FCC Test Report FCC ID: ANO20030500CMR
Document Number: FCC 19-0253-0
User's Manual
(for ThinkPad X30 and X40 Series)
The attachment is the part of the user's manual of the specific host devices (IBM ThinkPad X30
and X40 Series) that indicates the regulatory notices concerning the FCC Part 15 and IC RSS-
210/102.
Due to the large volume, the notices for other countries and other regulatory issues (e.g.
Telecommunications, Safety, and EMC ) are omitted.
Prepared by T. Murota
Advertisement
Related Manuals for IBM ThinkPad X30 Series
Summary of Contents for IBM ThinkPad X30 Series
- Page 1 User’s Manual (for ThinkPad X30 and X40 Series) The attachment is the part of the user’s manual of the specific host devices (IBM ThinkPad X30 and X40 Series) that indicates the regulatory notices concerning the FCC Part 15 and IC RSS- 210/102.
- Page 2 Verwendung als drahtlose Einheit zugelassen ist. Der ThinkPad X40 muss exakt wie nachfolgend beschrieben installiert und verwendet werden. Lesen Sie unbedingt die entsprechenden Informationen in diesem Dokument, bevor Sie den ThinkPad X40 verwenden. © Copyright IBM Corp. 2003...
- Page 3 For information concerning the wireless cards announced after the publication of this notice, visit the Web site at www.ibm.com/pc/qtechinfo/MIGR-43693.html IBM 11b/g Wireless LAN Mini PCI Adapter marketed in US and Canada does not support nor function in the extended channels (12ch, 13ch).
- Page 4 PRO/Wireless LAN 2100 3B Mini PCI Adapter), v FCC ID: ANO20030400LEG, Model: PH12127E (IBM 11a/b/g Wireless LAN Mini PCI Adapter), or v FCC ID: ANO20030500CMR, Model: T60H786-U (IBM 11b/g Wireless LAN Mini PCI Adapter) TX FCC ID for an installed transmitter card...
- Page 5 If no integrated wireless LAN Mini-PCI Card or RF CDC module is preinstalled in your ThinkPad computer, you can install one, provided by IBM as an option. Plug the wireless card option into the Mini-PCI Card slot or CDC slot located under the expansion slot cover of your ThinkPad computer as...
- Page 6 Expansion slot cover Mini PCI Card slot Communication Daughter Card slot Attention: The ThinkPad X40 Series computer contains an authentication mechanism If you install an unauthorized wireless LAN Mini-PCI Card or RF CDC module that is not approved for use in the ThinkPad X40 Series computer, the computer will not start, but only displays an error message and emits beeps.
- Page 7 iii) The FCC RF safety requirement The radiated output power of the Wireless LAN Mini-PCI Cards or RF CDC module authorized to use for the ThinkPad X40 Series computer is far below the FCC radio frequency exposure limits. Nevertheless, the ThinkPad X40 Series computer shall be used in such a manner that the potential for human contact during normal operation is minimized as follows: Caution: To comply with FCC RF exposure compliance requirements, a separation distance of at least 20 cm (8 inches) must be maintained between the antenna for the integrated Wireless LAN Mini-PCI...
- Page 8 FCC ID: ANO20030400LEG, Model: PH12127E (IBM 11a/b/g Wireless LAN Mini PCI Adapter) or FCC ID: ANO20030500CMR, Model: T60H786-U (IBM 11b/g Wireless LAN Mini PCI Adapter) Diversity antenna positions Main Auxiliary 20cm 20cm Note: The transmission diversity function is implemented for the Card (FCC ID: ANO20030400LEG, Model: PH12127E (IBM 11a/b/g Wireless LAN Mini PCI Adapter) or FCC ID: ANO20030500CMR, Model: T60H786-U (IBM 11b/g Wireless LAN Mini PCI Adapter)).
- Page 9 2. When you use any other RF option device that is not listed on the IBM site, all other wireless features including the integrated transmitter in your ThinkPad computer are required to be turned off.
- Page 10 v This device is restricted to indoor use due to its operation in the 5.15 to 5.25 GHz frequency range. FCC requires this product to be used indoors for the frequency range 5.15 to 5.25 GHz to reduce the potential for harmful interference to co-channel Mobile Satellite systems. v High power radar are allocated as primary users of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands.
- Page 11 CDC slot as shown below. The applied wireless cards are: v IC: 349E-PH12127E, Model: PH12127E (IBM 11a/b/g Wireless LAN Mini PCI Adapter) v IC: 349E-T60H786U, Model: T60H786-U (IBM 11b/g Wireless LAN Mini PCI Adapter) v IC: 349E-WM3B2100, Model: WM3B2100 (Intel PRO/Wireless LAN 2100 3B Mini PCI Adapter)
- Page 12 2. this device must accept any interference, including interference that may cause undesired operation of the device. When you use the model PH12127E (IBM 11a/b/g Wireless LAN Mini PCI Adapter): v The device for the band 5150–5250 MHz is only for indoor usage to reduce potential for harmful interference to co-channel Mobile Satellite systems.
- Page 13 Mini-PCI Card ou CDC comme illustré ci-dessous. Les cartes sans fil applicables sont les suivantes: v IC: 349E-PH12127E, Model: PH12127E (IBM 11a/b/g Wireless LAN Mini PCI Adapter) v IC: 349E-T60H786U, Model: T60H786-U (IBM 11b/g Wireless LAN Mini PCI Adapter) v IC: 349E-WM3B2100, Model: WM3B2100 (Intel PRO/Wireless LAN 2100 3B Mini PCI Adapter)
- Page 14 Fonctionnement dans la bande 5 GHz v Tout appareil destiné à la bande 5150–5250 MHz devra être exclusivement utilisé en intérieur afin de réduire les risques de perturbations électromagnétiques gênantes sur les systémes de satellite mobile dans un même canal. v Les radars à...
- Page 15 Regulatory Notice for ThinkPad X30 Series (X31) This notice is a supplementary document of the ThinkPad X30 Series Service and Troubleshooting Guide. Please read this document before you use the ThinkPad X30 Series computer. The ThinkPad X30 Series computer complies with the radio frequency and safety standards of any country or region in which it has been approved for wireless use.
- Page 16 For information concerning the wireless cards announced after the publication of this notice, visit the Web site at www.ibm.com/pc/qtechinfo/MIGR-43693.html Note: IBM 11b/g Wireless LAN Mini PCI Adapter marketed in US and Canada does not support nor function in the extended channels (12ch, 13ch).
- Page 17 Attention: The ThinkPad X30 Series computer contains an authentication mechanism If you install an unauthorized wireless LAN Mini-PCI Card or RF CDC module that is not approved for use in the ThinkPad X30 Series computer, the computer will not start, but only displays an error message and emits beeps.
- Page 18 ThinkPad X30 Series computer is far below the FCC radio frequency exposure limits. Nevertheless, the ThinkPad X30 Series computer shall be used in such a manner that the potential for human contact during normal operation is minimized as follows:...
- Page 19 RF option devices that have been approved to cooperate with the integrated wireless feature. 2. When you use any other RF option device that is not listed on the IBM site, all other wireless features including the integrated transmitter in your ThinkPad computer are required to be turned off.
- Page 20 U58H004 (Cisco Aironet Wireless 802.11b) 349E-BMDC200 BMDC200 (IBM Integrated Bluetooth III with 56K Modem) Note: IBM 11b/g Wireless LAN Mini PCI Adapter marketed in US and Canada does not support nor function in the extended channels (12ch, 13ch). Certification number...
- Page 21 You can install or remove each wireless feature by yourself. If you install an unauthorized wireless adapter that is not approved for use in the ThinkPad X30 Series computer, the computer will not start, but only displays an error message and emits beeps.
- Page 22 Exposition des êtres humains aux champs radioélectriques (RF) (RSS-102) Le ThinkPad X30 Series utilise des antennes intégrales à faible gain qui n’émettent pas un champ électromagnétique supérieur aux normes imposées par le Ministére de la santé canadien pour la population.
