OWNER'S
MANUAL
Model No. GZFI8033.5
Serial No.
Write the serial number in the
space above for future reference.
Serial Number Decal
(inside tower)
QUESTIONS?
At FreeMotion Fitness, we are
committed to providing com-
plete customer satisfaction. If
you have questions, see HOW
TO CONTACT CUSTOMER
CARE on the back cover of this
manual.
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
Visit our website at
www.freemotionfitness.com
®

Advertisement

Table of Contents
loading

Related Manuals for Freemotion GZFI8033.5

Summary of Contents for Freemotion GZFI8033.5

  • Page 1 Write the serial number in the space above for future reference. Serial Number Decal (inside tower) QUESTIONS? At FreeMotion Fitness, we are committed to providing com- plete customer satisfaction. If you have questions, see HOW TO CONTACT CUSTOMER CARE on the back cover of this manual.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............3 WARNING DECAL PLACEMENT .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precautions before using the strength equipment. 1. Read all instructions in this manual before 9. All users of the strength equipment should using the strength equipment. Use the be instructed to report any injury or strength strength equipment only as described in this equipment irregularity to facility staff imme-...

  • Page 4: Warning Decal Placement

    WARNING DECAL PLACEMENT The decals shown below have been placed on the strength equipment in the indicated locations. If a decal is missing or illegible, see HOW TO CONTACT CUSTOMER CARE on the back cover of this manual and order a free replacement decal.

  • Page 5: Before You Begin

    GZFI8033.5. The serial number can be found reliable product for your club. And the advanced solu- on a decal attached to the strength equipment (see the tions to isolating individual muscle groups make the front cover of this manual).

  • Page 6: Adjustments

    ADJUSTMENTS This section explains how to adjust the strength equipment. Make sure all parts are properly tightened each time the strength equipment is used. Replace any worn parts immediately. ADJUSTING THE RESISTANCE To change the amount of resistance for your workout, insert the weight pin into the desired weight.
  • Page 7 ADJUSTING THE CAM RESISTANCE The CAM resistance can be adjusted to either a 1:1 ratio or a 1:2 ratio to the weight stack. At a 1:1 ratio, the resistance will be equal to the weight of the weight stack. At a 1:2 ratio, the resistance will be equal to one-half the weight of the weight stack.

  • Page 8: Maintenance

    Personnel must record and report any accident. To maintain the strength equipment’s warranty, use only FREEMOTION EPIC parts for repair or replacement. If there are any questions or concerns, see HOW TO CONTACT CUSTOMER CARE on the back cover of this manual.
  • Page 9 CABLE GUARDS MONTHLY 1. Grips: Check for alignment periodically to ensure that cable • Check and replace as needed. guards are not rubbing on the cable and that they are performing their intended duty. If the alignment is not YEARLY OR AS REQUIRED proper, loosen the bolt slightly, readjust the cable guard as necessary, and retighten the bolt.
  • Page 10 CABLE ADJUSTMENTS CAUTION: After making any cable adjustment, pull ADDITIONAL ADJUSTMENTS the handle using a light load and have someone Top Weight Adjustment— make sure that the cable is not derailed from a pulley or rubbing on a guard (see CABLE GUARDS on Tools required: 5/32”...
  • Page 11 SERVICING THE WEIGHT STACK Servicing the weight stack involves replacing the two holes. Tighten the set screws equally until they guide bushings and weight insert in the top weight. To contact the cable. Then, tighten each screw order these parts, see HOW TO CONTACT CUS- alternately 1/4 turn, until all are set to 85 TOMER CARE on the back cover of this manual.

  • Page 12: Cable Diagram

    CABLE DIAGRAM The cable diagram shows the proper route of the cable. Use the diagram to make sure that the cable and the cable guards have been assembled correctly. If the cable has not been correctly routed, the strength equipment will not function properly and damage may occur.
  • Page 13 NOTES...

  • Page 14: Part List

    PART LIST—Model No. GZFI8033.5 R0206A If replacement parts are needed, or if parts are missing or damaged, see HOW TO CONTACT CUSTOMER CARE on the back cover of this manual. Key No. Qty. Description Key No. Qty. Description Base Pivot Bushing...

  • Page 15: Exploded Drawing

    EXPLODED DRAWING—Model No. GZFI8033.5 R0206A 41 79 56 55...

  • Page 16: How To Contact Customer Care

    PART LIST and the EXPLODED DRAWING on pages 14 and 15 of this manual). Customer Care: 1-800-201-2109, Monday–Friday, 8 a.m.–5 p.m. Mountain Time FreeMotion Fitness, Inc. • 1096 Elkton Dr., Suite 600 • Colorado Springs, CO 80907 Part No. GZ7340 R0206A...
