Samsung SBH100 User Manual

Stereo bluetooth headset
Hide thumbs Also See for SBH100:
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading

Related Manuals for Samsung SBH100

Summary of Contents for Samsung SBH100

  • Page 2 English ......... . Français .

  • Page 3: Table Of Contents

    English » Getting started 1. Unpacking ..........3 2.
  • Page 4 Thank you Thank you for purchasing the Samsung Stereo Bluetooth Headset SBH100, we hope you will be delighted with its operation. Please read the instruction manual to get started and to make best use of the headset’s many features. Drive safely Using a mobile phone while driving creates a distraction to the driver which may increase the likelihood of an accident.

  • Page 5: Getting Started

    Getting Started Explains what to remember for a proper use of your Bluetooth headset. Unpacking Carrying Case Charger Stereo Headset User Manual Headset Overview » Left Microphone Talk Button Volume Up Button Volume Down Button Charger Indicator Light Connector Play/Pause/Stop Button On/Off Button FF Button...

  • Page 6: Button Functions

    Button Functions Talk Button Makes/Answers Press the button to make or answer a call a call Press and hold to reject an incoming call. - Available only when your headset and phone are connected using the Hands-free Bluetooth profile and your phone supports this function. Press and hold to activate voice dialing in standby mode.
  • Page 7 Volume Up/Down Button Press to adjust the speaker volume while the music is on. Press to adjust the speaker volume during a phone call. Press and hold to switch call to the phone Switching an active during a call. call from the headset - Available only when your headset and the phone to the phone are connected as Hands-free Bluetooth profile.

  • Page 8: Charging The Battery

    If press these buttons together Press several buttons together to activate these functions. Gets ready for pairing. (Switch on) Red light is flashing to notify the remained battery amount. (While turned on) - Flashes once : Approx. 5~20% charged Press and hold (FF) + - Flashes twice : Approx.
  • Page 9 – Disconnect the charger from the power source or the headset after completing the charging. - Use only Samsung-approved charger. Unauthorized charger may cause an explosion or damage on the headset. - Always try to keep the battery at room temperature (0 ~ +40°C).
  • Page 10 When the battery charge falls low > Warning sound beeps and the red indicator light flashes every 10 seconds. > If the warning sound beeps, switch the call from the headset to the phone. > If the warning sound beeps, the headset will be automatically turned off.

  • Page 11: Putting On The Headset

    Putting on the headset Check the RIGHT/LEFT sign at the bottom of the ear-hook to put on the headset properly. Slide the headset onto your ear Grip the headset body and while opening wide the ear-hook jostle it to back of the ear for to be easy to wear on.

  • Page 12: Before Using Your Headset

    Before using your headset Explains the basic operation and set-ups of your Bluetooth headset. Turning the headset On or Off > Push the On/Off Button to turn the headset on. > Push the On/Off Button to turn the headset off. If the headset is ready to be paired, the blue indicator light flashes per second.
  • Page 13 2. Prepare your phone according to the phone’s user manual on Pairing. 3. Your phone will find “Samsung Stereo Headset” and ask if you want to pair with it. Confirm this by selecting “Yes” or “OK”. 4. Enter passkey or PIN = 0000(4zeros).

  • Page 14: Connecting The Paired Headset To The Phone

    Connecting the paired headset to the phone If two Bluetooth Devices are disconnected by being turned off, you need to reconnect them. When you reconnect a paired headset, you are not asked for its passkey. 1. Turn on the headset. - The blue indicator light will flash per second if the headset is ready to be paired.

  • Page 15: Using The Headset

    Using the headset Explains how to use the various functions such as making/answering a call, menus that you can use while the call is in progress, and listening to music that SBH100 provides. Making and answering a call Making a call >...
  • Page 16 Answering a call > Press if the phone rings. - Press once again to hang up the phone. Redialing the last dialed number > Press to check the latest call numbers list. > Press once again to make a call to the last dialed number. - The headset can make a call to the last dialed number by pressing once depending on the types of the phone.

  • Page 17: Rejecting A Call

    Rejecting a call > Press and hold if a call comes in. - Available only when your headset and the phone are connected as Hands-free Bluetooth profile, and the phone supports the incoming call rejecting function. Switching the call between phone and headset >...

  • Page 18: Adjusting The Speaker Volume

    Adjusting the speaker volume > Press to adjust the speaker volume while talking. > Press to adjust the speaker volume while listening to music. Activating Call-Waiting function Press and hold to activate Call-Waiting while talking on the headset. - Call-Waiting is a feature that allows a user to be notified of another incoming call while a call is already in progress, and give the user the ability to answer the second call while the first call remains on hold.

  • Page 19: Listening To Music

    Listening to music Settings to play MP3 files may differ depending on your Bluetooth phone. So please make sure that you make proper setting for MP3 playback on your phone by following the phone’s user guide. Listening to music > Press while being connected to your Bluetooth phone.

  • Page 20: Answering A Call While Listening To Music

    Pausing music > Press while listening to music. > Press again to listen to the track from the paused part. Listening to the previous/next track > Press while music is on. Rewinding/Fast Forwarding > Press and hold while music is on. Answering a call while listening to music.
  • Page 21 Making a call while listening to music > Press and hold to stop the music. > Press to check the latest call numbers list. > Press once again to make a call to the last dialed number. - The headset can make a call to the last dialed number without showing the latest call number list by pressing once depending on the types of the phone.

  • Page 22: Care And Maintenance

    - Be careful for the headset not to be scratched nor cracked by applying excessive force or giving damage. - Always store the Samsung SBH100 with power off and safely protected. - Avoid storage at high temperatures (above 60°C / 134 °F)- such as in a hot vehicle or in direct sunlight.

  • Page 23: Frequently Asked Questions

    Frequently asked questions 1. How far away from my phone will my Samsung SBH100 work? The operating range is typically up to 30 feet (10 metres). 2. Will Samsung SBH100 work with my cordless phone at home? Samsung SBH100 is not designed for use with cordless phones.
  • Page 24 *.wav, * .wma and *.avi other than MP3 files. Make sure that you have the right file format (*.mp3) for your music files. 12. How do I take care of Samsung SBH100? To clean the headset, use a clean, soft cloth that is slightly damp.

  • Page 25: Certification And Safety Approvals

    Certification and safety approvals Declaration of Conformity (R&TTE) • For the following product : Samsung Bluetooth Headset SBH100 • Manufactured at : Youngbo Engineering Inc. Daeho B/D 7th 1462-7, Seocho3-Dong Seocho-Gu, Seoul South Korea to which this declaration relates, is in conformity with the following standards and/or other normative documents.
  • Page 26 The device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. Users are not permitted to make changes or modify the device in any way. Changes or modifications not expressly approved by Samsung will void the user’s authority to operate the equipment.

  • Page 27: Warranty And Parts Replacement

    Warranty and parts replacement Samsung warrants this product as free of defects in material, design and workmanship for the period of one year from the original date of purchase. If during the period of warranty this product proves defective under normal use and service you should return the product to the retailer from whom it was originally purchased or qualified service center.

  • Page 28: Correct Disposal Of This Product

    It must be returned to the purchase point, factory or authorised service agency for all such work • Samsung will not assume any responsibility for any loss or damage incurred in shipping. All repair work on Samsung products by unauthorised third parties voids any warranty Correct Disposal of This Product (Waste Electrical &...

  • Page 29: Glossary

    Glossary Bluetooth is a radio technology developed to connect devices, such as mobile phones and headsets, without wires or cords over a short distance of approximately 10 metres. More information is available at www.bluetooth.com Bluetooth profiles are protocols through which Bluetooth devices communicate with other devices.

  • Page 30: Specification

    Specification Bluetooth version Version 1.2 Advanced audio distribution profile, A/V Remote Bluetooth profile support control profile, Headset profile, Hands-free profile. Frequency Range 2.402 ~2.480 GHz Power consumption for 0.25~2.5 mW transmission Bluetooth-available 10 m distance Dimensions 49mm(W)*24mm(H)*64mm(D) Weight Operating Temperature 0~40°C Range Typical Standby Time...
