VR1600v
(NBN FTTC, NBN HFC & NBN Fixed Wireless)
Windows 10
IMPORTANT MESSAGE
Your modem has already been pre-configured, you do not need to follow each step of the set-up guide but should retain
this document in case you need to manually configure your equipment.
To configure your PC/Laptop with your wireless password including changing your wireless password, please
proceed to step 4.
Contents
1. Physical Connection
2. Network Configuration
1. PHYSICAL CONNECTION
Have your modem powered on and connected directly to your PC via Ethernet Cable before you begin, as these
instructions are based on wired Ethernet connection
For further information, please see wiring diagram and instructions for your NBN connection type below
•
NBN Fibre To The Curb (FTTC)
•
NBN Fixed Wireless
•
NBN Cable Broadband (HFC)
2. NETWORK CONFIGURATION
PPPoE connection does not require you to have an IP address or DNS settings manually encoded on your network card.
PPPoE connection uses authentication to establish the Internet connection and once connected your modem will be
assigned an IP and DNS settings from TPG.
To begin, your PC needs to receive a private IP address from the modem. Most modems have DHCP enabled by default
that will take care of this.
VR1600v
1
Advertisement
Related Manuals for TP-Link Archer VR1600v
Summary of Contents for TP-Link Archer VR1600v
- Page 1 Modem Configuration Guide VR1600v VR1600v (NBN FTTC, NBN HFC & NBN Fixed Wireless) Windows 10 IMPORTANT MESSAGE Your modem has already been pre-configured, you do not need to follow each step of the set-up guide but should retain this document in case you need to manually configure your equipment. To configure your PC/Laptop with your wireless password including changing your wireless password, please proceed to step 4.
- Page 2 Modem Configuration Guide VR1600v To ensure your Network Card is ready for this, please follow the following steps: A. Click Start -> Settings -> Network and Internet -> Ethernet -> Change adapter options B. Right click on Ethernet, and then click Properties C.
- Page 3 Modem Configuration Guide VR1600v 3. CONFIGURING MODEM A. Open your browser and in the address bar type http://192.168.1.1 and press Enter B. Enter admin for both the username and password and click Login. If you have changed the login credentials, please enter the current username and password for your modem interface.
- Page 4 Modem Configuration Guide VR1600v E. Enter your TPG Username and Password. Click Save F. Click the Basic tab. G. On the menu on the left side of the page, click Wireless. H. You can change your Wi-Fi details or keep the default settings.
- Page 5 Modem Configuration Guide VR1600v 4. CONFIGURING WIRELESS To use Wireless, ensure that you already have set up your wireless adapter. A. Click Start -> Settings -> Network and Internet B. Click Wi-Fi and then find the SSID (Network name) of your modem.
