Summary of Contents for Alto AMX-140
Page 1
Service Manual Model: AMX-140/AMX-140FX www.altoproaudio.com Version: .2...
Page 2
CONTENTS 1. Specification 2. Block Diagram 3. Schematic Diagram 4. Printed Circuit Board 5. Wiring Diagram 6. Test Procedure 7. Electrical Parts List 8. Exploded Views & Mechanical Parts List 9. Notes...
Page 3
Mono input channels Microphone input electronically balanced, discrete input configuration Frequency response 10Hz to 55kHz, + /- 3dB Distortion (THD & N) 0.005% at +4dBu, 1kHz Gain range 0dB to 44dB (MIC) SNR (Signal to Noise Ratio) 115dB Line input electronically balanced Frequency response 10Hz to 55kHz, + -3dB...
Page 12
PCB : 313123/2 Top Overlay...
Page 13
PCB : AMX-140FX Top Overlay...
Page 14
PCB : AMX-140FX Top Layer...
Page 15
PCB : AMX-140FX Bottom Overlay...
Page 16
PCB : AMX-140FX Bottom Layer...
Page 17
PCB : FX-DSP Top Overlay PCB : FX-DSP Bottom Overlay PCB : FX-DSP Top Layer PCB : AMX-100FX Bottom Layer PCB : FX-DSP Top Overlay PCB : FX-DSP Bottom Overlay...
Page 19
HA01442 row-wire connector wiring 2P 200 ├0037 NF01658 instruction AMX-140/140FX ALTO_V1.3 ├0038 NB02753 gift carton AMX-140FX ALTO ├0039 NE12193 label AMX-140FX ├0040 NI02835 handle 269*33*26mm AMX-140 black ├0041 NB02757 barrier AMX-140 ├0042 NB02756 barrier AMX-140 ├0043 NB02752 carton AMX-140;140FX ├0044 NI01594 MOUNT TH-1 ├0045...
Page 20
PF01442 AMX-140FX AMX-140FX_ALTO_230V_歐規_無 Revised:2005/8/18 Level Part No. Description Specification Reference C21,C22,C24,C25,C41,C44,C48,C49 │ ├0006 CB00042 electrolytic capacitor 47uF/63V 105℃ LZ φ8*11mm ,C91,C92 │ ├0007 CB00043 electrolytic capacitor 47uF/100V φ10*12mm C401,C402,C406,C407 │ ├0008 CB00052 electrolytic capacitor 100uF/100V φ13*21mm C405 │ ├0009 CB00056 electrolytic capacitor 220uF/25V φ8*11mm C403,C404 │...
Page 21
PF01442 AMX-140FX AMX-140FX_ALTO_230V_歐規_無 Revised:2005/8/18 Level Part No. Description Specification Reference │ ├0051 SA00127 zener diode 1/2W 47V 1N5261 │ ├0052 HA01825 wire 100 red │ ├0053 HA01828 P.V.C single wave wired UL101 230 green │ └0054 HK00826 PC board P-AMX-140FX-AI J7,J8,J9,J10,J11,J12,J13,J14,J15,J16,J17,J18 ,J19,J20,J21,J22,J23,J25,J27,J28,J29,J30,J31 ,J32,J33,J34,J35,J36,J37,J38,J39,J40,J41,J43...
Page 22
PF01442 AMX-140FX AMX-140FX_ALTO_230V_歐規_無 Revised:2005/8/18 Level Part No. Description Specification Reference C42,C63,C64,C65,C84,C85,C109,C2 01,C202,C203,C204,C205,C206,C20 7,C208,C209,C210,C211,C212,C213, C214,C215,C216,C217,C218,C219,C 220,C287,C288,C289,C290,C291,C2 │ ├0006 CI00075 SMD ceramic capacitor 0603 0.1uF/50V Y5V +80,-20% 92,C293,C294,C295,C296,C297,C29 8,C299,C300,C301,C302,C303,C304, C305,C306,C307,C308,C309,C310,C 311,C312,C313,C314,C315,C316,C3 17,C322,C324,C325,C335,C354,C35 5,C323 C1,C2,C3,C5,C6,C7,C8,C9,C10,C12, │ ├0007 CI00063 SMD ceramic capacitor 0603 470PF/50V NPO ±5﹪ C13,C37,C82 │...
Page 25
NI02249 insulate bean TW-1(TO-220) NC00005 silicone insulator TO-220 square type MG00162 screw M3*8 MG00238 copper pillar M3*6*0.5PH MG00036 screw M3*4 ME00015 nut 3m/m NI02835 handle 269*33*26mm AMX-140 black HK00821 PC board P-AMX-140FX-DIP HK00832 PC board P-FX-DSP-DIP HK01409 PC board P-313123-DIP(AMX-140FX)
Page 26
MB03078 rear board AMX-140 HI00026 power switch RA12KKATOF 2P HI00171 power switch R612KKAT0F1 NI01863 φ5.5*W10*7.5 NI02083 knob φ10.5*18mm NI02835 handle 269*33*26mm AMX-140 black NI02082 knob φ10.5*18mm NI02817 knob φ10.5*18mm NI02081 knob φ10.5*18mm NI02714 knob φ10*13.5mm NI00826 knob φ12*18mm double color...
