Garmin GMI 20 Installation Instructions

GMI ™ 20 Installation Instructions
To obtain the best possible performance, install this marine
instrument according to these instructions. If you experience
difficulty during the installation, contact Garmin
Support, or seek the advice of a professional installer.
This instrument communicates with NMEA 2000
devices, and shows information such as speed, heading, water
depth, and fuel information when connected to the appropriate
sensors. The instrument can also communicate with a NMEA
0183 device using an optional data cable.

Important Safety Information

See the Important Safety and Product Information guide in the
product box for product warnings and other important
information.
Always wear safety goggles, ear protection, and a dust mask
when drilling, cutting, or sanding.
When drilling or cutting, always check what is on the opposite
side of the surface.
Registering Your Device
Help us better support you by completing our online registration
today. Keep the original sales receipt, or a photocopy, in a safe
place.
1
Go to my.garmin.com/registration.
2
Sign in to your Garmin account.
Contacting Garmin Support
• Go to support.garmin.com
product manuals, frequently asked questions, videos, and
customer support.
• In the USA, call 913-397-8200 or 1-800-800-1020.
• In the UK, call 0808 238 0000.
• In Europe, call +44 (0) 870 850 1241.

Mounting Considerations

This device should be mounted in a location that is not exposed
to extreme temperatures or conditions. The temperature range
for this device is listed in the product specifications. Extended
exposure to temperatures exceeding the specified temperature
range, in storage or operating conditions, may cause device
failure. Extreme-temperature-induced damage and related
consequences are not covered by the warranty.
The mounting surface must be flat to avoid damaging the device
when it is mounted.
Using the included hardware and template, you can flush mount
the device in the dashboard. If you want to mount the device
using an alternative method where it appears flat with the front
of the dashboard, you must purchase a flat-mount kit
(professional installation recommended) from your Garmin
dealer.
When selecting a mounting location, observe these
considerations.
• The mounting location should be at or below eye level to
provide optimal viewing as you operate your vessel.
® Product
® sensors and
WARNING
CAUTION
NOTICE
for help and information, such as
NOTICE
• The mounting location should allow easy access to the keys
on the device.
• The mounting surface must be strong enough to support the
weight of the device and protect it from excessive vibration or
shock.
• To avoid interference with a magnetic compass, the device
should not be installed closer to a compass than the
compass-safe distance value listed in the product
specifications.
• The area behind the mounting surface must allow room for
the routing and connection of the cables.

Mounting the Device

®
If you are mounting the device in fiberglass, when drilling the
pilot holes, it is recommended to use a countersink bit to drill a
clearance counterbore through only the top gel-coat layer. This
will help to avoid cracking in the gel-coat layer when the screws
are tightened.
Stainless-steel screws may bind when screwed into fiberglass
and overtightened. It is recommended to apply an anti-seize
lubricant on the screws before installing them.
The included template and hardware can be used to flush mount
the device in your dashboard. To mount the device so the
screen is flat with the dashboard, you must purchase a flat-
mount kit from your Garmin dealer.
1
Trim the flush-mount template and ensure it will fit in the
location where you plan to mount the marine instrument.
The flush-mount template is included in the product box.
2
Remove the liner from the adhesive on the back of the
template and apply it to the location where you plan to mount
the marine instrument.
3
If you plan to cut the hole with a jigsaw instead of a 90 mm
(3.5 in.) hole saw, use a 10 mm (
hole to begin cutting the mounting surface.
4
Using the jigsaw or the 90 mm (3.5 in.) hole saw, cut the
mounting surface along the inside of the dashed line
indicated on the flush-mount template.
5
If necessary, use a file and sandpaper to refine the size of
the hole.
6
Place the marine instrument into the cutout to confirm that
the mounting holes on the template are in the correct
locations.
7
If the mounting holes are not correct, mark the correct
locations of the mounting holes.
8
Remove the marine instrument from the cutout.
9
Drill the 2.8 mm (
If you are mounting the marine instrument in fiberglass, use a
countersink bit as advised in the notice.
10
Remove the remainder of the template.
11
Place the included gasket on the back of the device and
apply marine sealant around the gasket to prevent leakage
behind the dashboard.
12
If you will not have access to the back of the device after you
mount it, connect all necessary cables to the device before
placing it into the cutout.
NOTE: To prevent corrosion of the metal contacts, cover
unused connectors with the attached weather caps.
13 Place the marine instrument into the cutout.
14
Securely fasten the marine instrument to the mounting
surface using the supplied screws.
If you are mounting the marine instrument in fiberglass, use a
anti-galling lubricant as advised in the notice.
15
Snap the bezel
NOTICE
3
/ in.) drill bit to drill a pilot
8
7
/ in.) pilot holes.
64
into place.
190-01609-02_0B
October 2017
