CONTENTS Installation ...3 DIN Front-Mount (Method A) ...3 Installing the unit ...3 Removing the unit ...4 DIN Rear-Mount (Method B) ...4 How To Remove And Install The Front Panel ...5 Wiring Connection ...6 Operation ...7 General Operation ...7 Radio Operation...8 CD Operation ...9 Specification...10 Trouble Shooting ...11...
INSTALLATION Notes: • Choose the mounting location where the unit will not interfere with the normal driving function of the driver. • Before finally installing the unit, connect the wiring temporarily and make sure it is all connected up properly and the unit and the system work properly. •...
INSTALLATION (Fig. 2) 1. Dashboard 2. Nut (5mm) 3. Spring washer 4. Screw (5 x 25mm) 5. Screw 6. Strap Be sure to use the strap to secure the back of the unit in place. The strap can be bent by hand to the desired angle. 7.
INSTALLATION HOW TO REMOVE AND INSTALL THE FRONT PANEL 1. Press the release button and pull-off the front panel. Keep the front panel into the case. 2. To install the front panel, insert the panel into the housing and make sure the panel is properly installed, otherwise, abnormalities occurs on the display or some keys will not function properly.
WIRING CONNECTION ANTENNA CONNECTOR IGNITION SWITCH (B+) YELLOW MEMORY BACK-UP BLACK GROUND (B–) POWER ANTENNA (FOR POWER ANT. VERSION ONLY) LEFT SPEAKER MAIN UNIT BLUE WHITE WHITE/BLACK (GREY) Rch RED RCA CABLE Lch WHITE (FOR RCA LINE OUT VERSION ONLY) GREY RIGHT SPEAKER...
OPERATION COMPACT DISC PLAYER MODE GENERAL OPERATION ON/OFF Press PWR button (1) to turn on the unit. Press it again to turn it off. BALANCE Slide BAL button (2) to left or right to adjust sound balance between left and right speakers.
OPERATION RESET BUTTON RESET button (17) is placed on the housing and must be activated with either a ballpoint pen or thin metal object. The RESET button (17) is to be activated for the following reasons: • Initial installation of the unit when all wiring is completed. •...
OPERATION CD OPERATION CD OPERATION DISC PLAY DISC PLAY Gently insert a compact disc with the label side facing up into the disc slot (13). The Gently insert a compact disc with the label side facing up into the disc slot (13). The disc is then automatically loaded into the unit and starts playing with the first track of disc is then automatically loaded into the unit and starts playing with the first track of the disc.
SPECIFICATION GENERAL GENERAL Power Supply Requirements Power Supply Requirements Chassis Dimensions Chassis Dimensions Tone Controls Tone Controls - Bass (at 100 Hz) - Bass (at 100 Hz) - Treble (at 10 KHz) - Treble (at 10 KHz) Maximum Output Power Maximum Output Power Current Drain Current Drain...
TROUBLE SHOOTING Before going through the check list, check wiring connection. If any of the problems persist after check list has been made, consult your nearest service dealer. Symptom No power. The car ignition switch is not on. The fuse is blown. Disc cannot Presence of CD disc inside Remove the disc in the player, then be loaded or...
