Summary of Contents for Pyle PLCD67
Page 1
PLCD67 OWNER’S MANUAL Mobile Audio System • PLL Synthesizer Stereo Radio • Digital Compact Disc Player • Automatically Memory Storing • Preset Equalization • Remote Control • Electronic Detachable Panel...
CONTENTS Installation ...3 DIN Front-Mount (Method A) ...3 Installing the unit ...3 Removing the unit ...4 DIN Rear-Mount (Method B) ...4 Using the Detachable Front Panel ...5 Wiring Connection ...6 Operation ...7 General Operation ...7 Radio Operation...8 CD Operation ...9 Remote Control...10 Specification...11 Trouble Shooting ...12...
INSTALLATION Notes: • Choose the mounting location where the unit will not interfere with the normal driving function of the driver. • Before finally installing the unit, connect the wiring temporarily and make sure it is all connected up properly and the unit and the system work properly.
INSTALLATION Removing the unit Open/Close 1. Before removing the frame, press the OPEN/CLOSE button to slide down the front panel. 2. Frame 3. Insert fingers into the groove in the right side of the frame and pull out to remove the frame. (You can also remove the frame from the left side.) 4.
USING THE DETACHABLE FRONT PANEL To Detach the Front Panel 1. Press the OPEN/CLOSE button, the front panel will slide down. Open/Close 2. Press the OPEN/CLOSE button again, the front panel will slide up. Open/Close 3. When the front panel slides down, press the bottom button of the front panel upward and pull it out from the panel bracket.
WIRING CONNECTION ANTENNA CONNECTOR IGNITION SWITCH (B+) YELLOW MEMORY BACK-UP CHOKE BLACK GROUND (B–) BLUE POWER ANTENNA FRONT Lch SPEAKER WHITE/BLACK REAR Lch SPEAKER GREEN/BLACK MAIN UNIT WHITE GREEN (BLACK) Rch RED CD IN Lch WHITE (GREY) Rch RED RCA CABLE Lch WHITE GREY FRONT Rch...
OPERATION GENERAL OPERATION • ON/OFF Switch on the unit by pressing any button (except OPEN/CLOSE button (7) and EJECT button (4)). When system is on, press POWER button (9) to turn off the unit. • FACEPLATE RELEASE Press OPEN/CLOSE button (7) to slide down the front panel and you can •...
OPERATION For Electrical Volume: By pressing AUDIO CONTROL button (11) or AUDIO CONTROL button (12), it is possible to adjust the desired sound quality. For Digital Rotating Volume: By rotating the knob (11 & 12) clockwise or counter-clockwise, it is possible to adjust the desired sound quality.
OPERATION retune to seek tuning mode and “AUTO” appeared on the display. • LOCAL/DISTANCE Press LOC button (3) shortly to select between local and distant stations. Local setting for reception of strong station, and a distant setting for reception of weaker stations. •...
Power Supply Requirements Chassis Dimensions Tone Controls - Bass (at 100 Hz) - Treble (at 10 KHz) Maximum Output Power Current Drain CD PLAYER Signal to Noise Ratio Channel Separation Frequency Response RADIO Frequency Coverage Sensitivity (S/N = 30 dB)
TROUBLE SHOOTING Before going through the check list, check wiring connection. If any of the problems persist after check list has been made, consult your nearest service dealer. Symptom No power. The car ignition switch is not on. The fuse is blown. Disc cannot Presence of CD disc inside Remove the disc in the player, then be loaded or...
