Model No. PFSB43140 Serial No. The serial number is on a sign behind the access panel. Write the serial number in the space above. Access Panel QUESTIONS? If you have questions, or if there are missing parts, we will guar-...
Whenever the spa is moved, the sign must also be moved and reposted near the spa. If the sign becomes lost or illegible, call our toll-free Customer Hot Line at 1-888-884-6555 to obtain a replacement sign. Post the sign as described above. PROFORM is a registered trademark of ICON IP, Inc.
Important Safety Instructions WARNING: To reduce the risk of drowning, electric shock, or serious injury, read the fol- lowing important precautions before using the hydrotherapy spa. READ AND FOLLOW ALL INSTRUCTIONS 1. It is the responsibility of the owner to ensure that all users of the hydrotherapy spa are adequately informed of all precautions.
Page 4
The effects of hyperthermia include failure to per- ceive heat; failure to recognize the need to exit the spa or hot tub; unawareness of impending hazard; fetal damage in pregnant women; physical inability to exit the spa or hot tub and unconsciousness resulting in danger of drowning.
35. WARNING: The spa jets produce a stream of water with relatively high pressure. Prolonged exposure of a localized area of the body may cause bruises to the skin. 36. The included warning sign must be posted where all users of the hydrotherapy spa can see and read it.
Time (excluding holidays). To help us assist you, please mention the product model number and serial number when calling. The model number is PFSB43140. The serial number can be found on a decal on the access panel inside the spa (see the front cover of this manual).
Choosing a Location for the Hydrotherapy Spa There are many factors to consider when choosing a location to set up the hydrotherapy spa. These factors vary depending on whether you plan to use the spa inside or outside. We have listed several factors you may wish to consider as you decide where to set up the spa.
Wiring the Hydrotherapy Spa This procedure must be performed by a qualified, licensed electrician in accordance with the nation- al electric code, and with all local, state, and feder- al electric code. Under no circumstances should the hydrotherapy spa be wired by someone other than a qualified electrician.
Assembly Place all parts of the hydrotherapy spa in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires your own phillips screwdriver 1. Before beginning assembly, make sure that you have read and understand the information in the box above and on the previous two pages.
Page 10
3. Make sure that a qualified electrician has wired the spa to a 240 volt power source. Remove the two warning decals (see page 5) from the spa shell. Using a damp cloth, wipe the spa shell clean. Before filling the spa, make sure that it is in the desired position and that there is room to easily service it.
Using the Hydrotherapy Spa The hydrotherapy spa is designed to seat seven adults. The spa holds approximately 375 gallons of water and offers a heating system (80°F to 104°F), a filtration system, and adjustable hydrotherapy jets. Follow the guidelines below to use and maintain the spa for your long-term enjoyment.
Page 12
8. After one minute, the current temperature of the water will be displayed. Push the temperature up or down button to set the temperature of the water. If the water temperature is below the set temperature, the heat indicator light will turn on to show that the water is being heated.
Jet Layout Diagram A. The underwater light can be used for night opera- tion (see USING THE CONTROLS on page 14). B. The ten air injectors create air bubbles that enhance the hydrotherapy experience. C. The volcano jet provides a soothing foot massage. D.
Using the Controls Waterfall Valve Blower Mode Button Button Pump Pump Light Button 1 Button 2 Button Air control 1 determines the amount of air flowing through the hydrotherapy jets labeled 1 in the drawing above. If the control is turned counterclockwise, the amount of air will increase;...
Page 15
Your spa features an LED light with twelve different programmed lighting effects: 1. Lights cycle between Red, Green, and Blue 2. Dark Blue 3. Orange 4. Purple 5. Green 6. Red 7. Hot Pink 8. Cyan 9. White 10. Color Spectrum (each color is displayed for approximately one minute) 11.
Maintenance The hydrotherapy spa is designed to provide years of enjoyment. Please follow the guidelines below to properly maintain your spa. MAINTENANCE SCHEDULE Daily • Check the water level and refill the spa to the level shown in step 3 on page 10. •...
Page 17
WATER CHEMISTRY Maintaining the pH level of the water is very important to the operation of the spa. To maintain the proper pH level and to sanitize the spa, you can purchase a chemical starter kit from your local pool and spa sup- ply store.
Page 18
ATTACHING AND REMOVING THE ACCESS PANELS Shut off the power to the spa, at the circuit breaker or GFCI. To remove the indicated Access Panels (25), remove the eight #10 x 2” Machine Screws (39) that secure the Access Panels to the spa. Carefully remove the Access Panels and set them aside.
Page 19
DRAINING THE PUMPS After the hydrotherapy spa is drained, the jet pumps should also be drained if the spa will be stored for more than thirty days or if it may be exposed to freez- ing temperatures. Shut off the power to the spa, at the circuit breaker or GFCI.
Troubleshooting Most problems can be solved by following the simple steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, call our Customer Service Department toll-free at 1-888-884-6555, Monday through Friday, 8 a.m. until 5 p.m. Central Time. 1.
Page 21
9. SYMPTOM: THE WATER LEVEL DROPS a. A clamp or seal inside the pump compartment may be loose. Check inside the pump compart- ment for excess water and watch the pump unit while it is operating to see if water drips from any of the plumbing.
• The MODEL NUMBER of the product (PFSB43140) • The NAME of the product (PROFORM TEMPEST hydrotherapy spa) • The SERIAL NUMBER of the product (see the front cover of this manual) • The KEY NUMBER and DESCRIPTION of the part(s) (see the PART LIST and the EXPLODED DRAWING on...
