- Page 1 4890-SP-D-4S DVI S PLITTER BCI reserves the right to make changes to the products described herein without prior notice or consent. No liability is assumed as a result of their use or application. All rights reserved. ©2010 Broadata Communications, Inc.
- Page 2 BCI 4890-SP-D-4S User’s Manual DVI Splitter SAFETY INSTRUCTIONS AND COMPLIANCE DECLARATIONS PLEASE OBSERVE THE FOLLOWING SAFETY PRECAUTIONS AS OUR PRODUCTS CONTAIN CLASS I LASER PRODUCTS WARNING Do not disconnect the fiber optic connector while the unit is powered up. Exposure to laser radiation is possible when the laser fiber optic connector is disconnected while the unit is powered up.
-
Page 3: Table Of Contents
BCI 4890-SP-D-4S User’s Manual DVI Splitter TABLE OF CONTENTS 1.0 PRODUCT DESCRIPTION ..........5 2.0 OPERATION CONTROLS AND FUNCTIONS ....5 3.0 CONNECTION AND INSTALLATION......6 4.0 SPECIFICATIONS ............7 5.0 SERVICE PROCEDURE ..........8 5.1 REPLACEMENT POLICY ..........8 5.2 RETURN AND REPAIR SERVICE ........8 6.0 LIMITED WARRANTY ............ -
Page 4: Product Description
HDMI to DVI adaptor cable. It supports a wide range of PC and HDTV resolutions from VGA to UXGA and 480p to 1080p. This 4890-SP-D-4S can be cascaded up to 3 layers. Each of the buffered output can run up to 15 meters. -
Page 5: Connection And Installation
BCI 4890-SP-D-4S User’s Manual DVI Splitter Rear Panel 1. DVI output 2/3/4: Connect these ports to the digital input of each output display. 3.0 CONNECTION AND INSTALLATION Broadata Technical Support, (800) 214-0222... -
Page 6: Specifications
BCI 4890-SP-D-4S User’s Manual DVI Splitter 4.0 SPECIFICATIONS Frequency Bandwidth 1.5Gbps (single link) Input/Output 1-in/4-out DVI female port Power Consumption 6W max. Power 5VDC Universal Power Supply Physical Dimension (H x W x D) 1.49” x 4.02” x 5.55” Operating Temperature... -
Page 7: Service Procedure
U.S. Please call Customer Service at 800-214-0222 for information. 5.2 Return/Repair Service The BCI 4890-SP-D-4S System contains no user serviceable components. If you have a problem with your unit, please contact the Customer Service Department. To facilitate our return/repair processing please contact Broadata Communications, Inc. -
Page 8: Limited Warranty
DVI Splitter 6.0 LIMITED WARRANTY Broadata Communications, Inc. (BCI) warrants, for a period of one year from date of shipment, each product sold shall be free from defects in material and workmanship. BCI will correct, either by repair, or at BCI’s... - Page 9 Broadata Communications, Inc. 2545 West 237th Street, Suite K Torrance, CA 90505 1-800-214-0222 (310) 530-1416 (310) 530-5958 (Facsimile) e-mail: CustomerService@Broadatacom.com Website: www.broadatacom.com 60000-4890-SP-D-4S...
