- Page 1 43-637.fm Page 1 Friday, August 13, 1999 10:45 AM Cat. No. 43-637 OWNER’S MANUAL Please read before using this equipment. ET–148 20-Number Memory Speakerphone with Privacy...
- Page 2 43-637.fm Page 2 Friday, August 13, 1999 10:45 AM FEATURES Your RadioShack ET-148 20-Number Memory Speakerphone with Privacy is designed to exacting standards that en- sure reliability, long life, and outstanding performance. Its features include: 20-Number Memory Dialing — lets you store up to 15 digits in each of 20 memory locations for easy dialing.
-
Page 3: Fcc Statement
43-637.fm Page 3 Friday, August 13, 1999 10:45 AM WARNING: To reduce the risk of fire or shock hazard, do not ex- pose this product to rain or mois- ture. CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN. CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER OR BACK. -
Page 4: Table Of Contents
43-637.fm Page 4 Friday, August 13, 1999 10:45 AM CONTENTS Preparation ... 5 Installing Batteries ... 5 Testing/Replacing the Batteries ... 5 Selecting a Location ... 6 Placing the Phone on a Desk Top ... 6 Mounting the Phone on a Wall ... 6 Connecting the Handset ... -
Page 5: Preparation
43-637.fm Page 5 Friday, August 13, 1999 10:45 AM PREPARATION INSTALLING BATTERIES Your telephone uses two AAA batteries (not supplied) for power to retain the numbers you store in memory. For the best performance and longest life, we recommend alkaline batteries, such as Cat. -
Page 6: Selecting A Location
43-637.fm Page 6 Friday, August 13, 1999 10:45 AM To prevent the loss of stored numbers when the batteries are removed, replace the batteries within 5 minutes. NORM/STORE BATT TEST NORM SELECTING A LOCATION You can place the phone on a desk top or table, or mount it on a telephone wall plate or directly on the wall. -
Page 7: Connecting The Handset
43-637.fm Page 7 Friday, August 13, 1999 10:45 AM 1. Press in on the side of the bracket nearest the label and lift the DESK bracket. Rotate the bracket 180 and insert it into the WALL then push it upward to secure it. 2. -
Page 8: Connecting An Optional Ac Adapter
43-637.fm Page 8 Friday, August 13, 1999 10:45 AM You might prefer a longer cord for the handset. Your local RadioShack store has a wide selection of telephone acces- sories, including longer coiled handset cords. CONNECTING AN OPTIONAL AC ADAPTER Your telephone operates from telephone line power. -
Page 9: Setting The Dialing Mode
— Reduced ringer volume. — The telephone does not ring Note: With the phone’s ringer off, you can still make calls using the ET-148. You can also receive calls if you hear an- other telephone on the same line ringing. -
Page 10: Operation
43-637.fm Page 10 Friday, August 13, 1999 10:45 AM OPERATION Make and receive calls with this phone as you would with any other phone. This section describes some of the phone’s special features. USING THE SPEAKERPHONE To make or receive a call on the speak- erphone, leave the handset in the cradle and press SPEAKER... -
Page 11: Using Pause
43-637.fm Page 11 Friday, August 13, 1999 10:45 AM Notes: • The redial memory holds up to 32 digits in the pulse mode and 31 digits in the tone mode. This means redial distance as well as local numbers. • The redial memory also holds pause entries (see “Using Pause”). -
Page 12: Memory Dialing
43-637.fm Page 12 Friday, August 13, 1999 10:45 AM MEMORY DIALING You can store up to 20 numbers in memory (15 digits each in the tone mode, 16 in the pulse mode), then dial a stored number by pressing a memory button. -
Page 13: Dialing A Memory Number
43-637.fm Page 13 Friday, August 13, 1999 10:45 AM Notes: • If the telephone rings while you are storing numbers, you can answer the call by lifting the handset or pressing . If you answer a SPEAKER call before pressing the memory button for the number you were stor- ing, you must start again from Step 3 after the phone call. -
Page 14: Troubleshooting
43-637.fm Page 14 Friday, August 13, 1999 10:45 AM TROUBLESHOOTING We do not expect you to have any problems with your phone, but if you do, the follow- ing suggestions might help. Problem The phone does not work or works poorly. Memory does not hold pro- grammed numbers. -
Page 15: Care And Maintenance
43-637.fm Page 15 Friday, August 13, 1999 10:45 AM CARE AND MAINTENANCE Your RadioShack ET-148 20-Number Memory Speakerphone with Privacy is an ex- ample of superior design and craftsmanship. The following suggestions will help you care for your phone so you can enjoy it for years. -
Page 16: Lightning
43-637.fm Page 16 Friday, August 13, 1999 10:45 AM LIGHTNING Your telephone has built-in protection circuits to reduce the risk of damage from surg- es in telephone line and power line current. These protection circuits meet or exceed the FCC requirements. However, lightning striking the telephone or power lines can damage your telephone.
