L L X 570 Pre-Delivery Service Manual
Lexus Technician:
Before you perform a Pre-Delivery Service (PDS) on this vehicle, be sure you:
• Read and understand this PDS Manual
• Read and understand the PDS Precautions on page 69, 70
• Read and understand all applicable PDS Technical Service Information Bulletins (TSIBs) for this vehicle
• Attend the "Technical Introduction to Lexus Course L005" at the Lexus Area Office
When performing a PDS on this vehicle:
• Use the PDS Manual when performing this service
• Check the Techincal Information System (TIS) for PDS Technical Service Information Bulletins
(TSIBs) that apply to the model you are servicing
• Verify the Vehicle Identification Number (VIN) on repair order and vehicle match
• Lift vehicle and perform undervehicle safety/damage inspection
• Road test vehicle long enough to test hot engine and driven over rough road/Bott dots to test for
rattles/squeaks
• When completed, sign Vehicle Delivery Certificate, located in the glovebox
The following TSIBs are available on TIS:
Battery Maintenance for In-Stock Vehicles & Pre-Delivery (Revised)
Floor Mat Installation During PDS
Front License Plate Mounting Bracket & License Plate Installation
Installation of Towing Wire Harness Connector During PDS
Long Term Vehicle Storage Guidelines
Roof Rack Cross Bar Installation During PDS
Short Pin Installation During PDS
Tire Positioning Before New Vehicle Delivery (Revised)
Tire Pressure Warning System Activation & Initialization
To obtain PDS material:
Manual
• Download from TIS website or Lexus Customer Services website on Dealer daily
• Order from MDC, 00242-PDSLX-MAN14
Check Sheet
• Sheet is two-sided, back side has procedure tips
• Order from MDC, 00242-PDSLX-CK14, each packet contains 25 Check Sheets
• Download from TIS website or Lexus Customer Services website on Dealer Daily
Vehicle Delivery Certificate
• Order from MDC, 00242-TIQ13
Other PDS TSIBs
• Download from TIS website
Contact your District Service & Parts Manager if you have any questions.
MDC #00242-PDSLX-MAN14 ©2013 Lexus, a Division of Toyota Motor Sales, U.S.A., Inc.
20130729CJE

Advertisement

Table of Contents
loading

Related Manuals for Lexus LX570

Summary of Contents for Lexus LX570

  • Page 1 • Read and understand the PDS Precautions on page 69, 70 • Read and understand all applicable PDS Technical Service Information Bulletins (TSIBs) for this vehicle • Attend the “Technical Introduction to Lexus Course L005” at the Lexus Area Office When performing a PDS on this vehicle: •...
  • Page 2 - THIS PAGE INTENTIONALLY LEFT BLANK -...
  • Page 3 3 3 3 '6 0$18$/ '6 0$18$/ '6 0$18$/ '6 0$18$/...

  • Page 4: Table Of Contents

    INDEX Section 1 Engine oil level Rear door release (manual) Technical Service Information Bulletins Exterior lights Rear seat entertainment system Exhaust system Battery maintenance Remote entry Floor mat installation Fluid leaks Road test Front license bracket Front seat position memory RSCA switch Long term vehicle storage Front &...
  • Page 5 Bott Dot Road Test Layout As part of the PDS road test, the vehicle must be driven over a rough road surface or over Bott Dots in order to check for squeeks and rattles. If a rough surface is not available for this road test, Bott Dots should be installed on the dealership property where vehicles can be safely driven 5 to 10 mph.
  • Page 6 G. Final Inspection ........86 H. Two Hours Before Delivery ......88 LX570...

  • Page 7: Before Starting Pre-Derivery Service

    INSPECTION OVERVIE2 BEFORE STARTING PRE-DERIVERY SERVICE LX570...
  • Page 8 3. ENGINE COMPARTMENT SIDE COV- ER REMOVAL Push the core of the clips of the engine com- partment side cover and remove the clips. After that, remove the engine compartment side cover. 08LXI001I 4. SHORT PIN INSTALLATION Refer to the Service Bulletin LX570...
  • Page 9 BEFORE STARTING PRE-DELIVERY SERVICE 5. ENGINE COMPARTMENT COVER IN- STALLATION Installation is in the reverse order of remov- Insert the clips, as shown in the illustration. 08LXI003I 6. INSTALLATION OF ROOF RACK CROSSBARS Refer to the Service Bulletin LX570...
  • Page 10 BEFORE STARTING PRE-DELIVERY SERVICE 7. FRONT LICENSE PLATE MOUNTING BRACKET AND LICENSE PLATE IN- STALLATION Refer to the Service Bulletinn LX570...

  • Page 11: Shift Lock Override Button Cover

    BEFORE STARTING PRE-DELIVERY SERVICE 8. SHIFT LOCK OVERRIDE BUTTON COVER INSTALLATION Install the cover into the shift lock override button hole. NOTE: The cover is in a plastic envelope attached to the shift lever. 08LXI011I LX570...
  • Page 12 MEMO BEFORE STARTING PRE-DERLIVERY SERVIC7 - THIS PAGE INTENTIONALLY LEFT BLANK - LX570...

  • Page 13: Inspection Overview

    INSPECTION OVERVIEW8 INSPECTION OVERVIEW LX570...
  • Page 14 B13. Check windshield wipers and washers B14. Check headlight cleaner* B15. Check warning lights and indicator lights B16. Check multi-information display B17. Check LEXUS navigation system* B18. Check air conditioning B19. Check seat heaters/climate control seats* B20. Check audio system B21.
  • Page 15 Detail starts on page 22 C. LUGGAGE COMPARTMENT C01. Check tools, jack and jack handle C02. Check manual back door opener C03. Check trim appearance and luggage car- pet fit Detail starts on page 64. 08LXII003I * Optional equipment LX570...
  • Page 16 E06. Visually check transfer case & differential for leaks E07. Check chassis inspection for leakage or damage E08. Check/tighten chassis bolts of components that are replaced due to repairs E09. Check exhaust system E10. Install towing wire harness connector Detail starts on page 72. 08LXII006Y LX570...
  • Page 17 H. TWO HOURS BEFORE DEL IVERY H01. Place the Quick Guide booklets in the glovebox. Check that the Owner's Manual Portfolio contains the Owner's Manuals and place in trunk. H02. Fill up fuel tank. H03. Wash and clean vehicle. Detail starts on page 88. LX570...
  • Page 18 MEMO BEFORE STARTING PRE-DERLIVERY SERVIC7 - THIS PAGE INTENTIONALLY LEFT BLANK - LX570...

  • Page 19: Inspection Details

    INSPECTION DETAIL III. INSPECTION DETAILS LX570...

  • Page 20: Vehicle Exterior

    ) Front and rear bumpers b ) Window moldings (front, side and rear) c ) Lexus emblems (front and rear) d ) Outside rear view mirrors e ) Headlights, turn signal lights, side mark- er lights, fog lights and tail light lenses...
  • Page 21 ) Check that the back door closes auto- matically to the full-closed position. c ) Check that the power back door system switches on and off by operating the “PWR DOOR OFF” switch. 08LXIIIA005I * Optional equipment LX570...

  • Page 22: Illuminated Entry

    Unlocks the door (two-step unlock function): 1. Turn the key once to unlock the driv- er's door. 2. Turn the key twice to unlock all the doors. Opens the windows and moon roof. 08LXIIIA003I (Turn and hold) * Optional equipment LX570...

  • Page 23: Smartaccess

    Check that the door unlocks. NOTE: 08LXIIIA007I The doors cannot be unlocked for 3 sec- onds after the doors are locked. d ) Check that the back door is unlocked by pushing the back door button. LX570...
  • Page 24 ) Opening the windows and moon roof Push the "UNLOCK" button until the windows and moon roof start moving. When the button is released, they stop opening. NOTE: When all the windows and the moon roof start to open, one beep sounds. * Optional equipment LX570...

  • Page 25: Theft Deterrent System

    (sounding of the horn, blinking of the headlights, tail lights and emer- gency flasher, lighting up interior light). d ) Cancel the system by unlocking doors with the smart access system, wireless remote control or mechanical key. * Optional equipment LX570...

  • Page 26: Exterior Lights

    High-mounted Brake Light (when brake pedal is depressed) h ) Back-up lights (when shift lever is placed in "R" position with the engine switch in "IG-ON" mode) Back-up Lights Side Marker Light License Plate Lights Turn Signal Light 08LXIIIA010I LX570...

  • Page 27: Vehicle Interior

    45 - 48 B15,B16 Windshield Wipers/Washer Switch and Rear Window Wiper/ Washer Switch ˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ Tire Pressure Warning Reset Switch˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ Engine Hood Release Lever˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ Fuel Filler Door Opener˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ Driving Position Memory Switches˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ Window Lock Switch˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ Door Lock Switch˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ Power Window Switches˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ LX570...
  • Page 28 INSPECTION DETAILS - B. Vehicle Interior Without Navigation System With Navigation System 08LXIIIB002I Item Page Touch Screen˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ Navigation System*˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ Rear Window and Outside Rear View Mirror Defoggers˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ Air Conditioning System˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ Clock˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ Emergency Flasher Switch˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ Audio System˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ * Optional equipment LX570...
  • Page 29 INSPECTION DETAILS - B. Vehicle Interior With Dynamic Radar Cruise Control Without Dynamic Radar Cruise Control 08LXIIIB003I Item Page Audio Remote Control Switches˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ DISP Switch˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ Distance Switch˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ Cruise Control Switch˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ LX570...
  • Page 30 INSPECTION DETAILS - B. Vehicle Interior 08LXIIIB004I Item Page VIEW Switch*˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ Intuitive Parking Assist-Sensor Switch*˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ Engine Switch˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ Center Differential Lock/unlock Switch˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ RSCA (Roll Sensing of Curtain shield Airbag) OFF Switch˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ Power Back Door OFF Switch*˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ VSC OFF Switch˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ * Optional equipment LX570...
  • Page 31 Power Back Door Switch*˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ NOTE: Inspect interior parts after removing the necessary factory interior protective covering. To prevent the battery from being discharged, the engine should be running when the electrical control switches are turned on. * Optional equipment LX570...

  • Page 32: Power Supply Changeover

    Power supply mode is in the "OFF" mode. c ) In each mode, check that the power sup- ply has changed properly. NOTE: If the engine switch illuminator blinks in am- ber, refer to the Repair Manual. 08LXIIIB006I LX570...

  • Page 33: Immobilizer System

    Check seat belts operation. a ) Check that each belt extends and re- tracts smoothly. Fastenig b ) Check that the belt lengths are not twist- c ) Check that the buckles lock securely and Releasing release smoothly. 08LXIIIB009I LX570...

  • Page 34: Seat Adjustments

    Check that the seats slide smoothly, recline properly and lock securely in any position. a ) Front Seats Seat slide adjustment Seatback angle adjustment Seat cushion angle adjustment Vertical height adjustment Lumbar support adjustment Seat cushion length adjustment Head restraints adjustment 08LXIIIB012I LX570...
  • Page 35 ) Second Seats Seatback angle adjustment Seat position adjustment Head restraints adjustment 08LXIIIB013I Tumble Folds 08LXIIIB044I Tumbling Instructions 1. Before tumbling (1) Stow the seat belt buckles and lower the head restraints to the lowest po- sition. 08LXIIIB014I LX570...
  • Page 36 (1) Fold down the seatback while pulling the seatback angle adjustment lever, and swing the whole seat up and for- ward. 08LXIIIB016I (2) Hook the holding strap to the assist grip and secure the seat by pulling its free end. 08LXIIIB017I LX570...
  • Page 37 INSPECTION DETAILS - B. Vehicle Interior c ) Third Seats Seatback angle adjustment 08LXIIIB018I Tumble Folds 08LXIIIB046I LX570...
  • Page 38 Third Seat Tumbling Switch Third Seat Table Mode Switch Third Seat Lock Release Lever 08LXIIIB019I Folding and Tumbling Instructions 1. Before folding (1) Stow the seat belt buckles. 08LXIIIB020I (2) Stow the center head restraint in the seatback. 08LXIIIB021I LX570...
  • Page 39 • To release the hooked tab, insert the mechanical key into the hole on the buckle with the light gray buckle re- lease button. 08LXIIIB024I • Stow the seat belt tabs as shown. 08LXIIIB023I LX570...
  • Page 40 3. Tumbling (1) If the switch is pressed and held, the seat will automatically fold and lift sideward. NOTE: For the automatic type, the buzzer Automatic Type sounds twice when the seat is about to lift. Manual Type 08LXIIIB026I LX570...
  • Page 41 08LXIIIB029I (2) When the switch is held down, the seat will automatically return to the folding position. (For the automatic type, the buzzer sounds twice) 08LXIIIB030I LX570...
  • Page 42 The seatback striker will be automat- ically stowed when the seat is low- ered. (Manual type only) 08LXIIIB031I 5. Pull the handle and raise the seat- backs. 08LXIIIB032I 6. Raise the headrests. 08LXIIIB033I LX570...

  • Page 43: Tilt And Telescopic Steering Wheel

    • When the engine switch is switched to the "OFF" mode, the steering column moves forward away from the driver and also tilts • When the engine switch is switched to the “ACC“ or "IG-ON" mode, the steering col- umn returns to the previously set position. 08LXIIIB035I LX570...

  • Page 44: Outside Rearview Mirrors

    • The doors are unlocked with power door lock switch on the driver's side. • The shift lever is moved out of the "P" position. NOTE: Check that the outer foot lights illuminate for 15 seconds and then go off. 08LXIIIB038I LX570...
  • Page 45 2. Check the driver’s door is unlocked using the entry function or wireless re- mote control, the driver’s door is opened, and the stored driving posi- tion is recalled. 08LXIIIB041I * Optional equipment LX570...

  • Page 46: Door Locks

    "ACC" or "OFF" mode. 08LXIIIB043I NOTE: This feature is canceled after 45 sec- onds or if either front door is opened. B11. CHECK FUEL FILLER DOOR OPENER Check operation of the fuel filler door opener. 08LXIIIB045I LX570...

  • Page 47: Headlight Indicator Light

    ) Check that the high beam indicator light illuminates when the high beams are on. With the headlights on, push the lever forward to turn on the high beams. Pull the lever toward you to turn on the high beams. 08LXIIIB049I LX570...

  • Page 48: Emergency Flasher

    ) Check that the horn sounds when the horn button is pressed. Darker Brighter 08LXIIIB051I h ) Check that the front fog lights are on when front fog light switch is on with the headlights on. 08LXIIIB056I LX570...
  • Page 49 Intermittent window wiper operation Normal window wiper operation Washer operation Washer/wiper dual operation c ) The wiper should not make any abnor- mal noise when operating. NOTE: Add washer fluid up to the proper level. 08LXIIIB054I LX570...
  • Page 50 • PCS (Pre-Collision System) warning light • AFS (Adaptive Front-lighting System) OFF Indicator Light • Brake system warning light • Charging system warning light • Malfunction indicator lamp Refer to "Warning Lights and Buzzers" on page 46 for details. * Optional equipment LX570...
  • Page 52 "P" position: The transmission will disengage and the wheels 08LXIIIB072I will not lock. Low Fuel Level Warning Indicates the fuel level is low. (Apploxi- Light mately 15L [4.0 gal., 3.3 lmp. gal.]) 08LXIIIB073I LX570...

  • Page 53: Multi-Information Display

    ) Open any doors and back door, and check that the opening condition is dis- played by graphic information. NOTE: Refer to the multi-information display sec- tion in the vehicle's Owner's Manual for a comprehensive list of the system's functions and displays. LX570...

  • Page 54: Navigation System

    "MENU", "MAP/VOICE" or "DEST" but- tons and check that the display changes according to the pressed button. c ) XM NavWeather This service is active on all new Lexus vehicles with navigation systems. To confirm activation, press the "MENU" button, select "Info.Phone" then select "XM NavWeather".

  • Page 55: Heater

    ) Press the "OFF" button. o ) Turn on the rear window defogger switch and check that the indicator light illumi- nates. p ) Turn the pollen removal mode switch and check that the indicator light illumi- nates. LX570...

  • Page 56: Climate Control Seats

    2. Then turn the switch off and check that the indicator light goes off. Press the knob to turn the system on. Turn the knob to the desired temper- ature setting. 08LXIIIB079I * Optional equipment LX570...
  • Page 57 2. Then turn the switch off and check that the indicator light goes off. For left second seat For right second seat High heating temperature 08LXIIIB081I Low heating temperature * Optional equipment LX570...

  • Page 58: Audio System

    Radio mode: Selects radio stations CD mode: Selects tracks, files (MP3 and WMA) and discs DVD mode (DVD player only): Selects tracks, chapters and discs Sound library mode (DVD player only): Selects tracks, albums, artists and genres. LX570...

  • Page 59: Rear Seat Entertainment System

    ) Press the “OPEN/CLOSE” button again and check that the display closes. 08LXIIIB085I • Insert the headphone into the headphone jack, and then check for smooth operation of the following controls: Headphone jack Volume knob 08LXIIIB086I * Optional equipment LX570...
  • Page 60 "R" position. 08LXIIIB088I b ) Pole stoods at point as illustrated and Pole Pole gradually approaches the vehicle. About 60 cm (23.6 in., 2.0 ft.) About 100 cm (39.4 in., 3.3 ft.) Pole Pole Pole Pole 08LXIIIB089I * Optional equipment LX570...
  • Page 61 B23. CHECK REAR VIEW MONI- TOR SYSTEM* When the engine switch is in the "IG-ON" mode and the shift lever is shifted in the "R" position, check that the rear view is dis- played on the screen. 08LXIIIB091I * Optional equipment LX570...

  • Page 62: Clock

    To adjust the time to the nearest hour, touch ”:00”. d ) Turn daylight saving time on. e ) Turn daylight saving time off. f ) After setting, touch “OK“. With navigation system: Refer to Navigation System Owner’s Manu- 08LXIIIB094I * Optional equipment LX570...

  • Page 63: Ashtray(S)

    ) With the engine switch in the “IG-ON“ mode, press the power outlet main switch and check that the indicator light illuminates. Check the power outlet (AC 115V) in the luggage compartment using an electrical accessory designed for this use. 08LXIIIB097I LX570...

  • Page 64: Cool Box

    NOTE: When the cool box is on, the indicator light comes on and the front air conditioning sys- tem is activated. (The air conditioning sys- tem cannot be turned off.) 08LXIIIB100I * Optional equipment LX570...

  • Page 65: Center Armrests

    Front personal lights Front and rear No.1 interior lights Rear personal lights Rear No.2 interior lights Shift lever lighting Inside door handle light Door courtesy lighting 08LXIIIA011I Engine switch lighting Footwell lighting Luggage compartment light Outer foot lights Running board lights LX570...

  • Page 66: Moon Roof

    ) Check that the moon roof can be fully op- erated after the engine switch has been switced to the "ACC" or "OFF" mode. NOTE: However, it can not be oprated after 45 08LXIIIB105I seconds or if either front door is opened. LX570...

  • Page 67: Inside Rearview Mirror

    ) Check that the sun visors are easy to use in the following operations: Flip down Unhook and swing to the side Place in side position, and slide back- ward 08LXIIIB108I b ) Open the cover and check that the vanity light comes on. 08LXIIIB109I LX570...

  • Page 68: Homelink Garage Door Opener

    B35. CHECK ON-BOARD DIAG- NOSTIC SYSTEM OPERA- TION Using the “Techstream”, check the on-board diagnostic system function. For details of this procedure, refer to the en- gine troubleshooting section of the Repair Manual. LX570...

  • Page 69: Luggage Compartment

    C01. CHECK TOOLS, JACK AND JACK HANDLE Check that the tools, jack and jack handle are properly installed. 08LXIIIC001I 08LXIIIC002I C02. CHECK MANUAL BACK DOOR OPENER Check for proper operation of the manual back door opener located on the back door. 08LXIIIC003I LX570...
  • Page 70 INSPECTION DETAILS - C. Luggage Compartment C03. CHECK TRIM APPEARNCE AND LUGGAGE CARPET FIT Inspect the luggage trim, luggage installa- tion and appearance. 08LXIIIC004I LX570...

  • Page 71: Under The Hood

    Power Steering Fluid Reservoir˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ Engine Oil Level Dipstick˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ Engine Oil Filler Cap˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ Brake Fluid Reservoir˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ Fuse Box˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ Washer Fluid Tank˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ Battery˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ Cooling Fan˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ Condenser˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ Radiator˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ Engine Coolant Reservoir˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜˜ NOTE: Install protective fender covers prior to beginning the under hood inspection. LX570...

  • Page 72: Engine Oil Level

    The level should be between the two marks. Full b ) Check for dirt or impurities in the oil. 08LXIIID003I NOTICE: If the oil level is too low, add specified en- gine oil and check for oil leaks. LX570...

  • Page 73: Brake Fluid Level

    ) If the fluid temperature is low (10 - [50 - 85 F]), the reading should be in the “cold“ range. If the fulid level is low, replenish with auto- £ matic transmission fluid DEXRON II or III. LX570...

  • Page 74: Coolant Level

    12.6 V or less, Wait 60 seconds or more to remove the sur- recharge the battery. face charge. 08LXIIID009I If the engine was running before measuring the voltage, wait 20 minutes or more after the engine stops to remove the surface charge. LX570...
  • Page 75 Then, check that the electric cooling fans turn on and rotate smoothly. CAUTION: The electric cooling fan are controlled de- pending on air conditioning refrigerant pres- sure. Do not touch the fans when the “A/C” switch is turned on. LX570...

  • Page 76: Fluid Leaks

    ) Power steering lines and hoses d ) Brake lines and hoses e ) Radiator and hoses f ) Fuel lines and hoses D13. CHECK HEADLIGHT AIM If headlight aim not correct, see Repair Manual for headlight aim procedure. LX570...

  • Page 77: Under Vehicle (On Hoist)

    Torque specifications: 131N-m (13.4 kgf-m, 97 ft-lbf) 08LXIIIE001I E02. ACTIVATION AND INITIAL- IZATION OF TIRE PRES- SURE WARNING SYSTEM Refer to the Service Bulletin LX570...

  • Page 78: Wheel Center Caps

    INSPECTION DETAILS - E. Under Vehicle (ON Hoist) E03. CHECK TIRES Visually inspect all tires for damage and/or defects. E04. INSTALL WHEEL CENTER CAPS Install the wheel center caps on the wheels. 08LXIIIE008I LX570...
  • Page 79 Visually inspect rotors for rust. NOTE: For the best rotor rust prevention, retain wheel film on vehicle until just prior to cus- tomer delivery. E06. VISUALLY CHECK TRANSFER CASE AND DIFFERENTIAL FOR LEAKS If leakage is found, see Repair Manual. LX570...
  • Page 80 ) Visually check the following components for fluid leakage: • Engine • Transmission • Front axle • Transfer • Steering gear • Brake lines • Fuel lines • Rear axle c ) Visually check the entire underside of the body for proper rust-resistant coating. LX570...

  • Page 81: Chassis Bolts

    Repair Manual for proper bolt torque specifi- Rear cation. a ) Front and rear suspensions b ) Steering linkages c ) Propeller shaft d ) Front/rear cross members e ) Front/rear brakes f ) Drive shaft Front Propeller Shaft Transfer Rear Propeller Shaft Transfer 08LXIIIE014IY LX570...

  • Page 82: Exhaust System

    INSPECTION DETAILS - E. Under Vehicle (ON Hoist) E09. CHECK EXHAUST SYSTEM Visually check for leaks and damage to the exhaust pipes and mufflers. Ensure they are properly installed. 08LXIIIE009Y E10. INSTALL TOWING WIRE HARNESS CONNECTOR Refer to the Service Bulletin LX570...

  • Page 83: Road Test

    A comprehensive road test is vital in order to ensure that a perfect automobile is deliv- ered to a Lexus customer. We recommend that you map out a specific road test course that includes a variety of road conditions including stop and go, highway speed and rough road surfaces.
  • Page 84 "S" range. Check that the transmission shifts up when the shift lever is moved toward the front. Check that the transmission shifts down when the shift lever is moved to- ward the back. LX570...
  • Page 85 "L4" position. “H4“ (high speed position) 08LXIIIF007I “L4“ (low speed position) b ) Center differential lock/unlock switch Check that the indicator lights and multi- information display come on when the switch is pressed. 08LXIIIF008I LX570...

  • Page 86: Crawl Control

    "Lo (low) height mode" when the height Lower select switch is moved up and down. Also, check that the multi-information display switches to the "OFF mode" when the height control OFF switch is pressed. Current mode Height up Height down Height control “OFF“ indicator 08LXIIIF010I LX570...

  • Page 87: Active Trac

    Check that the indicator light comes on when the switch is pressed once. 08LXIIIF012I b ) Active TRAC and VSC stop operating Check that the indicator light and multi- information display come on when the switch is pressed and held more than 3 seconds. 08LXIIIF013I LX570...

  • Page 88: Cruise Control

    ) Check that the preset speed is canceled • Depressing the brake pedal • Shifting the shift lever to "N" position • Using cancel switch and “ON-OFF" button For details regarding the operation of the cruise control, refer to the Owner's Man- ual. 08LXIIIF015I LX570...

  • Page 89: Dynamic Radar Cruise Control

    OR VIBRATION Check for vibration or abnormal noise while the vehicle is in motion. a ) Wind noise b ) Power train (engine, transmission, differ- ential, propeller shaft) c ) Road noise (tires) d ) Others * Optional equipment LX570...
  • Page 90 INSPECTION DETAILS - F. Road Test F16. CHECK SQUEAKS AND RAT- TLES Check for squeaks and rattles in the follow- ings: a ) Instrument panel b ) Doors c ) Trim d ) Body e ) Others LX570...

  • Page 91: Final Inspection

    It is recommended that the interior protec- 08LXII002I tive covers be removed just before delivery of the vehicle to the customer. NOTE: If the interior color is light white for some ve- hicle, plastic cover will be set for front, center and roof side garnishes. LX570...

  • Page 92: Vehicle Delivery Certificate

    Peel VIN number sticker off sticker sheet and apply to “Vehicle Identification Number” line at inside top of certificate. The person performing PDS is required to sign their name over “Dealership Representative” line and return certificate and VIN sticker sheet to glovebox. LX570...

  • Page 93: Two Hours Before Delivery

    It is recommended that you wash the vehicle by hand. If mechanical brushes are used in an "automatic car wash", the brushes may scratch the paint surface. Battery Maintenance for In-Stock Vehicles & Pre-Delivery, see TSIB Floor Mat Installation - see TSIB LX570...

Table of Contents
