6000 / SX6000 User Commands FINE_GAMMA_B Fine gamma (B) adjustment Format FINE_GAMMA_B=<Fine gamma (B) adjustment point 1 adjustment value:Number>, <Fine gamma (B) adjustment point 2 adjustment value:Number>, ・・・,<Fine gamma (B) adjustment point n adjustment value:Number> GET□FINE_GAMMA_B ?△FINE_GAMMA_B Adjustment values for <Fine gamma (B) adjustment point n adjustment value:Number> are 0 to 1024. -
Page 44: Fltwrn
WX6000 / SX6000 User Commands FLTWRN Filter warning indication at startup Format FLTWRN=<Filter warning parameter: ID> GET□FLTWRN ?△FLTWRN <Filter warning parameter: ID> Turned off Turned on Environment Power Input D-RGB A-RGB COMP HDMI None Response "i:OK" is returned when setting of filter warning indication at startup was completed successfully. -
Page 45: Freeze
WX6000 / SX6000 User Commands FREEZE Freeze status Format FREEZE=<FREEZE parameter:ID> GET□FREEZE ?△FREEZE <FREEZE parameter:ID> Image now frozen Image now not frozen Environment Power Input D-RGB A-RGB COMP HDMI None Response "i:OK" is returned if the parameter was set properly. -
Page 46: Gamma
WX6000 / SX6000 User Commands GAMMA Gamma adjustment Format GAMMA=<Gamma adjustment:Number> GET□GAMMA ?△GAMMA Setting values for <Gamma adjustment: Number> are -10 to 10. Environment Power Input D-RGB A-RGB COMP HDMI None Response "i:OK" is returned if the parameter was set properly. -
Page 47: Hdmi_In
WX6000 / SX6000 User Commands HDMI_IN HDMI input setting Format HDMI_IN=<HDMI input setting parameter:ID> GET□HDMI_IN ?△HDMI_IN <HDMI input setting parameter:ID> AUTO Select this when connecting to an AV equipment. Image processing and menu displays are adjusted respective to the connected video equipment. -
Page 48: Hdmi_Ovscan
WX6000 / SX6000 User Commands HDMI_OVSCAN HDMI overscan setting Format HDMI_OVSCAN=<HDMI overscan setting parameter:ID> GET□HDMI_OVSCAN ?△HDMI_OVSCAN <HDMI overscan setting parameter:ID> Turns overscan to OFF Turns overscan to ON Environment Power Input D-RGB A-RGB COMP HDMI None Response "i:OK" is returned if HDMI overscan was set properly. -
Page 49: Hue
WX6000 / SX6000 User Commands Hue setting Format HUE=<Hue setting value:Number> GET□HUE ?△HUE Setting values for <Hue setting value:Number> are -20 to 20. Environment Power Input D-RGB A-RGB COMP HDMI None Response "i:OK" is returned if the parameter was set properly. -
Page 50: Image
WX6000 / SX6000 User Commands IMAGE Image mode setting Format IMAGE=<Image mode setting parameter:ID> GET□IMAGE ?△IMAGE <Image mode setting parameter:ID> STANDARD Standard PRESENTATION Presentation VIVID_PHOTO Vivid photo PHOTO_SRGB Photo / sRGB DCM_SIM DICOM Sim* DYNAMIC Dynamic VIDEO Video CINEMA Cinema... - Page 51 WX6000 / SX6000 User Commands Setting Commands related to the settings Dynamic gamma FINE_GAMMA_R∼B Memory color adjustment MEMCADJ RGB gain / offset adjustment RGBGAIN / RGBOFFSET Lamp mode LAMP 6-axis adjustment 6AXADJ 6-axis color correction 6AXR∼Y The current image quality can be acquired using the applicable GET command. ("...
-
Page 52: Imageflip
WX6000 / SX6000 User Commands IMAGEFLIP Flip display Format IMAGEFLIP=<Image flip setting parameters:ID> GET□IMAGEFLIP ?△IMAGEFLIP <Image flip setting parameters:ID> NONE None CEILING Ceiling REAR Rear projection REAR_CEILING Rear projection with ceiling Environment Power Input D-RGB A-RGB COMP HDMI None Response "i:OK"... -
Page 53: Input
WX6000 / SX6000 User Commands INPUT Input selection Format INPUT=<Input selection parameters:ID> GET□INPUT ?△INPUT <Input selection parameters:ID> D-RGB Digital PC A-RGB1 Analog PC-1 A-RGB2 Analog PC-2 COMP Component HDMI HDMI Environment Power Input D-RGB A-RGB COMP HDMI None Response "i:OK" is returned if the parameter was set properly. -
Page 54: Krep
WX6000 / SX6000 User Commands KREP Key repeat Format KREP=<Key repeat parameter: ID> GET□KREP ?△KREP <Key repeat parameter: ID> Turned off Turned on Environment Power Input D-RGB A-RGB COMP HDMI None Response "i:OK" is returned when Key repeat parameter was completed successfully. -
Page 55: Lamp
WX6000 / SX6000 User Commands LAMP Lamp output setting Format LAMP=<Lamp output setting parameters:ID> GET□LAMP ?△LAMP <Lamp output setting parameters:ID> NORMAL Normal SILENT Silent cooling Environment Power Input D-RGB A-RGB COMP HDMI None Response "i:OK" is returned if the parameter was set properly. -
Page 56: Lampcounter
WX6000 / SX6000 User Commands LAMPCOUNTER Lamp ON time inquiry Format GET□LAMPCOUNTER ?△LAMPCOUNTER Environment Power Input D-RGB A-RGB COMP HDMI None Response Returns current lamp on time as g:LAMPCOUNTER="<Lamp ON time:Character string>" For details on other responses, refer to the "Error List". -
Page 57: Lmpwrn
WX6000 / SX6000 User Commands LMPWRN Lamp warning indication at startup Format LMPWRN=<Lamp warning parameter: ID> GET□LMPWRN ?△LMPWRN <Lamp warning parameter: ID> Turned off Turned on Environment Power Input D-RGB A-RGB COMP HDMI None Response "i:OK" is returned when setting of lamp warning indication at startup was completed successfully. -
Page 58: Main
WX6000 / SX6000 User Commands MAIN Side control operation emulation Format MAIN□<Side control emulation button parameters:ID> <Side control emulation button parameters:ID> POWER POWER button POWER_OFF POWER button pressed twice MENU MENU LENS LENS INPUT INPUT UP+REP Hold down the UP button... -
Page 59: Memcadj
WX6000 / SX6000 User Commands MEMCADJ Memory color adjustment Format MEMCADJ=<Memory color adjustment parameter:ID> GET□MEMCADJ ?△MEMCADJ <Memory color adjustment parameter:ID> No adjustment MEM_L Memory color adjustment - light MEM_M Memory color adjustment - medium MEM_H Memory color adjustment - heavy... -
Page 60: Mode
WX6000 / SX6000 User Commands MODE Control mode switch Format REMOTE LOCAL GET□MODE ?△MODE Environment Power Input D-RGB A-RGB COMP HDMI None Response "i:OK" is always returned with the control mode switch setting. For ' ' or ' ', current control mode is returned as... -
Page 61: Mute
WX6000 / SX6000 User Commands MUTE Mute control Format MUTE=<Mute control parameter: ID> GET□MUTE ?△MUTE <Mute control parameter: ID> Disables the audio / beep sound. Enables the audio / beep sound. Environment Power Input D-RGB A-RGB COMP HDMI None Response "i:OK"... - Page 62 WX6000 / SX6000 User Commands Noise reduction Format NR=<Noise reduction setting parameter:ID> GET□NR ?△NR <Noise reduction setting parameter:ID> WEAK Weak MIDDLE Middle STRONG Strong Environment Power Input D-RGB A-RGB COMP HDMI None Response "i:OK" is returned if noise reduction was set properly.
-
Page 63: Power
WX6000 / SX6000 User Commands POWER This controls the power supply Format POWER□<Parameter:ID> GET□POWER ?△POWER <Parameter:ID> Power ON Power OFF Environment Power Input D-RGB A-RGB COMP HDMI None Response "i:OK" is returned if the parameter was set properly. For ' ' or ' ', current power supply status is returned as shown in the table below. -
Page 64: Prodcode
WX6000 / SX6000 User Commands PRODCODE Product information inquiry Format GET□PRODCODE ?△PRODCODE Environment Power Input D-RGB A-RGB COMP HDMI None Response Product name is returned as g:PRODCODE="<Product name:Character string>" For details on other responses, refer to the "Error List". <Product name:Character string>... - Page 65 WX6000 / SX6000 User Commands Remote control operation emulate Format RC□<Remote control emulation button parameters:ID> <Remote control emulation button parameters:ID> POWER POWER button POWER_OFF POWER button pressed twice MENU MENU EXIT EXIT INPUT INPUT DIGITAL APC1 ANALOG PC1 APC2 ANALOG PC2...
- Page 66 WX6000 / SX6000 User Commands * After setting the status of the button to be pressed down, send a command from the PC to release the pressed status after predetermined time. . * Although emulation parameters for both values and function are available for the common key for 1/DZOOM+, 3/VOL+, 4/DZOOM-, 6/VOL- and 9/MUTE, there is no difference in operation so that it works in the same manner as when the "Common key"...
-
Page 67: Rgbgain
WX6000 / SX6000 User Commands RGBGAIN RGB gain adjustment Format RGBGAIN=<R gain setting:Number>▽<G gain setting:Number>▽<B gain setting:Number> GET□RGBGAIN ?△RGBGAIN Setting values for <R/G/B gain setting:Number> are -60 to 60. Environment Power Input D-RGB A-RGB COMP HDMI None Response "i:OK" is returned if the parameter was set properly. -
Page 68: Rgboffset
WX6000 / SX6000 User Commands RGBOFFSET RGB offset adjustment Format RGBOFFSET=<R offset setting:Number>▽<G offset setting:Number>▽<B offset setting:Number> GET□RGBOFFSET ?△RGBOFFSET Setting values for <R/G/B offset setting:Number> are -60 to 60. Environment Power Input D-RGB A-RGB COMP HDMI None Response "i:OK" is returned if the parameter was set properly. -
Page 69: Romver
WX6000 / SX6000 User Commands ROMVER ROM version inquiry Format GET□ROMVER ?△ROMVER Environment Power Input D-RGB A-RGB COMP HDMI None Response ROM version of the firmware is returned as g:ROMVER="<ROM version:Character string>" For details on other responses, refer to the "Error List". -
Page 70: Sat
WX6000 / SX6000 User Commands Color saturation setting Format RGBGAIN=<R gain setting:Number>▽<G gain setting:Number>▽<B gain setting:Number> GET□RGBGAIN ?△RGBGAIN Setting values for <Color saturation setting value:Number> are -20 to 20. Environment Power Input D-RGB A-RGB COMP HDMI None Response "i:OK" is returned if the parameter was set properly. -
Page 71: Saveimgprof
WX6000 / SX6000 User Commands SAVEIMGPROF Create, save, delete user memory / Create user memory status Format SAVEIMGPROF=<User memory save to parameter:ID> <User memory save to parameter:ID> USER_1 Save to User 1 USER_2 Save to User 2 USER_3 Save to User 3... -
Page 72: Scrnaspect
WX6000 / SX6000 User Commands SCRNASPECT Screen aspect setting Format SCRNASPECT=<Screen aspect setting parameter:ID> GET□SCRNASPECT ?△SCRNASPECT <Screen aspect setting parameter:ID> 16:10 16:10 16:9 16:9 display 4:3 display 16:10_DIS 16:10 digital image shift *Not available with WX6000 16:9_DIS 16:9 digital image shift... -
Page 73: Sharp
WX6000 / SX6000 User Commands SHARP Sharpness setting Format SHARP=<Sharpness setting:Number> GET□SHARP ?△SHARP Setting values for <Sharpness setting:Number> are -10 to 10. Environment Power Input D-RGB A-RGB COMP HDMI None Response "i:OK" is returned if the parameter was set properly. -
Page 74: Signal_Info
WX6000 / SX6000 User Commands SIGNAL_INFO Input signal information inquiry Format GET□SIGNAL_INFO ?△SIGNAL_INFO Environment Power Input D-RGB A-RGB COMP HDMI None Response Current input signal information is returned as g:SIGNAL_INFO="<Input signal information:Character string>" For details on other responses, refer to the "Error List". -
Page 75: Signalstatus
WX6000 / SX6000 User Commands SIGNALSTATUS Signal status inquiry Format GET□SIGNALSTATUS ?△SIGNALSTATUS Environment Power Input D-RGB A-RGB COMP HDMI None Response Current image signal input status is returned as 'g:SIGNALSTATUS=<Signal status:ID>' For details on other responses, refer to the "Error List". -
Page 76: Temp
WX6000 / SX6000 User Commands TEMP Temperature sensor value inquiry Format GET□TEMP ?△TEMP Environment Power Input D-RGB A-RGB COMP HDMI None Response For ' ' or ' ', temperature sensor value is returned as GET TEMP ?TEMP TEMP=<Number of sensors>,<Sensor 1 value>,…,<Sensor n value>... -
Page 77: Tptn
WX6000 / SX6000 User Commands TPTN Test pattern Format TPTN=<Test pattern parameter: ID> GET□TPTN ?△TPTN < Test pattern parameter: ID> Turned off Color bar SSH1 Stair step H No.1 SSH2 Stair step H No.2 SSH3 Stair step H No.3 SSV1 Stair step V No.1... - Page 78 WX6000 / SX6000 User Commands Reference Test pattern is acquired. > GET TPTN or ?TPTN GET TPTN or ?TPTN < g:TPTN=OFF *Commands are indicated by ">", and responses are indicated by "<". - 75 -...
-
Page 79: Error List
WX6000 / SX6000 User Commands 7. Error List Item Code TYPE Error character strings Error Remedy Wait until a response is received before 0001 BAD_SEQUENCE Communication sequence error sending the next command. 0002 INVALID_COMMAND Invalid (undefined) command. Send a valid command. - Page 80 WX6000 / SX6000 User Commands Item Code TYPE Error character strings Error Remedy Cannot execute command with 201F INVALID_SIGNAL Change the input signal. current input signal. Numerical parameters are 17 0801 INVALID_VALUE invalid or outside the specified Set the parameters in the correct range.
-
Page 81: Error Processing
WX6000 / SX6000 User Commands 8. Error Processing START Error judgment Processing user command? "BAD_SEQUENCE" Invalid (undefined) "INVALID_COMMAND" command? "INVALID_FORMAT" Invalid command format? Command executable while power mode is OFF? "NOT_POWER_SUPPLIED" Power mode is "OFF"? Command executable with PMM? "NOT_POWER_SUPPLIED"... - Page 82 WX6000 / SX6000 User Commands Limitations in input source? Incorrect input source? "INVALID_SOURCE (**)" Requires input signal? No input signal? "NO_SIGNAL" Invalid input signal? "INVALID_SIGNAL (**)" Numerical parameter "INVALID_VALUE" outside the specified range? User command is executable FINISHED - 79 -...
