harman/kardon
HKTS 200 SUB
(HKTS 20/HKTS 30/HKTS 60 SUBWOOFER)
SERVICE MANUAL
harman/kardon, Inc.
8500 Balboa Blvd.
Released 2010
Northridge, CA. 91329
Rev1 3/2011
Discontinued XXXX

Advertisement

Table of Contents
loading

Related Manuals for Harman Kardon HKTS 200 SUB

Summary of Contents for Harman Kardon HKTS 200 SUB

  • Page 1 HKTS 200 SUB (HKTS 20/HKTS 30/HKTS 60 SUBWOOFER) SERVICE MANUAL harman/kardon, Inc. 8500 Balboa Blvd. Released 2010 Northridge, CA. 91329 Rev1 3/2011 Discontinued XXXX...

  • Page 2: Table Of Contents

    SEMICONDUCTOR PINOUTS ....……………..………..………. .19 SCHEMATIC DIAGRAMS ..... . ………………………..……. .37 HKTS 200 SUB SPECIFICATIONS Amplifier Power (RMS)
  • Page 3 harman/kardon HKTS200SUB HKTS200SUB Amplifier Specifications Parameter Specification Unit QA Test Limits Test Conditions, Notes, and Comments Amplifier Section Type (Class AB, D, other) No external heat sink required. Digital 192 kHz ternary mode PWM. Load Impedance (speaker) Minimum rated load impedance Rated Output Power 50 Hz THD @ Rated Power...
  • Page 4 harman/kardon HKTS200SUB Parameter Specification Unit QA Test Limits Test Conditions, Notes, and Comments Power supply Half bridge, with auxiliary fly back standby supply. Type SMPS 1/2 rated power continuous, and rated power for > 1 Minute, 25 degree ambient, rated resistive load measured on bench top.

  • Page 5: Packaging

    harman/kardon HKTS200SUB PACKAGING...

  • Page 6: Controls

    harman/kardon HKTS200SUB HKTS200SUB Rear-Panel Connections PL0004-01001 the trigger signal ceases. (This will occur even when the Power On Mode Subwoofer Level Control: Use this control to adjust the HKTS200SUB’s Switch is in the AUTO position.) volume. Turn clockwise to increase the volume; turn counterclockwise to decrease the volume.

  • Page 7: Connections

    harman/kardon HKTS200SUB Left Front Center Right Front Front Left Center Front Right Speaker Cable Speaker Cable Speaker Cable (White Bands) (Green Bands) (Red Bands) – – – FRONT SURROUND CENTER + – + – RIGHT LEFT LFE OUT + – + –...
  • Page 8 harman/kardon HKTS200SUB Left Front Center Right Front Front Left Center Front Right Speaker Cable Speaker Cable Speaker Cable (White Bands) (Green Bands) (Red Bands) – – – FRONT SURROUND CENTER + – + – RIGHT LINE-LEVEL LEFT OUTPUTS + – + –...
  • Page 9 harman/kardon HKTS200SUB Receiver FRONT SURROUND CENTER + – + – RIGHT LFE SUB TRIGGER LEFT OUTPUT + – + – Subwoofer Trigger Cable (Black Ends) PL0004-01001 Connecting to a Trigger Voltage Source If your preamp/processor or another audio/video component has a trigger NOTE: Please do not connect the subwoofer ON/OFF trigger cable to the voltage connection that supplies between 3 and 30V (AC or DC), connect Remote Control Output (IR Out) of your home cinema system or surround...

  • Page 10: Troubleshooting

    harman/kardon HKTS200SUB Operation Troubleshooting Turning the Subwoofer On and Off If there is no sound from any of the speakers: Set the HKTS200SUB’s Power Switch to the ON position. • Check that the receiver/amplifier is on and a source is playing. •...
  • Page 11 harman/kardon HKTS200SUB Test Set Up and Procedure Equipment needed: • Function/signal generator/sweep generator • Integrated amplifier • Multimeter Initial Control Settings: • Power Switch OFF; Bass Mode OFF • Level MIN (Full CCW) • Phase, Auto/On switches do not matter General Unit Function (UUT = Unit Under Test) 1) From the signal generator, connect one line level (RCA) cable to the Subwoofer Line Level Input jacks L/R on the UUT.
  • Page 12 harman/kardon HKTS200SUB BPVA00032-0001-ABS-AMP Rear Cover GALA00113-0001-AL 5052-Heat sink DSS100017-0001-Nylon66-SPACER SUPPORT-E*2PCS HNT009540-1230-NUT-E*7PCS HSB053083-1120-Screw-E*2PCS XBT090001-M000-BUTYL TAP TPS220200-0408-SMPS APEA00690-4001-PCBA IVEA00168-0001-SEAL EVA -OBAE*2PCS DSS100043-0001-Nylon66-SPACER SUPPORT-E*4PCS GCUA00023-0001- BRASS-RCA Shield Cap IVEA00168-0002-SEAL EVA -OBAE*2PCS IVHA12002-0001-SEAL PE PAD-OBAE*2PCS IVHA12002-0002-SEAL PE PAD-OBAE*2PCS DKNA01009-0001-Small knob HSP043083-3100-Screw-E*2PCS HSP140054-3100-Screw-E*1PC GALA00112-0002-AL-Rear Plate HSP053083-3200-Screw-E*4PCS MSW108001-0015 -Power Switch IVAA02071-0001 Wire Tie...
  • Page 13 harman/kardon HKTS200SUB...

  • Page 14: Block Diagram

    harman/kardon HKTS200SUB HKTS200SUB Subwoofer Block Diagram Two 2-pos Slide Trigger Input, plug Switch’s and level detection NTC Temperature Analog to ADC, for Sensor Input Buffer (w/ (Renesas R8C/1B Series, 8 kB flash) standby potentiometer for volume (8 MHz) Power Stage Fault ctrl) Detection Circuit ADC (AK5358A, 24...
  • Page 15 CAM Products 2000(TM): harman/kardon HKTS200SUB...
  • Page 16 CAM Products 2000(TM): harman/kardon HKTS200SUB...
  • Page 17 CAM Products 2000(TM): harman/kardon HKTS200SUB...

  • Page 18: Electrical Parts List

    harman/kardon HKTS200SUB HKTS200SUB Electrical Parts list Part number Description Qty Reference Designator MAIN PCB Resistors QCF015030-0000 GP CHIP RES. 0 OHM 1/10W 5% 0603 R77 R78 QCF011030-1801 GP CHIP RES. 1.8K OHM 1/10W 1% 0603 R2 R5 R6 R10 R13 R20 R27 R28 R29 R34 QCF011030-1002 GP CHIP RES.
  • Page 19 harman/kardon HKTS200SUB Part number Description Qty Reference Designator RCI111733-1102 3P AP1117E33LA SOT223 Low Drop Pos Adjustable/Fixed-Mode Regulator RCI111750-0001 3P LM1117MPX-5.0 SOT-223 Low-Dropout Linear Regulator RCI000516-0001 IC 36P STA516B SO36 60 V 6 A quad power half bridge RCP000856-0001 GP TRANSISTOR PNP BC856B SOT-23 T3 T8 RCP003906-0002 CHIP TRANSISTOR 3P PNP MMBT3906 PNP SOT23...
  • Page 20 harman/kardon HKTS200SUB...
  • Page 21 harman/kardon HKTS200SUB T2,T6 T4,T5,T9,T10...
  • Page 22 harman/kardon HKTS200SUB T3,T8 D1,D6...
  • Page 23 harman/kardon HKTS200SUB REJ09B0252-0110 R8C/1A Group, R8C/1B Group Hardware Manual RENESAS 16-BIT SINGLE-CHIP MICROCOMPUTER M16C FAMILY / R8C/Tiny SERIES All information contained in these materials, including products and product specifications, represents information on the product at the time of publication and is subject to change by Renesas Technology Corp.
  • Page 24 harman/kardon HKTS200SUB R8C/1A Group, R8C/1B Group REJ09B0252-0110 SINGLE-CHIP 16-BIT CMOS MICROCOMPUTER Rev.1.10 Mar 17, 2006 Overview These MCUs are fabricated using the high-performance silicon gate CMOS process, embedding the R8C/ Tiny Series CPU core, and is packaged in a 20-pin molded-plastic LSSOP, SDIP or a 28-pin plastic molded- HWQFN.
  • Page 25 harman/kardon HKTS200SUB R8C/1A Group, R8C/1B Group 1. Overview PIN assignments (top view) P3_5/SSCK/SCL/CMP1_2 P3_4/SCS/SDA/CMP1_1 P3_3/TCIN/INT3/SSI00/CMP1_0 P3_7/CNTR0/SSO/TXD1 P1_0/KI0/AN8/CMP0_0 RESET P1_1/KI1/AN9/CMP0_1 XOUT/P4_7 P4_2/VREF VSS/AVSS P1_2/KI2/AN10/CMP0_2 XIN/P4_6 P1_3/KI3/AN11/TZOUT VCC/AVCC P1_4/TXD0 MODE P4_5/INT0/RXD1 P1_5/RXD0/CNTR01/INT11 P1_6/CLK0/SSI01 P1_7/CNTR00/INT10 NOTE: 1. P4_7 is an input-only port. Package: PRDP0020BA-A (20P4B) Figure 1.5 Pin Assignments for PRDP0020BA-A Package (Top View)
  • Page 26 harman/kardon HKTS200SUB R8C/1A Group, R8C/1B Group 1. Overview Pin Functions Table 1.5 lists Pin Functions, Table 1.6 lists Pin Name Information by Pin Number of PLSP0020JB-A, PRDP0020BA-A Packages and Table 1.7 lists Pin Name Information by Pin Number of PWQN0028KA- B Package.
  • Page 27 harman/kardon HKTS200SUB R8C/1A Group, R8C/1B Group 1. Overview Table 1.6 Pin Name Information by Pin Number of PLSP0020JB-A, PRDP0020BA-A Packages I/O Pin Functions for Peripheral Modules Clock Control Port Serial Synchronous C bus Number Interrupt Timer Interface Serial I/O with Converter Interface Chip Select...
  • Page 28 harman/kardon HKTS200SUB R8C/1A Group, R8C/1B Group 1. Overview Table 1.7 Pin Name Information by Pin Number of PWQN0028KA-B Package I/O Pin Functions for Peripheral Modules Clock Control Port Serial Synchronous C bus Number Interrupt Timer Interface Serial I/O with Converter Interface Chip Select XOUT...
  • Page 29 harman/kardon HKTS200SUB CS5343/4 98 dB, 96 kHz, Multi-Bit Audio A/D Converter Features General Description Advanced Multi-Bit ∆Σ Architecture The CS5343/4 is a complete analog-to-digital converter for digital audio systems. It performs sampling, analog- 24-bit Conversion to-digital conversion, and anti-alias filtering, generating Supports Audio Sample Rates Up to 108 kHz 24-bit values for both left and right inputs in serial form at sample rates up to 108 kHz per channel.
  • Page 30 harman/kardon HKTS200SUB 1. PIN DESCRIPTIONS CS5343/4 SDOUT SCLK AINR LRCK MCLK FILT+ AINL Pin Name Pin # Pin Description Serial Audio Data Output (Output) - Output for two’s complement serial audio data. Also selects Master SDOUT or Slave Mode. SCLK Serial Clock (Input/Output) - Serial clock for the serial audio interface.
  • Page 31 harman/kardon HKTS200SUB October 1996 Revised June 2000 NC7SZ04 TinyLogic  UHS Inverter General Description Features The NC7SZ04 is a single inverter from Fairchild’s Ultra Space saving SOT23 or SC70 5-lead package High Speed Series of TinyLogic  . The device is fabricated Ultra High Speed;...
  • Page 32 harman/kardon HKTS200SUB STA309A Multi-channel digital audio processor with DDX® Features ® 8 channels of 24-bit DDX TQFP64 >100 dB SNR and dynamic range Selectable 32 kHz - 192 kHz input sample rates Advanced PopFree operation 6 channels of DSD/SACD input Advanced AM interference frequency Digital gain/attenuation +58 dB to -100 dB in switching and noise suppression modes...
  • Page 33 harman/kardon HKTS200SUB STA309A Block diagram Block diagram Figure 1. Block diagram SCL SDA OUT1A/B LRCKI OUT2A/B BICKI SERIAL OUT3A/B OVERSAMPLING SDI12 DATA OUT4A/B SDI34 SYSTEM OUT5A/B SDI56 CONTROL OUT6A/B SDI78 OUT7A/B OUT8A/B VARIABLE TREBLE, VOLUME CHANNEL OVER- BASS, EQ LIMITING MAPPING LRCKO SAMPLING...
  • Page 34 harman/kardon HKTS200SUB Pin connections STA309A Pin connections Figure 3. Pin connection (top view) 59 58 57 56 53 52 51 50 49 OUT2_A OUT2_B SDI_78 OUT3_A SDI_56 OUT3_B SDI_34 OUT4_A SDI_12 OUT4_B LRCKI OUT5_A BICKI OUT5_B RESET OUT6_A PLLB OUT6_B 17 18 19 20 21 22 23 24 25 26 28 29 30 31 32...
  • Page 35 harman/kardon HKTS200SUB STA309A Pin connections Table 2. Pin description (continued) Type Name Description CMOS input buffer with Select address (I pull-down Bidirectional buffer: 5-V tolerant TTL schmitt trigger Serial data (I input; 3.3-V capable 2mA slew-rate controlled output. 5-V tolerant TTL schmitt Serial clock (I trigger input buffer 5-V tolerant TTL schmitt...
  • Page 36 harman/kardon HKTS200SUB Pin connections STA309A Table 2. Pin description (continued) Type Name Description 3.3-V capable TTL 16mA OUT2A PWM channel 2 output A output buffer 3.3-V capable TTL 16mA OUT1B PWM channel 1 output B output buffer 3.3-V capable TTL 16mA OUT1A PWM channel 1 output A output buffer...
  • Page 37 harman/kardon HKTS200SUB...
  • Page 38 Vref 7 9 10 NOTE the SMPS power supply should be replaced in its entirety and the schematic is supplied only for reference 120v part# TPS220200-0407 230v part# TPS220200-0408 HYS3B210-CS harman/kardon HKTS200SUB...
  • Page 39 HKTS200SUB (DNP) +3.3V +3.3V 100nF 100nF 1.8k harman/kardon 100nF EAPD EAPD 1.2nF (DNP) PCB_HOLDER 1.8k 1.2nF NC7SZ04 8.192MHz 2N3904 100nF 100pF 22uF 22pF 22pF 10uF OUT2A +3.3V 10uF 100nF OUT2B 100pF 2.7k VDD3 10uF 22uF 22pF PDN_ctr 100nF VDD3 +3.3V 100nF 49.9k C100...
