ORDERING REPLACEMENT PARTS

To order replacement parts, contact the ICON Health & Fitness, Ltd. office, or write:
ICON Health & Fitness, Ltd.
Customer Service Department
Unit 4, Revie Road Industrial Estate
Revie Road
Beeston
Leeds, LS118JG
UK
Tel:
08457 089 009
Outside the UK: 0 (044) 113 387 7133
Fax: 0 (044) 113 387 7125
To help us assist you, please be prepared to give the following information:
• The MODEL NUMBER of the product (PFEVEL26040)
• The NAME of the product (PROFORM
®
535 SMR elliptical crosstrainer)
• The SERIAL NUMBER of the product (see the front cover of this manual)
• The KEY NUMBER and DESCRIPTION of the part(s) (see page 14)
Part No. 216020 R0904A
Printed in China © 2004 ICON IP, Inc.
Model No. PFEVEL26040
Serial No.
Serial Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete cus-
tomer satisfaction. If you have
questions, or if there are missing
or damaged parts, please call:
08457 089 009
Or write:
ICON Health & Fitness, Ltd.
Unit 4
Revie Road Industrial Estate
Revie Road, Beeston
Leeds, LS11 8JG
UK
email: csuk@iconeurope.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manu-
al for future reference.
USER'S MANUAL
Class HC Fitness Product
Visit our website at
www.iconeurope.com

Advertisement

Table of Contents
loading

Related Manuals for Pro-Form PFEVEL26040

Summary of Contents for Pro-Form PFEVEL26040

  • Page 1: Ordering Replacement Parts

    Fax: 0 (044) 113 387 7125 To help us assist you, please be prepared to give the following information: QUESTIONS? • The MODEL NUMBER of the product (PFEVEL26040) As a manufacturer, we are com- mitted to providing complete cus- • The NAME of the product (PROFORM ®...
  • Page 2 EXPLODED DRAWING—Model No. PFEVEL26040 R0904A TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............3 BEFORE YOU BEGIN .
  • Page 3 PART LIST—Model No. PFEVEL26040 R0904A IMPORTANT PRECAUTIONS Key No. Qty. Description Key No. Qty. Description WARNING: To reduce the risk of serious injury, read the following important precau- Frame Pedal Arm Bushing tions before using the elliptical crosstrainer. Upright M8 Nylon Locknut...

  • Page 4: Before You Begin

    And the unique number is PFEVEL26040. The serial number is found If your goal is to burn fat, adjust the intensity of your...

  • Page 5: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING ASSEMBLY Assembly requires two persons. Place all parts of the elliptical crosstrainer in a cleared area and remove the Inspect and tighten all parts of the elliptical crosstrainer See the drawing below and locate the Reed Switch packing materials.
  • Page 6 2. Whilst another person lifts the back of the Frame (1), The centre of measurement, hold down the On/Reset button for attach the Rear Stabiliser (28) to the Frame with two the large dis- about six seconds. When the batteries are M8 x 53mm Button Bolts (34), two M8 Washers (48), play will show replaced, it may be necessary to reselect the...
  • Page 7 5. Whilst another person holds the Upright (2) near the Frame (1), connect the Upper Wire (44) to the Sensor Make sure that Wire (53). the wires do not get pinched Push the excess wire down into the Frame (1). Slide and damaged the Upright (2) onto the Frame.

  • Page 8: How To Use The Elliptical Crosstrainer

    7. Identify the Left Pedal Arm (11). Attach a Pedal (13) to HOW TO USE THE ELLIPTICAL CROSSTRAINER the Left Pedal Arm with two M6 x 48mm Flat Head Screws (36) as shown. HOW TO EXERCISE ON THE ELLIPTICAL Attach the other Pedal to the Right Pedal Arm (not CROSSTRAINER shown) in the same way.

This manual is also suitable for:
