Page 13: About This Guide
Networks (VLANs). Accessing the softcopy library Softcopy versions of 8275-416 product documentation are available from either the Documentation CD-ROM (shipped with the product) or the IBM Networking Products Web site. To access product documentation shipped on the CD-ROM, follow the instructions in the booklet that accompanies the CD-ROM.
Page 14: Online Support
Online support To obtain support information, including technical tips, current product information, and code updates and fixes for the switch, visit the IBM Networking Tech Support page at: http://www.ibm.com/networking/support You may also subscribe to receive e-mail notifications about code updates, tips, and FAQs for your switch.
Page 15 – Port-based and fast spanning tree – Enable/disable Web mode configuration from SNMP – Enable/disable broadcast storm suppression trap v New terminal interface panels in Chapter 4 to reflect new function for Release 1.2. v General editorial changes xiii © Copyright IBM Corp. 1999...
Page 16 8275-416 User’s Guide...
Page 17: Chapter 1. Introduction
Flow Control v Year 2000 (Y2K) compliance Layer 2 switching The 8275-416 is a Layer 2 Ethernet switch in which frame forwarding is based on MAC addresses and VLAN membership. The switch supports the IEEE 802.1D (1998) and 802.1Q standards.
Page 18: Virtual Local Area Networks (Vlans)
“front” the router (the switch is positioned logically between the router and the networks to which it belongs). Because of this strategic vantage point in the network (Figure 1 on page 3), the switch has visibility to all packets flowing to and from the 8275-416 User’s Guide...
Page 19 router, as well as between any two switch ports. The switch monitors the traffic to determine if a Layer 2 shortcut can be used instead of subjecting the packet to Layer 3 router processing which can be relatively lengthy. Router Switch 1.1.1.x 2.2.2.x...
Page 20: Link Aggregation (Trunking)
So, when a network station is ready to send data, the switch does not allow the network station to communicate on the network until STP puts the port in forwarding state. The 30 second delay forces the network station users to wait 8275-416 User’s Guide...
Page 21: Management And User Interfaces
– Any standard MIB browser (SNMPv1) ® ® – IBM Nways Manager for Windows NT (V2.0 or later) – IBM Nways Manager for HP-UX (V2.0 or later) ® – IBM Nways Manager for AIX (V2.0 or later) Chapter 1. Introduction...
Page 22: Security
The default Read/Write user name is: admin , and the default password consists of blanks (no password). If you lose the password, contact your IBM service representative. v SNMP read/write protection based on community name. Reliability and serviceability...
Page 23: Hardware
ANSI/TIA/EIA 856-A or CSA T529 standards when connected to MDI ports. When connecting to other MDX ports, such as ports of other 8275-416 switches, you must use crossover cables. Do not use telephone extension cables in 10/100BASE-TX networks. The wire pairs in those cables are not twisted and the cables do not meet other requirements for use in a 10BASE-T network.
Page 24: Front Panel
Port LEDs are explained later in this chapter. Feature Module Slots 1 and 2 These feature modules are available to expand port connections for your switch: v 8-Port 10/100BASE-TX Ethernet Feature Module, P/N 30L6661 v 8-Port 100BASE-FX Ethernet Feature Module, P/N 30L6662 8275-416 User’s Guide...
Page 25 v 4-Port 100BASE-FX Ethernet Feature Module, P/N 31L4054 v 2-Port 1000BASE-SX Ethernet Feature Module, P/N 30L6663 Chapter 1. Introduction...
Page 26: Switch Led Status
There is a hardware fault. The switch is not operational. Blinking Diagnostics are in process. The switch is not yet operational. Note: Any other state of the LEDs indicates an LED failure. 8275-416 User’s Guide...
Page 27: Single-Digit Display
Single-digit display The single-digit display (shown in Figure 3 on page 10) displays characters while diagnostics are running after power is applied to the switch. At the successful completion of diagnostics, the unit number appears in the display (for example, “1” indicates Unit Number 1).
Page 28: Base Ports Leds
Table 4. Status of LEDs for 16 base 10/100BASE-TX ports Color State Explanation Right Ethernet Green Indicates a 100-Mbps port. Port LED Indicates a 10-Mbps port. Left Ethernet Port Green The link is up. The link is down. Blinking Transmitting (Tx) and Receiving (Rx) traffic. 8275-416 User’s Guide...
Page 29: Feature Module Leds
Feature module LEDs Each feature module has an OK and a Fault LED located at the left side of the faceplate. The OK LED is green and the Fault LED is yellow. LED locations are shown in Figure 5, Figure 6 on page 14, Figure 7 on page 15, and Figure 8 on page 16;...
Page 30 Fault Yellow There is a module fault. There is no module fault. Port LED Green Link is up. Link is down. Blinking Transmitting (Tx) and receiving (Rx) traffic. 8275-416 User’s Guide...
Page 31 Status LEDs for the 4-port 100BASE-FX Ethernet feature module 4-Port 100BASE-FX Feature Module Fault Link /TxRx Feature Port Module LEDs Figure 7. LEDs for the 4-port 100BASE-FX feature module. Table 7. Status of LEDs for 4-port 100BASE-FX feature module Color State Explanation Green...
Page 32 Fault Yellow There is a module fault. There is no module fault. Port LED Green Link is up. Link is down. Blinking Transmitting (Tx) and receiving (Rx) traffic. 8275-416 User’s Guide...
Page 33: Physical Characteristics
Physical characteristics Table 9 summarizes the physical characteristics for the switch: Table 9. Summary of physical characteristics for the switch Characteristic Specification Physical Dimensions Height 63.0 mm (2.48 in.) 1.5 EIA rack units Width 440.0 mm (17.16 in.) Depth 355.6 mm (14 in.) Weight (estimate) 6.0 kg (13 lb) Minimum Service Clearance...
Page 34 8275-416 User’s Guide...
Page 35: Chapter 2. Accessing The Switch
1. Attach one end of a null-modem cable to the EIA 232 port of the switch as shown in Figure 9 on page 20, and the other end to the COM port of your PC (see “Appendix C. Cable Pinout Diagrams” on page 109). © Copyright IBM Corp. 1999...
Page 36 Figure 10. Out-of-band connectivity - remotely attached terminal 3. Set up the modem that is attached to the switch by following these steps: a. Configure the modem to use the same settings as those on your switch. v Baud rate: 19200 8275-416 User’s Guide...
Page 37: In-Band Connection – Telnet, Web, Snmp
v Parity: None v Data bits: 8 v Stop bits: 1 v Flow control: None b. Configuration command syntax varies from modem to modem. Make sure that the modem has the following characteristics: v Asynchronous mode v Disable modem response v Disable flow control (for example, AT \Q) v Disable echo (for example, AT Q1) v Autoanswer mode on second ring (for example, AT SO=2)
Page 38 You can use the Web interface to access and change switch parameters. Menus similar to those available through the terminal interface are also displayed by the Web browser. To access the switch from a Web browser, you must have configured 8275-416 User’s Guide...
Page 39 the IP information for the switch. You will need a valid login user ID and password. The accepted user IDs and passwords are the same as those configured for the terminal interface. The is no specific logout command to end a Web session. The Web session will be automatically logged off after a period of inactivity.
Page 40 8275-416 User’s Guide...
Page 41: Chapter 3. Configuring Your Switch
2. Select the Management Menu from the Main Menu. 3. Select Network Connectivity Configuration Menu from the Management Menu, then specify IP address, Subnet Mask, and Default Gateway. Also, ensure that None is specified for Network Configuration Protocol Current. © Copyright IBM Corp. 1999...
Page 42 DHCP server until a response is received. v None: the switch will be manually configured with IP information as specified on the Network Connectivity Configuration Menu. Network Configuration Protocol on Next Reset When you select BootP/Static DHCP (the default), the switch periodically 8275-416 User’s Guide...
Page 43: Configuration Changes
sends requests to a BootP or DHCP server until a response is received. You must specify None, if you want to manually configure the switch with the appropriate IP information. When this value is modified, you need to issue a Save and then reset the switch in order for the new value to take effect.
Page 44 – MAIN MENU – PREV MENU Note: Configuration changes are not automatically retained across a reset or a power cycle. To retain changes, you must select the Save command as described in the following section. 8275-416 User’s Guide...
Page 45: Making Configuration Changes Using The Web Interface
Saving the configuration changes across a reset or power cycle To save configuration changes across a reset or power cycle, perform one of the following actions: v Select F4 (Save). v Select Save Applied Changes on the System Utilities Menu. If you select SAVE without previously having selected APPLY for recently made configuration changes, the changes are automatically applied.
Page 46: Making Configuration Changes Using Snmp
From the System Utilities panel, you can select to Upload File From Switch or Download File to Switch to process a configuration file; just specify Config File as the file type on either panel. The switch must have a path available through Default VLAN (VLAN 1). 8275-416 User’s Guide...
Page 47: Chapter 4. Using The Terminal Interface
The terminal interface provides a way to log out. From the Main Menu, select LOGOUT or select System Utilities Menu, then select Logout. When you have finished using the terminal interface, ensure you have saved all configuration changes before logging out. © Copyright IBM Corp. 1999...
Page 48: The Main Menu
To access system information, select System Information Menu on the Main Menu. By selecting Inventory Information Menu and System Description Menu, you can view information about your switch. Figure 15 on page 33 shows your system information options. 8275-416 User’s Guide...
Page 49: Inventory Information
Figure 15. System information menu Inventory information Figure 16 shows the Read-Only inventory information available for your switch. Figure 16. Inventory information menu System description Figure 17 on page 34 shows the system information for your switch. Chapter 4. Using the Terminal Interface...
Page 50 Indicates the physical location of the switch. Specify up to 31 alphanumeric characters. The default is blank. System Contact Identifies the person responsible for your network (for example, you network administrator) Specify up to 31 alphanumeric characters. The default is blank. 8275-416 User’s Guide...
Page 51: Management
Management Select Management Menu on the Main Menu (Figure 18) to use the management functions of the switch. Figure 18. Management menu Configuring network connection for the switch To configure the IP information, select Management Menu from the Main Menu, then select Network Connectivity Configuration Menu from the Management Menu.
Page 52: Configuring Serial Port
The switch allows you to access the switch through the serial EIA 232 port. This type of connectivity is called out-of-band connection. See “Chapter 2. Accessing the switch” on page 19 for descriptions of ways to access the switch. 8275-416 User’s Guide...
Page 53: Configuring For Dhcp Or Bootp
On the Main Menu, select Management Menu. From the Management Menu, select Serial Port Configuration Menu. Figure 20 shows the parameters to configure the serial EIA 232 port. Figure 20. Serial port configuration You specify Login Timeout and Baud Rate: Serial Port Login Timeout Specifies the maximum connect time without console activity.
Page 54: Configuring The Snmp Community
SNMP managers allowed to manage it with a specified privileged level. You can add, change or delete communities. The switch does not have to be reset for changes to take effect. Up to six communities are simultaneously supported. 8275-416 User’s Guide...
Page 55 Community names in the SNMP community table must be unique. If you make multiple entries using the same community name, the first entry is kept and processed and all duplicate entries are ignored. To configure your SNMP communities, select SNMP Community Configuration Menu from the Management Menu.
Page 56 IP address, the first entry is kept and processed and all duplicate entries are ignored. To configure trap receivers, select SNMP Trap Receiver Configuration Menu on the Management Menu. Figure 22 on page 41 shows the parameters you need to specify. 8275-416 User’s Guide...
Page 57: Configuring Traps
Figure 22. SNMP trap receiver configuration Trap receiver parameters are: SNMP Community Name This is the SNMP community name of the remote network manager; the name can be up to 16 characters, and is case-sensitive. The default value for the 6 undefined community names is Delete. IP Address Each IP address parameter is four decimal numbers.
Page 58: Trap Log
Trap Log information is not retained across a switch reset. Select Trap Menu from the Management Menu, then select Trap Log Menu from the Trap Menu. Figure 24 on page 43 shows the entries in the trap log. 8275-416 User’s Guide...
Page 59 Figure 24. Trap log Each entry contains: System Up Time This entry shows how long the system has been up when the trap occurred. Trap This entry is the name of the trap condition, which can be: v Cold Start v Authentication Failure v Link Up v Link Down...
Page 60: Configuring Telnet
Accessing the switch” on page 19 describes setting up a Telnet connection. To configure for Telnet, select Management Menu from the Main Menu, then from the Management Menu, select Telnet Configuration Menu (Figure 26). Figure 26. Telnet configuration 8275-416 User’s Guide...
Page 61: Ping
The following parameters are for configuring a Telnet session with the switch: Telnet Login Timeout A session is active as long as the session has not remained idle for the value set. Specify a decimal value from 0 to 160 minutes. A value of 0 indicates that a Telnet session remains active indefinitely.
Page 62: Arp Cache
This is used to check connectivity between the switch and other devices. The ARP cache identifies the MAC addresses of the IP stations communicating with the switch. Figure 28 shows ARP Cache information. Figure 28. ARP cache 8275-416 User’s Guide...
Page 63: Device Configuration
Device configuration To configure the switch, select Device Configuration Menu on the Main Menu. Figure 29 shows your options. Figure 29. Device configuration Configuring the switch The switch allows you to set a time after which the address will timeout, and to enable/disable broadcast storm recovery and 802.3x flow control.
Page 64: Configuring Ports
See “Chapter 3. Configuring your switch” on page 25 for details about making and saving configuration changes. To configure the ports, select Device Configuration Menu from the Main Menu, then select Port Configuration Menu from the Device Configuration Menu (Figure 31 on page 49). 8275-416 User’s Guide...
Page 65 Figure 31. Port configuration You can select or change the following values: Slot This is a read/write field. The 16 base ports are associated with slot 0. A feature module in Slot 1 or Slot 2 can have 2, 4, or 8 ports associated with each of them, depending on the feature module that is installed.
Page 66: Configuring Port Monitoring
3. The monitoring port always transmits frames with the NCFI bit set. Therefore, frames not transmitted not on the monitored port due to untagging and a set NCFI bit cannot be detected and filtered by the monitoring port. In this case, the 8275-416 User’s Guide...
Page 67 monitoring port will transmit these frames, even though they are not transmitted by the monitored port. The existence of such frames in a network is expected to be a rare occurrence. 4. Frames not forwarded by the monitored port will not be monitored. These include: v Local frames v 802.3x PAUSE frames...
Page 68: Configuring Spanning Tree Protocol (Stp)
When the switch is root, Maximum Age Time is the time in seconds during which the configuration message used by the Spanning Tree Algorithm is discarded. The range is 6 to 40 seconds. The default is 20 seconds. 8275-416 User’s Guide...
Page 69: Vlan Management
Hello Time When the switch is root, Hello Time is the time in seconds that the switch waits before sending the next configuration message. The range is 1 to 10 seconds. The default is 2 seconds. Forward Delay Time This value specifies the time spent in “Listening and Learning” mode before forwarding packets.
Page 70 32 VLANs. Figure 36. VLAN summary and configuration The parameters for this panel are: Unit ID Selects the unit for which data is to be displayed or configured. In a non-stacked environment the Unit ID is 1. 8275-416 User’s Guide...
Page 71 VLAN Index Sequential number of defined VLANs. You can configure 8 VLANs on each of 4 pages for up to 32 VLANs. VLAN ID VLAN identifier. It can be any number from 2 to 4094 (ID 1 is reserved for the default VLAN).
Page 72 GVRP Used to enable or disable GVRP (GARP VLAN Registration Protocol). The default is Disabled. GARP Timers v Join Time: Specifies the interval between the transmission of GARP PDUs registering (or reregistering) membership for a VLAN or multicast 8275-416 User’s Guide...
Page 73 group. This value applies per port and per GARP. The value can be from 10 to 100 centiseconds (0.1 to 1.0 seconds). The default is 20 centiseconds (0.2 seconds). v Leave Time: Specifies the period of time to wait after receiving an unregister request for a VLAN or a multicast group before deleting the VLAN entry.
Page 74: Trunk Management Menu
Trunk Status Menu, then move the cursor to the ifIndex field, press Enter, and the Configure Trunk Menu (Figure 42 on page 60) is displayed. Complete the configuration information on the Configure Trunk Menu. 8275-416 User’s Guide...
Page 75 Figure 41. Trunk status menu ifIndex Trunk interface number (ifIndex) values are fixed at 33 to 40. The interface number is assigned by the switch and in a range above the numbers of the ports (for example, ifIndex 33 to 36 is shown on panel 1of 2, and 37 to 40 is shown on panel 2 of 2).
Page 76 (ports 1 and 2, 1 to 4, or 1 to 8 are listed on the first panel) if the feature module is installed. Include in Trunk Indicates whether the port is included in trunk. You can specify No or Yes; No is the default. 8275-416 User’s Guide...
Page 77: Statistics
Statistics To access statistics, select Statistics Menu on the Main Menu. Traffic statistics are kept by port. Details and summaries of packets broadcast, transmitted, and switched, as well as error packets and discarded packets are the types of statistics kept for your switch. Figure 43 shows the types of statistics that you can select to view from the Statistics Menu.
Page 78: Port Detailed Statistics
(Figure 45, Figure 46 on page 63, Figure 47 on page 63, and Figure 48 on page 64). To view the next panel, move the cursor to NEXT PAGE (at the bottom of each panel) and press Enter. Figure 45. Port detailed statistics (Page 1 of 4) 8275-416 User’s Guide...
Page 79 Figure 46. Port detailed statistics (Page 2 of 4) Figure 47. Port detailed statistics (Page 3 of 4) Chapter 4. Using the Terminal Interface...
Page 80: Switch Summary Statistics
Figure 49. Switch summary statistics Switch detailed statistics To view detailed switch statistics, select Switch Detailed Statistics Menu (Page 1 of 2) from the Statistics Menu. See Figure 50 on page 65 for the detailed switch statistics that are collected. 8275-416 User’s Guide...
Page 81 To view Self Learning IP statistics, select Switch Detailed Statistics Menu (Page 2 of 2) from the Statistics Menu. See Figure 51 for an example of the statistics that are collected for Self Learning IP. Figure 50. Switch detailed statistics Figure 51.
Page 82: Forwarding Database Information
To view statistics about known routers whenever the Self Learning IP function is enabled, select Statistics Menu from the Main Menu, then select Self Learning IP Router Table Menu. See Figure 53 on page 67 for the router statistics. 8275-416 User’s Guide...
Page 83: Self Learning Ip Host Address Menu
Figure 53. Self Learning IP router table menu The description of the information collected is: Number of known router entries Current number of known routers identified by the Self Learning IP function since it was enabled. This is the same value that is found on the Switch Detailed Statistics Menu.
Page 84 IP Address is entered and Apply is selected, these lines appear. 2. If the specified Host IP address is not found, the message “Information for <IP address> is not available” where <IP address> is the value that was entered for “IP Address of Host to Display”. 8275-416 User’s Guide...
Page 85 3. The latest value for the Host Packets Switched count is shown whenever the host information is displayed or manually refreshed. Changes in the count value are also reflected in the Packets Switched value on the Switch Detailed Statistics Menu. Chapter 4.
Page 86: User Account Management
This user can change the status of other users, add and delete users, change passwords and change configurations, and use system utilities. Read Only Up to five users can be defined with read only access mode per 8275-416 User’s Guide...
Page 87: Managing Login Sessions
switch. When Read only users are logged in, the message READONLY appears at the top right corner of all panels. A user with read only access is restricted from accessing the SNMP Community Configuration menu, SNMP Trap Receiver Configuration menu, User Account Management menu, and System Utilities menu.
Page 88: System Utilities
One way is to use the LOGOUT command on the Main Menu. Another way to log out is to select System Utilities Menu from the Main menu, then select Logout as shown in Figure 58 on page 73. 8275-416 User’s Guide...
Page 89: Handling Files
This allows you to back up the configuration or to easily update the configuration of multiple switches. Additionally, you can provide a configuration file to IBM support personnel for problem determination. The last-saved configuration used by the switch is retained after a code update or a reset.
Page 90 The file will not be stored in flash. If this is for a code update, obtain the correct software image from the IBM Web site. If this is for configuration, make sure that the configuration file originated from a 8275-416 switch.
Page 91: Downloading A File To The Switch
Table 12. Messages - while uploading files (continued) Message Explanation File transfer failed! A general error occurred. The most likely cause of this message is when the switch cannot complete the TFTP operation. This may happen if you have not entered the correct IP address for the TFTP server, or if an IP address has not been set up on the switch.
Page 92 The IP address of the server where the file is located. It is valid only when the Transfer Mode is TFTP. The address is 4 decimal bytes ranging from 0 to 255. The default value is zeros. 8275-416 User’s Guide...
Page 93: Reset Utility
Reset utility You can reset the switch without powering it off. Reset means that all network connections are terminated and the boot code executes. The switch uses the stored configuration to initialize the switch. You are prompted for confirmation if you want the reset to proceed.
Page 94: Resetting Configuration Data To Factory Default Values
Reset the configuration data to the factory defaults by indicating the particular unit as shown in Figure 63. You must identify the switch to reset. None is the default. Figure 63. Reset configuration data to factory defaults 8275-416 User’s Guide...
Page 95: Resetting Passwords To Factory Default Values
Resetting passwords to factory default values You can reset user passwords to factory default values without powering off the switch. The factory defaults are not restored until the switch is reset. The switch is automatically reset when this command is processed. You are prompted to confirm that you want the reset to proceed.
Page 96 8275-416 User’s Guide...
Page 98: Starting The Web Interface
Undo Restores any changes made on the panel to their original value since the last Apply or Save. Save Implements and saves the changes you just made. Some settings may require you to reset the system in order for them to take effect. 8275-416 User’s Guide...
Page 99 Apply Implements the changes you just made. Some settings may require you to reset the system for them to take effect. Refresh The Refresh button that appears next to the Apply button in Web interface panels refreshes the data on the panel. Restart Refreshes the list and displays the data starting at the beginning of the list.
Page 100 8275-416 User’s Guide...
Page 101: Chapter 6. Using The Snmp Interface
The latest 8275-416 MIBs can be obtained from our Web site at: http://www.ibm.com/networking/support Note: Exceptions to the 8275-416 support for the MIBs listed in Table 13 are described in the sections that follow in this chapter. MIB II (RFC 1213)
Page 102: Definitions Of Managed Objects For Bridges (Rfc 1493)
(LAN) segments. The following objects are 8275-416 exceptions to definitions of managed objects for bridges: dot1dStp dot1dStpPortEnable is a read-only object. To modify the administrative state of an interface via SNMP, use swPortCtrlAdminMode in the 8275-416 private MIB. dot1dSr Group Not supported.
Page 103: Remote Monitoring (Rmon) Mib (Rfc 1757)
IBM 8275-416 switch enterprise MIB Many of the items needed to obtain information from a switch are not available in standard MIBs. A private MIB for the switch (referred to as the IBM 8275-416 Switch Enterprise MIB) was created for these items.
Page 104 8275-416 User’s Guide...
Page 105: Chapter 7. Troubleshooting And Obtaining Service
Be sure you read “Appendix A. Safety Information” on page 93 before proceeding. Obtaining Software To obtain support information, including technical tips, current product information, and code updates and fixes for the switch, visit the IBM Networking Tech Support page at: http://www.ibm.com/networking/support You can also subscribe to receive e-mail notifications about code updates, tips, and FAQs for your switch.
Page 106: Choosing A Troubleshooting Procedure
If the switch comes up, reinstall the feature modules one at a time, and reset the switch to determine the failing feature module. 3. If the problem is not corrected, the switch is defective. See “Obtaining Service” on page 92. 8275-416 User’s Guide...
Page 107: Procedure C
Procedure C Use this procedure if all devices connected to the switch are having communication problems, the Fault LED is Off and the OK LED is On: 1. Reset the switch by disconnecting the power cord from the outlet, waiting 10 seconds, and reconnecting the power cord to the ac outlet.
Page 108: Procedure E
1 800 426 7378 (1 800 IBM-SERV) in Canada. v In other locations, contact your place of purchase. Refer to your IBM Warranty for information concerning service for the product, or contact the place where you purchased the product.
Page 109: Appendix A. Safety Information
Perigo: Antes de começar a instalar este produto, leia as informações de segurança contidas em Cuidado: Informações Sobre Segurança—Leia Isto Primeiro, SD21-0030. Esse folheto descreve procedimentos de segurança para a instalação de cabos e conexões em equipamentos elétricos. © Copyright IBM Corp. 1999...
Page 110 Danger : Avant d’installer le présent produit, consultez le livret Attention: Informations pour la sécurité — Lisez-moi d’abord , SD21-0030, qui décrit les procédures à respecter pour effectuer les opérations de câblage et brancher les équipements électriques en toute sécurité. 8275-416 User’s Guide...
Page 111 Vorsicht: Bevor mit der Installation des Produktes begonnen wird, die Sicherheitshinweise in Achtung: Sicherheitsinformationen—Bitte zuerst lesen, IBM Form SD21-0030, lesen. Diese Veröffentlichung beschreibt die Sicherheitsvorkehrungen für das Verkabeln und Anschließen elektrischer Geräte. Vigyázat: Mielôtt megkezdi a berendezés üzembe helyezését, olvassa el a Caution: Safety Information—...
Page 112 Perigo: Antes de iniciar a instalação deste produto, leia as informações de segurança Cuidado: Informações de Segurança — Leia Primeiro , SD21-0030. Este documento descreve como efectuar, de um modo seguro, as ligações eléctricas dos equipamentos. 8275-416 User’s Guide...
Page 113: Safety Notice
Peligro: Antes de empezar a instalar este producto, lea la información de seguridad en Atención: Información de Seguridad — Lea Esto Primero, SD21-0030. Este documento describe los procedimientos de seguridad para cablear y enchufar equipos eléctricos. Varning — livsfara: Innan du börjar installera den här produkten bör du läsa säkerhetsinformationen i dokumentet Varning: Säkerhetsföreskrifter—...
Page 114 Achtung: Zweipolige bzw. Neutralleiter-Sicherung im Netzteil. Netzstecker ziehen, um sicherzustellen, daß; keine Spannung am Gerät; anliegt. Attenzione: L’alimentatore contiene fusibili su fasi/neutro. Puoò essere presente tensione nell’apparecchiatura se il cavo di alimentazione è collegato. 8275-416 User’s Guide...
Page 115 Advarsel: Topolet/nøytral; sikring i strømforsyningsenheten.; Det kan være; strø.m; i maskinen hvis ikke nettkabelen er dratt ut . Cuidado: Protecção (por fusíveis) bipolar com neutro na fonte de alimentação. A menos que o cabo de alimentação esteja desligado, o produto pode estar sob tensão. Precaución: Hay una fusión de doble polo/neutro en la fuente de alimentación.
Page 116 8275-416 User’s Guide...
Page 117 Appendix A. Safety Information...
Page 118 8275-416 User’s Guide...
Page 119: Appendix B. Notices
Consult your local IBM representative for information on the products and services currently available in your area. Any reference to an IBM product, program, or service is not intended to state or imply that only that IBM product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any IBM intellectual property right may be used instead.
Page 120: Electronic Emission Notices
Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. IBM is not responsible for any radio or television interference caused by using other than recommended cables and connectors or by unauthorized changes or modifications to this equipment.
Page 121: Japanese Voluntary Control Council For Interference (Vcci) Statement
Störquelle zu vergrößern.” Anmerkung: Um die Einhaltung des EMVG sicherzustellen sind die Geräte, wie in den IBM Handbüchern angegeben, zu installieren und zu betreiben. Japanese Voluntary Control Council for Interference (VCCI) Statement This product is a Class A Information Technology Equipment and conforms to the standards set by the Voluntary Control Council for Interference by Information Technology Equipment (VCCI).
Page 122: Power Line Harmonics Compliance
Luokan 1 Laserlaite Appareil à Laser de Classe 1 To IEC 825-1:1993 Class 1 LED Statement Class 1 LED Product LED Klasse 1 LED Klass 1 Luokan 1 Ledlaite Appareil à LED de Classe 1 To IEC 825-1:1993 8275-416 User’s Guide...
Page 123: Trademarks
Trademarks The following terms are trademarks of International Business Machines Corporation in the United States or other countries or both: Nways Microsoft, Windows, Windows NT, and the Windows logo are trademarks of Microsoft Corporation in the United States, other countries, or both. Java and all Java-based trademarks and logos are trademarks of Sun Microsystems, Inc.
Page 124 8275-416 User’s Guide...
Page 125: Appendix C. Cable Pinout Diagrams
Straight-Through 10BASE-T/100BASE-TX Cables Figure 66. Straight-Through UTP Cable (RJ-45 to RJ-45), T568A Figure 67. Straight-Through UTP Cable (RJ-45 to RJ-45), T568B Straight-Through 10BASE-T/100BASE-TX Cables for STP Figure 68. Straight-Through STP Cable (RJ-45 to IBM Data Connector) © Copyright IBM Corp. 1999...
Page 126: Crossover 10Base-T/100Base-Tx Cables
Crossover 10BASE-T/100BASE-TX Cables Figure 69. Crossover UTP Cable (RJ-45 to RJ-45), T568A Figure 70. Crossover UTP Cable (RJ-45 to RJ-45), T568B Crossover 10BASE-T/100BASE-TX Cables for STP Figure 71. Crossover STP Cable (RJ-45 to IBM Data Connector Crossover) 8275-416 User’s Guide...
Page 127: Eia-232 Port
EIA-232 Port Figure 72. Pinout of the EIA-232 Port Appendix C. Cable Pinout Diagrams...
Page 128: Null-Modem Cables
Null-Modem Cables Terminal/PC End Switch End 25-Pin Male 9-Pin Female Signal Name Figure 73. EIA-232 Null Modem Cable for Terminal with 25-Pin Connector Figure 74. EIA-232 Null Modem Cable for Terminal with 9-Pin Connector 8275-416 User’s Guide...
Page 129: Appendix D. Interface Conventions For The Console
Up Arrow Key: The up arrow key moves the cursor vertically up to the first character in the previous row in the same position as the original row or wraps to the next section of the menu. © Copyright IBM Corp. 1999...
Page 130 When the cursor is on a modifiable field indicated by angle brackets, use the space bar to toggle through the options for that field. When the cursor is on a modifiable field indicated by square brackets, the space bar may be an allowable key to enter text. 8275-416 User’s Guide...
Page 131 Table 15. Special Keys and Commands Used with the Terminal Interface (continued) Special Keys/ Description Text/Commands Function keys Takes you to the Help Menu. Toggles between the first item in the menu body and the Command bar. Takes you back to the previous menu. This is the Save key and is used to save changed configuration data.
Page 132 8275-416 User’s Guide...
Page 133: Appendix E. Introduction To Virtual Lans (Vlans)
How VLANs provide extra security Devices within each VLAN can communicate only with devices in the same VLAN. Figure 75 on page 118 shows a network configured with three VLANs—one for each of the departments that access the network. © Copyright IBM Corp. 1999...
Page 134: Vlans And The Switch
0 to 3 are transmitted as low priority. Frames with a priority of 4 to 7 are transmitted at high priority. The mapping from user priority to traffic class is defined in table 7-2 of the IEEE P802.1D standard 8275-416 User’s Guide...
Page 135: Overview Of Ieee 820.1Q Vlan Support
Overview of IEEE 820.1Q VLAN support The switch supports IEEE 802.1Q standards-based VLANs. This standard describes port-based VLANs as well as the methods to propagate VLAN memberships across compliant devices using GARP VLAN Registration Protocol (GVRP). Each frame contains information about the VLAN. This information is contained in a 4-byte tag that is inserted into each frame.
Page 136: Configuration Examples
VLAN. After this configuration is complete, the frames from Station A will arrive at Port 1 untagged, and will then be tagged internally to the switch with the PVID (VLAN 5). 8275-416 User’s Guide...
Page 137 These frames will be sent to port 12 which is a member of the same VLAN. Because the port is set to untagged frames for this VLAN, the tag will be removed and the frame sent to Device B untagged. 802.1Q-compliant device (tagging and GVRP) to 802.1Q- compliant device (tagging and GVRP) No Static VLANs...
Page 138 VLAN. If any devices on a link cannot handle tagged frames, it would be best to configure the port to transmit frames as untagged in any VLAN in which those devices participate. 8275-416 User’s Guide...
Page 139: Using Unique Mac Addresses
Too many duplicate VLANs may also lead to an oversubscription of switch resources. The 8275-416 always guarantees resources for all 32 ports in the Default VLAN (VLAN 1). Up to 31 additional VLANs may be configured or registered with the switch, with certain restrictions.
Page 140 VLANs, but the VLANs having the same port membership. Another use for duplicate VLAN configurations would be if a switch is placed in the core or in an intermediate level of a network. The 8275-416 functions best as an edge device as opposed to as a core switch.
Page 141: Index
100BASE-FX 7 description of 2 100BASE-TX 7 8275-416 10BASE-TX 7 physical characteristics of 17 capabilities of 8275-416 1 Category 3 7 Category 4 7 Category 5 7 acceptable frame types 57 Clear, trap log operation 44 access mode, user account management...
Page 142 Dynamic Host Configuration Protocol (DHCP) 25 transfer mode 76 use of 73 hardware Enterprise MIB 6 physical characteristics of 17 error log upload 76 hardware description Ethernet cable types cable requirements 7 Category 3 7 front panel 8 8275-416 User’s Guide...
Page 143 IP information, configuring 25 menu command descriptions of 113 MIB II 6 MIBs supported known routers, number of 65 8275-416 MIB 85 Bridge MIB 5 Enterprise MIB 5 MIB II 5 Layer 2 switching functions RFC 1213 85 description of 1...
Page 144 61 telephone numbers for 92 port switching Service number of ports 6 diagnosing problems 89 packet processing rates 6 obtaining 89 port VLAN ID 57 obtaining software 89 PREV MENU command 113 service, Web site for 89 8275-416 User’s Guide...
Page 145 service clearance special keys (continued) front 17 brackets (continued) rear 17 square 113 sides 17 Cntl-Tab 113 serviceability 6 Delete 113 Simple Network Management Protocol (SNMP) down arrow 113 agent 5 End 113 Slot ID 55 Enter 113 SNMP-base management interface 22 Esc 113 SNMP-based management interface Insert 113...
Page 146 Link up 43 LOGOUT 113 Multiple users 43 MAIN MENU 113 New spanning tree root 43 NEXT PAGE 113 Spanning tree topology change 43 PREV MENU 113 trunking function PREV PAGE 113 REFRESH 113 description of 4 8275-416 User’s Guide...
Page 147 weight 17 UNSAVED DATA command 113 up arrow 113 uploading configuration file 76 Y2K (year 2000) uploading error log 76 compliance statement 6 uploading files from the switch 73 Web site for 6 uploading system trace 76 year 2000 6 uploading trap log 76 uppercase words 113 user access...
Page 148 8275-416 User’s Guide...
Page 149: Glossary
Fragment Packet. An Ethernet packet less than 64 octets long (excludes frame bits but includes FCS octets) - not an integral number of packets in length or has a bad FCS. GARP. See Generic Attributes Registration Protocol. © Copyright IBM Corp. 1999...
Page 150 Presentation Layer. The sixth layer of the OSI network layer model. This layer controls the formatting and translation of data. Protocol. A set of rules and procedures that govern the exchange of data between two communicating systems. 8275-416 User’s Guide...
Page 151 Protocol Number. The port or program number as defined by the parent protocol. For example, if you are adding a TCP child protocol, the protocol number will be the TCP port number. PSTN. Public switched telephone network. RMON. Remote MONitoring. Subset of SNMP MIB II which allows monitoring and management capabilities by addressing up to ten different groups of information.
Page 152 8275-416 User’s Guide...
Page 153 Thank you for your responses. May we contact you? h Yes h No When you send comments to IBM, you grant IBM a nonexclusive right to use or distribute your comments in any way it believes appropriate without incurring any obligation to you. Name...
Page 154 FIRST-CLASS MAIL PERMIT NO. 40 ARMONK, NEW YORK POSTAGE WILL BE PAID BY ADDRESSEE Department CGFA–Design and Information Development IBM Corporation P.O. Box 12195 Research Triangle Park, NC, U.S.A. 27709-9990 _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _...
Page 156 Printed in the United States of America on recycled paper containing 10% recovered post-consumer fiber. Web sites: 8275-416 Documentation http://www.ibm.com/networking/support/docs.nsf/8275docs 8275-416 Software Updates http://www.ibm.com/networking/support/downloads/8275 8275-416 Product Support http://www.ibm.com/networking/support/8275 GC30-4026-02...

IBM 8275-416 User Manual

Chapter 1. Introduction

Chapter 2. Accessing the Switch

Chapter 3. Configuring Your Switch

Chapter 4. Using the Terminal Interface

Chapter 5. Using the Web Interface

Chapter 6. Using the SNMP Interface

Chapter 7. Troubleshooting and Obtaining Service

Appendix A. Safety Information

Appendix B. Notices

Appendix C. Cable Pinout Diagrams

Appendix D. Interface Conventions for the Console

Appendix E. Introduction to Virtual Lans (Vlans)

Quick Links

Troubleshooting

Related Manuals for IBM 8275-416

Summary of Contents for IBM 8275-416

Table of Contents
