5. Select the one Network Name(SSID) in the list.
• SSID: SSID (Service Set Identifier) is a name that identifies a
wireless network. Access points and wireless devices attempting
to connect to a specific wireless network must use the same
SSID. The SSID is case-sensitive.
• Operation Mode: Operation Mode refers to the type of wireless
connections. (See "Wireless network name and Network Key" on
page 1.)
- Ad-hoc: allows wireless devices to communicate directly
with each other in a peer-to-peer environment.
- Infrastructure: allows wireless devices to communicate with
each other through an access point.
If your network's Operation Mode is Infrastructure, select the
SSID of the access point. If the Operation Mode is Ad-hoc,
select the machine's SSID. Note that "airportthru" is the default
SSID of your machine.
6. Click Next.
If wireless security setting window appears, enter the registered
password (network key) and click Next.
7. The confirmation window appears, please check your wireless setup.
If the setup is right, click Apply.
8. Click OK.
Disconnect the network cable (standard or crossover). Your
machine should then start communicating wirelessly with the
network. In case of Ad-hoc mode, you can use a wireless LAN
and wired LAN simultaneously.
Now go to "Installing network connected machine's driver" on
page 31.
RESETTING FACTORY DEFAULT VALUES
Should it become necessary to reset the Samsung printer to its factory
default settings please use the following steps. Connect the printer to your
network, or you may connect the printer directly to a computer using the
special network cable.
If you cannot connect the printer to a computer from its former network
it must be temporarily assigned to a new Ad-Hoc network to access
the SyncThru web page. After you have established a direct link to the
printer, using the special network cable, follow these instructions to
reset the printer to the factory defaults.

Resetting the printer to factory default settings

(Windows)
1. Connect the special network cable between the printer and the PC.
2. Open a browser such as Internet Explorer and enter the IP address of
the printer. The printer's SyncThru™ Web Service page will open.
3. Select Network Settings in the top menu bar.
4. Select Reset in the left side bar, and select the Clear button next to
Factory Default (or Network). Click OK in each of the following three
windows that pop up.
5. Disconnect the printer from the network, recycle the power, and print a
Network Configuration Report to confirm the reset. This will reset all the
parameters and the printer will no longer be on the network.
Resetting the printer to factory default settings
(Macintosh)
1. Connect the special network cable between the printer and the
Macintosh.
2. Open System Preferences and select Print & Fax settings. Select the
printer you want to reset, opening the Print Queue, and select the
Utility icon in the top menu bar. Safari will open the printer's
SyncThru™ Web Service page.
3. Select Network Settings in the top menu bar.
4. Select Reset in the left side bar, and select the Clear button next to
Factory Default (or Netowrk). Click OK in each of the following three
windows that pop up.
5. Disconnect the printer from the network, recycle the power, and print a
Network Configuration Report to confirm the reset. This will reset all the
parameters and the printer will no longer be on the network.

Network parameter setting

You can also set up the various network settings through the network
administration programs such as SyncThru™ Web Admin Service and
SyncThru™ Web Service.

COMPLETING THE INSTALLATION

After you have installed your Samsung wireless network printer, print
another copy of the Network Configuration Report and keep it for future
reference. You are now ready to use your new Samsung wireless printer on
your network.
Wireless network setup_ 8
