Technical Specification

Models
• Refer to Product Selection Guide for details
on various models
Installation
• Microsoft Windows: Software drivers for all
Windows platforms. Auto-installation of print
servers and printers in Windows
95/98/ME/NT4/2000 and TCP/IP
• NetWare: AXIS NetPilot Utility
• LAN Manager and LAN Server: AXIS Print
Utility for OS/2
• UNIX: Installation script resident in memory.
No discs or tapes required
• Macintosh: Standard installation using
Chooser
• AS/400: Automatic AS/400 configuration
supported for TN5250E and SNA 5494 CU
emulation

Network Management

• SNMP-MIB II compliant (over UDP/IP and
IPX), private enterprise MIB included
• Print server/job/printer status presentation
and management via NWAdmin/PCONSOLE
• AXIS ThinWizard and embedded web pages for
remote monitoring, configuration and
firmware upgrading
Security
• NetWare: Encrypted passwords
• NetWare Packet Signature Level 1, 2, 3.
Enables documents to be sent across the
network without risk of interception
• UNIX/Linux: Root password, user access list
and printer access
©2001 Axis Communications AB. Axis is a registered trademark, and ThinWizard is a trademark of Axis Communications AB.. The BLUETOOTH
trademarks are owned by their proprietor and used by Axis Communications AB under license. All other company names and products are
trademarks or registered trademarks of their respective companies. We reserve the right to introduce modifications without notice.

- Network Print Servers

Firmware Updates
• Flash memory allows simple, central and
remote firmware updates over the network
using FTP
• Web flash loading directly from the web
interface without use of any client software
• Safe flash loading ensures that the new
firmware is downloaded before the old
version is deleted
Auto-IP Functionality
• The print server will always receive an IP
address automatically
E-mail Notification
• E-mail notification when printer needs
assistance, e.g. out of paper or toner refill
Multi-language Support
• Web interface can be displayed in the following
languages: English, German, French or Spanish
Logical Connection
• Fast Ethernet: Supports NWay which provides
auto-detection of network speed. Use of
IEEE802.2, IEEE802.3, SNAP and Ethernet II
frame types simultaneously
• Ethernet: Use of IEEE802.2, IEEE802.3, SNAP
and Ethernet II frame types simultaneously
• Token Ring: Use of IEEE802.2, IEEE802.5
(with Early Token release support for 16
MB/sec) frame types simultaneously
Network Attachments
• Fast Ethernet: RJ-45 connector (Cat 5 twisted
pair cable) for 10baseT Ethernet or 100baseTX
Fast Ethernet
• Ethernet: 10baseT (thin) and 10baseT (twisted
pair)
• Token Ring: Media type I/DB89/STP and type
3/RJ-45/UTP. Support for 4/16 MB
Logical Printers
• The logical printer ports can be programmed
to perform auto ASCII-to-PostScript
conversion, string before and after job, string
substitution, alternative output, character set
conversion
For more information visit our web site:
Parallel Ports
• Single-port models: 36-pin Centronics
connector parallel port, high-speed IEEE 1284
compliant
• Mutli-port models: Two 25-pin DSUB parallel
ports, high-speed IEEE 1284 compliant
• For applicable models, bi-directional support
for Raw TCP, Apple and PROS
Serial Ports
• RS-232, 9-pin DSUB connector. XON/XOFF or
RTS/CTS
• Data rates up to 115,200 kbit/sec
Dimensions
• Single-port models*, typically:
Height: 1.1 in/2.5 cm
Width: 2.2 in/5.6 cm
Depth: 4.7 in/12.0 cm
Weight: 0.26 Ibs/ 0.12 kg
• Multi-port models*, typically:
Height: 1.0 in/2.7 cm
Width: 6.1 in/15.5 cm
Depth: 4.7 in/12.0 cm
Weight: 0.55 Ibs/ 0.25 kg
* varies slightly by model and connector
Environmental
• Temperature: 40-105°F (5-40°C)
Humidity: 10-95% non-condensing
Approvals
• EMC CE; EN 55022/1987, EN50082-1/1992,
FCC Class A
Safety
• EN 60950, approved power supplies for all
countries
Processor
• 32-bit RISC controller (ETRAX 100 or ETRAX 4)
Front Panel
• 2 LED indicators: Power and Network
• Push button for information printouts
www.axis.com
