Page 2
IR Camera module* Camera Microphone Mode Mode Down Mode Up button button button Keyboard Mouse * Available on selected models only E12088_Zen_AiO_ZN270IE_QSG.indd 2 2016/12/7 11:32:18...
Page 3
Power input HDMI-out USB 3.1 Gen1 USB 2.0 2-in-1 card reader LAN port HDMI-in Headphone ASUS hereby delcares that this All-in-One PC is in compliance with the essential requirements and other relevant provisions of Directive 1995/5/EC. E12088_Zen_AiO_ZN270IE_QSG.indd 3 2016/12/7 11:32:18...
Page 4
Push the latch up and lift the bottom cover open. Remove the wireless dongle from the mouse and insert it into an empty USB port on your ASUS All-in-One PC. NOTE: • Using SuperSpeed USB devices and 2.4Ghz USB wireless devices at the same time may affect the wireless device performance.
