- Page 1 Installation Instructions Professional Style Bottom-Freezer Refrigerators ZICP720 Design Guide With Installation Instructions 49-60469 224D1234P001 07-06 JR...
-
Page 2: Table Of Contents
• Les réparations doivent être faites par un technicien qualifié. PRUDENCE : For Monogram local service in your area, À cause du poids et de la taille de ce réfrigérator et pour réduire call 1.800.444.1845. le risque de blessure et de dommages, IL FAUT TROIS PERSONNES POUR FAIRE L’INSTALLATION CORRECTEMENT. -
Page 3: The Installation Space
Design Guide THE INSTALLATION SPACE DIMENSIONS AND CLEARANCES The installation space must be 71-1/2″. 71-1/2″ 25-3/4″ Case Width 71-1/2" Case Depth Case Width 25-3/4" Case Depth 71-1/2″ Finished Width * Shipping height. The Wall refrigerators can be 2-5/16″ View 24-3/16″ adjusted to fit into a Electrical ″... -
Page 4: 130° Door Swing
Design Guide Frameless Cabinets: The case trim overlaps cabinets at the top and sides. Therefore, frameless cabinets may require filler strips to prevent interference with Refrigerator cabinet door swing. The opening must 23-7/8" From allow for filler strips. Rear of Refrigerator 1"... -
Page 5: 90° Door Swing
Design Guide Frameless Cabinets: The case trim overlaps cabinets at the top and sides. Therefore, frameless Refrigerator cabinets may require Case Trim filler strips to prevent interference with cabinet door swing. The opening must allow for filler strips. 23-7/8" From Rear of Refrigerator 1/4"... -
Page 6: Installation Instructions
Installation Instructions TOOLS REQUIRED MATERIALS REQUIRED • 71″ long 2x4 for Anti-Tip support • Tinsnips to cut banding • 1/4″ copper water line tubing or two GE • Stepladder SmartConnect ™ Refrigerator Tubing kits • Bucket • Two water shut-off valves •... -
Page 7: Step 1, Remove Packaging
Installation Instructions • Remove the four 7/16″ REMOVE PACKAGING bolts securing the straps CAUTION: to the skid. Refrigerator is much heavier at the top than at CAUTION: the bottom—be careful when moving. When using a hand truck, DO NOT handle from side only. ATTEMPT TO ROLL UNIT OFF SKID. -
Page 8: Step 3, Install New Side Trim
Installation Instructions INSTALL NEW SIDE TRIM CAUTION: Handle parts with care to avoid scratching. • Remove the inside case trim on both refrigerators. Foam Spacer Pads • Remove the Phillips head screws from the inside case trim of each product as shown. Remove and discard side trim. -
Page 9: Step 5, Install Anti-Tip Brackets
Installation Instructions INSTALL ANTI-TIP BRACKETS INSTALL ANTI-TIP BRACKETS (cont.) WARNING: • Screws must penetrate at least one inch into ANTI-TIP PRECAUTIONS vertical wall studs. The refrigerator is top-heavy and must be secured to prevent the possibility of tipping forward. • Before pushing the refrigerator into the opening, plug the power cord into the receptacle. -
Page 10: Step 6, Install New Top Trim
Installation Instructions INSTALL NEW TOP TRIM • Remove 2 trim screws from the back side of each corner. Lift off and discard top case trims. Retain screws and corner “L” brackets. • Install the unified top trim by inserting an “L” bracket into each corner. •... -
Page 11: Procedure
Installation Instructions ALTERNATE ANTI-TIP PROCEDURE The refrigerator must be secured to prevent tipping. 3/4″ The anti-tip brackets cannot be used on metal Min. wall studs. Use this Alternate Procedure to secure the refrigerator against tip-over whenever metal wall studs are encountered and there is no soffit. Side View Top Case Trim •... -
Page 12: Trim Strip
Installation Instructions INSTALL CENTER TRIM STRIP Case Trim • Open doors fully. • Starting at the top, press center trim strip over the inside case trims of both refrigerators. • Continue pressing trim until you reach the bottom of U-Shape the case trims. -
Page 13: Panels (If Present)
Installation Instructions REMOVE BOTH GRILLE PANELS (if present) • Remove 3 screws holding the grille panel to the Grille Panel hinge on each side. Lift grille panel off the hinges. Discard both grille panels. Retain screws. Leave hinges in open position. Do not push hinges back. -
Page 14: Step 14, Adjust Door Swing
Installation Instructions ADJUST DOOR SWING NOTE: This refrigerator has a 2-position door stop. When space does not allow the door to swing open Grille Base Wrap fully to 130°, you may change the door swing to a 90° opening. Skip this step if door opening is satisfactory for your installation situation. -
Page 15: Step 16, Connect Power
Installation Instructions CONNECT POWER INSTALL TOEKICK • Check to be sure the power cord is plugged • Install the toekick with 4 screws provided, into the receptacle. one on each side and 2 in the center. Raise Grille Panel IMPORTANT: The toekick must be positioned with Electrical Master Light the vented slots on the top side. - Page 16 NOTE: While performing installations described in this book, safety glasses or goggles should be worn. For Monogram ® local service in your area, call 1.800.444.1845. NOTE: Product improvement is a continuing endeavor at General Electric. Therefore, materials, appearance and specifications are subject to change without notice.
