- Page 1 Turf 1 Turf 2 Turf 6 200 1 asoline ehicles Owner’ s Manual...
-
Page 3: Turf
• Magneto or electronic ignition system system is used to eliminate blow-by gases. The System Warranty requires that you return your engine to an authorized Club Car Dealer for blow-by gases are led to the breather chamber • Fuel filter element through the crankcase. -
Page 4: Turf
Please complete and return the warranty registration card included in this manual. Club Car is not liable for errors in this manual or for incidental or consequential damages that result from the use of the material in this manual. - Page 5 We hope you will consider this owner’s manual a permanent part of your Club Car Turf utility vehicle. If you sell the vehicle, please include the manual so that the next owner will have the important operating, safety, and maintenance information it contains.
-
Page 6: Practice Safety
Safety signs like you see above may at first seem shocking, but their impact is mild compared with the reality of severe personal injury. Your safety and satisfaction are of the utmost importance to Club Car. That is why before operating the vehicle, we urge you to review the information in this manual. - Page 7 TABLE OF CONTENTS Safety Details ..............General Warnings .
-
Page 8: Turf
2001 Turf Utility Gasoline Vehicle Owner’s Manual... -
Page 9: Safety Details
If any of the operation or warning decals on the vehicle become damaged, have been removed, or cannot be easily read, they should be replaced immediately to avoid possible property damage, personal injury, or death. Contact your Club Car distributor/dealer. DANGER •... -
Page 10: General Warnings
• A UTILITY VEHICLE WILL NOT PROVIDE PROTECTION FROM LIGHTNING, FLYING OBJECTS, OR OTHER STORM RELATED HAZARDS. IF CAUGHT IN A STORM WHILE DRIVING A CLUB CAR TURF UTILITY VEHICLE, EXIT THE VEHICLE AND SEEK SHELTER IN ACCORDANCE WITH APPLICABLE SAFETY GUIDELINES FOR YOUR LOCATION. -
Page 11: General Information
MODEL IDENTIFICATION The serial number of your Club Car Turf utility vehicle is printed on a bar code decal mounted on the frame directly above the accelerator pedal (Example: FG0101-123456) (Figure 2, Page 9). There is also a second serial number decal mounted on the front body frame behind the center dash panel. -
Page 12: 2001 Turf Utility Gasoline Vehicle Owner's Manual
Vehicle Feature Identification TURF 1 AND TURF 2 OPERATING INSTRUCTIONS WARNING • Read Owner's Manual and safety warnings located on dash panel prior to driving. ROLLOVER OR FALLING OFF MAY CAUSE DEATH. • Study and understand controls. • Before using vehicle, read operating instructions. •... -
Page 13: 2001 Turf Utility Gasoline Vehicle Owner's Manual
Vehicle Feature Identification TURF 1 AND TURF 2 WARNING • GASOLINE EXPLOSION / FIRE. • CAN CAUSE SEVERE INJURY OR DEATH. • NO SMOKING, SPARKS, OR OPEN FLAME. • STOP ENGINE, ALLOW TO COOL BEFORE REFUELING. • TURN FUEL VALVE ( ) ON DURING OPERATION. -
Page 14: 2001 Turf Utility Gasoline Vehicle Owner's Manual
Vehicle Feature Identification TURF 6 WARNING WARNING • GASOLINE EXPLOSION / FIRE. • CAN CAUSE SEVERE INJURY OR DEATH. • NO SMOKING, SPARKS, OR OPEN FLAME. ROLLOVER OR FALLING OFF MAY CAUSE DEATH. • STOP ENGINE, ALLOW TO COOL BEFORE REFUELING. •... -
Page 15: 2001 Turf Utility Gasoline Vehicle Owner's Manual
Vehicle Feature Identification TURF 6 OPERATING INSTRUCTIONS • Read Owner's Manual and safety warnings located on dash panel prior to driving. • Study and understand controls. • Make sure wheels are turned in desired direction. • Turn key to “ON” position and be sure nothing is in your path. •... -
Page 16: Pre-Operation Checklist
Pre-Operation Checklist PRE-OPERATION CHECKLIST Each Club Car Turf utility vehicle is thoroughly inspected and adjusted at the factory. However, upon arrival of your new Club Car Turf utility vehicle, you should become familiar with its controls and operation, and care- fully inspect each vehicle to be satisfied that it is in proper working condition before accepting delivery. -
Page 17: Controls And Indicators
Read DANGER and WARNING on page 8. WARNING • BEFORE ALLOWING ANYONE TO DRIVE A CLUB CAR TURF UTILITY VEHICLE, MAKE SURE THE DRIVER IS FAMILIAR WITH ALL CONTROLS AND OPERATING PROCEDURES. • DO NOT TAMPER WITH THE GOVERNOR. DOING SO WILL VOID THE WARRANTY, AS WELL AS DAMAGE THE ENGINE AND OTHER COMPONENTS, AND COULD RESULT IN PROPERTY DAMAGE, PERSONAL INJURY, OR DEATH DUE TO UNSAFE SPEEDS. -
Page 18: 2001 Turf Utility Gasoline Vehicle Owner's Manual
When the handle is in the straight up, or N (NEUTRAL) position, the vehicle will not run. Club Car vehicles operate at reduced speed in reverse. The reverse buzzer will sound as a warn- ing when the Forward/Reverse handle is in REVERSE. -
Page 19: 2001 Turf Utility Gasoline Vehicle Owner's Manual
Controls and Indicators PARK BRAKE PEDAL The park brake pedal is the small raised portion in the upper left corner of the brake pedal. It has the word PARK molded into it and the words PARK BRAKE marked on top of it (Figure 6, Page 16). To set the park brake, depress the brake pedal firmly and tilt the park brake portion of the pedal forward (Figure 7, Page 16). -
Page 20: 2001 Turf Utility Gasoline Vehicle Owner's Manual
OIL LIGHT The gasoline powered Club Car Turf utility is equipped with a low oil warning light, located on the dash panel just above the steering column (Figure 12, Page 18). If the oil warning light comes on, oil should be checked and added to the engine as necessary before continuing to use the vehicle. -
Page 21: Driving Instructions
FUEL/HOUR GAUGE The gasoline powered Club Car Turf utility is equipped with a fuel/hour gauge, located on the dash panel (Figure 12, Page 18). The fuel gauge allows the operator to monitor the fuel level in the vehicle. The hour meter should be used by the trained technician in order to track vehicle usage and determine when periodic service procedures are required. -
Page 22: 2001 Turf Utility Gasoline Vehicle Owner's Manual
Driving Instructions WARNING • TO AVOID THE POSSIBILITY OF LOSING CONTROL OF OR OVERTURNING THE VEHICLE, REDUCE SPEED FOR ADVERSE DRIVING CONDITIONS SUCH AS WET GRASS OR ROUGH TERRAIN. • DO NOT USE THE VEHICLE ON PUBLIC ROADS. IT IS NEITHER DESIGNED NOR INTENDED FOR STREET USE AND SHOULD NOT BE LICENSED FOR USE ON PUBLIC ROADS. -
Page 23: Bed Latch
Bed Latch CAUTION • WHEN STOPPED ON A HILL, USE THE BRAKE PEDAL TO HOLD YOUR POSITION. DO NOT USE THE ACCELERATOR PEDAL. To stop the vehicle, release the accelerator pedal and depress the brake pedal until the vehicle comes to a complete stop. -
Page 24: Prop Rod
Prop Rod VENT FUEL SHUT-OFF VALVE PROP GAS TANK PROP ROD TO CARBURETOR TRACK Crush area. sever e injury Can cause g bed. when closin Stay clear VENT TUBES Figure 15 Prop Rod Figure 16 Fuel Shut-Off Valve PROP ROD Read DANGER and WARNING on page 8. -
Page 25: Towing With The Vehicle
Towing with the Vehicle Compare the calculated value for the total load. Cargo load should never exceed maximum rated capacity. See following WARNING. WARNING • FIRMLY ENGAGE THE PARK BRAKE BEFORE LOADING THE VEHICLE. • DO NOT ALLOW RIDERS IN THE CARGO BED. •... -
Page 26: Transporting On A Trailer
Because towing another Club Car vehicle or trailer can have adverse effects on vehicle handling, be espe- cially cautious when towing with a Club Car Turf utility vehicle. Total vehicle capacity, including the tow vehicle load rating and the gross weight of the vehicle with a trailer being towed should not exceed 800 lb. (363 kg) for the Turf 1, 1200 lb. -
Page 27: Storage
Storage STORAGE Read DANGER and WARNING on page 8. To prepare your vehicle for extended off season storage: 1. Unload the vehicle completely, so that only minimum vehicle weight will be placed on the tires. 2. Store vehicle in a cool place. This will minimize self-discharge of the battery. If the battery appears to be weak, have it charged using an automotive-type 12-volt battery charger rated 10 amps or less. -
Page 28: 2001 Turf Utility Gasoline Vehicle Owner's Manual
Storage TO RETURN THE STORED VEHICLE TO SERVICE 1. Restore fuel system to operation. 1.1. Remove plug from the fuel tank vent nipple and open the fuel shut-off valve (Figure 18, Page 26). Make sure the valve is fully open. A partially closed fuel valve (Figure 19, Page 26) combined with the use of the choke, can result in a fouled spark plug and engine failure. -
Page 29: Maintenance
This will prevent further damage to the vehicle and avoid the possibility of injury due to unsafe conditions. Contact your local Club Car distributor/dealer to perform all repairs and semiannual and annual periodic service. WARNING •... -
Page 30: Periodic Service Schedule
Periodic Service Schedule • Park brake • Reverse warning buzzer • Steering and linkages • Proper acceleration and maximum speed In addition, check the items listed below: • Tires: Visually inspect for wear, damage and proper inflation. • Exhaust system: Check for leaks. •... -
Page 31: Periodic Lubrication Schedule
REGULAR INTERVAL SERVICE RECOMMENDED LUBRICANT PLACE Brake Pedal shaft bearings Dry Moly Lube – Club Car Part No. 1012151 Semiannually by Owner or Trained Technician Brake Linkage and Pivots Dry Moly Lube – Club Car Part No. 1012151 (Every 50 hours of operation). -
Page 32: Engine Oil
Chassis Lube – EP NLGI Grade 2 or Trained Technician (Every 50 hours of operation), Continued: Brake slides Dry Moly Lube – Club Car Part No. 1012151 Check/fill unitized transaxle to plug 27 oz. (.8 liter) 80-90 WT. API Class GL-3 or Annually by Trained level 80-90 WT. -
Page 33: Sae 10W-30/Sae 10W
Vehicle Capacities VEHICLE CAPACITIES LIQUID CAPACITIES GASOLINE VEHICLES Engine Crankcase without filter 32 oz. (.95 liters) Engine Crankcase with filter 38 oz. (1.12 liters) Unitized Transaxle 27 oz. (.8 liters) Gasoline Tank 7 gallons (26.5 liters) TIRE CAPACITIES GASOLINE VEHICLES Turf 1 16-18 psi (110-124 kPa) Turf 2... -
Page 34: Fueling Instructions
Fueling Instructions FUELING INSTRUCTIONS Read DANGER and WARNING on page 8. DANGER • TURN KEY SWITCH TO THE OFF POSITION BEFORE FUELING. • NEVER POUR GASOLINE INTO THE FUEL TANK WHEN THE ENGINE IS HOT OR WHILE IT IS RUNNING. •... -
Page 35: 2001 Turf Utility Gasoline Vehicle Owner's Manual
• DO NOT JUMP START THE VEHICLE. TO CHARGE THE BATTERY, USE AN AUTOMOTIVE-TYPE 12-VOLT CHARGER RATED AT 10 AMPS OR LESS. The battery in a Club Car Turf utility gasoline vehicle is a 12-volt, low maintenance battery that requires infre- quent watering (Figure 23, Page 33). -
Page 36: Accessories
In the event a vehicle is bought used from another individual or from a distributor/dealer, we strongly urge the new owner to re-register the vehicle with Club Car. This will enable us to contact you if the need arises. Please send your name, address, and serial number(s) of the vehicle(s) to Club Car, Inc., P.O. Box 204658, Augusta. -
Page 37: 2001 Turf Utility Gasoline Vehicle Owner's Manual
Vehicle Specifications VEHICLE SPECIFICATIONS SPECIFICATIONS TURF 1 TURF 2 TURF 6 POWER SOURCE Engine: 4 cycle, OHV, 286 cc, 9.0 hp rated., single cylinder, air cooled, with pressure • lubrication system. Engine: 4 cycle, OHV, 351 cc, 11 hp rated., single cylinder, air cooled, with pressure •... -
Page 38: 2001 Turf Utility Gasoline Vehicle Owner's Manual
Vehicle Specifications SPECIFICATIONS TURF 1 TURF 2 TURF 6 49.3 in. 50 in. 49.3 in. Overall Width (125 cm) (127 cm) (125 cm) 48 in. 48 in. 48 in. Overall Height: At Steering Wheel. (122 cm) (122 cm) (122 cm) 65.5 in. -
Page 39: 2001 Turf Utility Gasoline Vehicle Owner's Manual
CLUB CAR’s liability under this limited warranty, or in any action whether based upon warranty, contract, negligence, strict product liability or otherwise, shall be the repair or replacement, at CLUB CAR’s option, of the vehicle or component thereof that CLUB CAR deems to be defective. Replacement shall mean furnishing, during the applicable limited warranty period, a new vehicle or factory-reconditioned vehicle or component thereof which is identical or reasonably equivalent to the warranted product or component at no cost to the purchaser. -
Page 40: 2001 Turf Utility Gasoline Vehicle Owner's Manual
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. 8. INFORMATION: For further information contact WARRANTY SERVICES, CLUB CAR, INC., P.O. Box 204658, Augusta, Georgia 30917- 4658, U.S.A., 706-863-3000. - Page 44 Manual No. 102189807 Edition Code 0800A00000 Turf Utility/Gasoline Club Car, Inc., P.O. Box 204658 Augusta, GA 30917-4658...
