Ramsey Electronics Model No.
Have you ever been so frustrated with the range of your remote
that you go to the extreme of rearranging your entertainment
room just to make it work? Tired of having to bounce your IR
remote off of ceilings and walls? Do you want to run your
system from another room? Here is the answer to your prayers!
Extend the range of your remote controls as far as you need;
it's only limited by the length of wire you use!
IR receiver module with sensitive element can receive your
remote control up to 36 feet away before re-broadcasting it.
The RR1 reconstitutes the receive signal using a PIC micro
controller, restores noisy or weak signals, and then re-broadcasts
the IR remote signals to your components via a long wire (tested
over 500 feet!) to a high-efficiency IR LED.
Extend the range of your remote control around corners or down
floors by running a wire to an IR LED in front of the components
you wish to control.
Works with almost any remote control (38 kHz carrier), does not
need to be programmed.
Will operate from 8V to 16V AC or DC. Use our AC125 wall adapter
for long operation.
LED indicator lets you know when you are receiving an IR signal
or not.
RR1

Advertisement

Table of Contents
loading

Summary of Contents for Ramsey Electronics RR1

  • Page 1 36 feet away before re-broadcasting it. • The RR1 reconstitutes the receive signal using a PIC micro controller, restores noisy or weak signals, and then re-broadcasts the IR remote signals to your components via a long wire (tested over 500 feet!) to a high-efficiency IR LED.
  • Page 2 Ramsey Electronics publication No. MRR1 Rev 1.1 First printing: January 2002 MRW COPYRIGHT 2002 by Ramsey Electronics, Inc. 590 Fishers Station Drive, Victor, New York 14564. All rights reserved. No portion of this publication may be copied or duplicated without the written permission of Ramsey Electronics, Inc.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS Introduction ...........4 Theory of Operation ......5 Learn As You Build Strategy ....7 Parts List ..........9 Assembly Instructions ......10 Testing the RR1 ........13 Using your RR1 ........14 Troubleshooting Guide ......15 RR1 Schematic ........16 RR1 Parts Layout ........17 Specifications ........18 Warranty ..........19...
  • Page 4: Introduction

    RR1 works. This will better help you understand what you are about to build. As simple as it may look, the RR1 is one of the best remote repeaters money can buy thanks to some specialized technology we have added to restore normally unusable signals.
  • Page 5: Theory Of Operation

    RR1 THEORY OF OPERATION The RR1 may look simple but there is actually quite a lot being done inside each one of the parts. Many individual components are packed inside of the IR receiver part (U2) itself; so many in fact that if it was built up with discrete components, it would never fit in this little kit case.
  • Page 6 LED on and off at 38 kHz during the entire send sequence. The LED may be on only about 50% of the total time to send the data. To achieve the maximum transmission range and peak performance from the system, we’ve cranked up the current a bit to get More Power!!!! RR1 • 6...
  • Page 7: Learn As You Build Strategy

    (1). The part is then soldered securely to the board (2-4) and the remaining lead length is then clipped off (5). Notice how the solder joint looks on close up, clean and smooth with no holes or sharp points (6). RR1 • 7...
  • Page 8 If a problem does occur, the manual will lead you through step by step in the troubleshooting guide until you find the problem and are able to correct it. RR1 • 8...
  • Page 9: Parts List

    PARTS SUPPLIED WITH YOUR RR1 KIT Capacitors 3 0.1 uF ceramic capacitors (marked .1 or 104 or 100 nF) [C2,3,4] 2 10 uF electrolytic capacitors [C1,5] 1 1000 uF electrolytic capacitor [C6] Resistors 1 1K ohm resistor (brown-black-red) [R2] 1 100 ohm resistor (brown-black-brown) [R1]...
  • Page 10: Assembly Instructions

    RR1 REMOTE REPEATER KIT ASSEMBLY Assembly of the RR1 is straight forward but it does require some time and patience. To get our bearings, we will start with mounting the power jack and move on from there. It serves as a good reference point for the other parts.
  • Page 11 20. Install S1, the power switch. Solder only one pin until you are sure the switch is flush to the board. If it is cocked at an angle it will not lineup with the case panel properly. RR1 • 11...
  • Page 12 21. The IR LED wiring offers you a bit of flexibility to custom match the RR1 to your application. You will need to determine how long of a wire you will actually need to fit the job at hand and then cut it to length. The 8 foot piece of wire that is supplied with the kit is more than enough for most of the common component cases available today (we didn’t want to...
  • Page 13: Testing The Rr1

    Sometimes the walls near you will reflect enough IR for the equipment to detect so it would be hard to verify if the RR1 is working. Now turn on the RR1 and press some remote control buttons. You should see the...
  • Page 14: Using Your Rr1

    We thought this might be a good spot for some mounting ideas that may help with the usage of your RR1. Primarily you will want to put the RR1 in a discrete location that isn’t too obtrusive. It should be where you can easily point your remote control’s IR data in a fashion that is unimpeded by other ob-...
  • Page 15: Troubleshooting Guide

    38 kHz. There are a variety of ranges available, but 38 kHz is by far the most common. Most consumer components operate at 38 kHz. The RR1 ONLY works 38 kHz carrier signal remotes. PROBLEM: The LED lights, but the IR LED seems to have no effect.
  • Page 16: Rr1 Schematic

    RR1 • 16...
  • Page 17: Rr1 Parts Layout

    RR1 PARTS PLACEMENT DIAGRAM RR1 • 17...
  • Page 18: Specifications

    Max effective BAUD rate: 2400 bps – standard for remotes. • IR receiver module has an effective pick-up range of 11 meters (36 feet!). • Max IR LED (D3) wire extension length: Unknown!! Tested over 750 feet and still going! RR1 • 18...
  • Page 19: Warranty

    But on rare occasions a sour component can slip through. All our kit parts carry the Ramsey Electronics Warranty that they are free from defects for a full ninety (90) days from the date of purchase. Defective parts will be replaced promptly at our expense. If you suspect any part to be defective, please mail it to our factory for testing and replacement.
  • Page 20 RR1 REMOTE REPEATER KIT Quick Reference Page Guide Introduction ..........4 Theory of Operation ......5 Parts List ..........9 Assembly Instructions ......10 Testing the RR1 ........13 Using your RR1 ........14 RR1 Schematic ........16 Specifications ........18 Warranty ..........19 REQUIRED TOOLS • Soldering Iron Ramsey WLC100 •...
