Counterflow Gas or Oil Heating Appliance
Owners Manual/Installation Instructions
CMF2 80-PG Convertible (65, 75, and 85 KBTU/H Inputs),
CMF2 80-PO Convertible (65, 75, and 85 KBTU/H Inputs)
Read all instructions carefully before beginning the installation. Read all labels and tags
on the furnace carefully and follow all precautions outlined on those labels and tags.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
!
WARNING:
Improper installation, alteration, ser-
vice or maintenance can cause injury
or property damage. Refer to this
manual for assistance or consult a
qualified installer, service agency, or
the gas supplier for additional infor-
mation.
FOR YOUR SAFETY
WHAT TO DO IF YOU
SMELL GAS
• Do not try to light any appliance.
• Do not touch any electric switch; do not
use any phone in your building.
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier,
call the fire department.
Rated
CMF2-PG
BTUH
80 CONV.
Input
75,000
Output
56,000
GENERAL
CMF2 furnaces are high quality, direct vent
furnaces used for manufactured housing, rec-
reational vehicle, and residential
These furnaces are offered in either power gas
(designated by PG) or power oil (designated by
PO) models. The power gas models are de-
signed for operation with either natural or pro-
pane (LP) gas.
The CMF2 series is convertible from power oil
to power gas, and vice versa. Furthermore, the
firing rate of the CMF2 80 Convertible Series
can be changed using a certified NORDYNE
conversion kit field-installed by a qualified service
technician. Refer to the "Firing Rate Conversion"
section later in these instructions for more
information on the firing rate change.
These furnaces are certified to the UL307
standards (UL 307A for oil models; UL 307B for
gas models), and can be installed in a variety of
applications, as shown in Table 1. This furnace
is not to be used for temporary heating of
buildings or structures under construction.
This furnace must be installed by a quali-
fied installing agency and in accordance
with applicable local codes and ordi-
nances that govern this type of equip-
ment. Failure to properly install the fur-
nace, base assembly, and venting sys-
tem as described herein may damage the
equipment and/or the home, can create a
fire or asphyxiation hazard, violates U.S.
CMF2-PO
listing requirements, and will void the
80 CONV.
warranty. This furnace is NOT approved
for installation with split system air con-
75,000
ditioning. Use a NORDYNE packaged air
60,000
conditioning system.
!
WARNING:
applications.

Advertisement

Table of Contents
loading

Summary of Contents for Nordyne CMF2 80-PG Convertible

  • Page 1 Counterflow Gas or Oil Heating Appliance Owners Manual/Installation Instructions CMF2 80-PG Convertible (65, 75, and 85 KBTU/H Inputs), CMF2 80-PO Convertible (65, 75, and 85 KBTU/H Inputs) Read all instructions carefully before beginning the installation. Read all labels and tags on the furnace carefully and follow all precautions outlined on those labels and tags.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS INSTALLATION REQUIREMENTS ................... 3 Equipment Check ......................... 3 Requirements and Codes ....................3 Important Note ........................3 Combustion Air and Ventilation Requirements ..............4 Venting Requirements – Manufactured Housing Installations ........... 4 Venting Requirements – Residential Installations ............... 5 Unit Location and Clearance Requirements ...............
  • Page 3: Installation Requirements

    Base Used Exhausted By Manufactured MA-100 or MA-200 NORDYNE SRJ Housing or Universal Base Roofjack Only Recreational Vehicle MA-100 or MA-200 NORDYNE SRJ Roofjack or † Residential Universal Base an Existing Chimney* CB-200A Cottage NORDYNE SRJ Roofjack or † Residential Base...
  • Page 4: Combustion Air And Ventilation Requirements

    bedroom(s), a carbon monoxide de- b. Be either hard-wired or battery pow- tector and alarm shall be placed in the ered or both; and living area outside the bedroom(s). c. Shall comply with NFPA 720 (2005 The carbon monoxide detector shall Edition).
  • Page 5: Venting Requirements - Manufactured Housing Installations

    result in safety and performance related problems. Some examples of chemical WARNING: contaminants are chlorine, fluorine, and sulfur, which can be found in a wide variety of some When venting through a chimney, check common commercial and household products. the chimney for soot, leaks, obstruc- tions, and proper installation.
  • Page 6 applicable codes to determine whether or not a It is recommended that the furnace flue serve barometric damper can be used for your CMF2 no other appliances. When the chimney serves power oil furnace installation. The barometric only the furnace, the flue area must be sized damper used must be installed such that air according to all applicable codes.
  • Page 7: Unit Location And Clearance Requirements

    (g) If improper venting is observed during any (d) Follow the lighting instructions. Place the of the above tests, the venting system appliance being inspected in operation. must be corrected. Adjust thermostat so appliance shall oper- ate continuously. Unit Location and Clearance to Adjacent Material Requirements (e) Test for draft hood equipped appliance The unit must be installed in a level position.
  • Page 8: Ma-200 Base Installation

    Cut the opening for the feeder duct 14-1/8" x 14- the feeder duct. If using the combustion air duct, 1/8" in flooring (cutting opening 1" larger all the select and knock out the combustion air open- way will allow the flanges on the underside of the ing to be used.
  • Page 9: Damper Installation

    Open the access door. Fasten the front of the When the rectangular combustion air duct is to furnace and the base to the floor with #8 x 1/2" be used, install the combustion air duct through long sheet metal screws. the selected knockout in the base.
  • Page 10: Closet Installation Of The Furnace

    for information on ordering this base. For or side wall), the opening is to be provided installation, refer to the instructions that are with means to prevent its inadvertent clo- provided with the CB-200A base kit. sure by a flat object placed over the open- ing.
  • Page 11 louvered door must be used having a F. Noncombustible pans having one inch minimum 200 square inch free area open- upturned flanges are located beneath ing directly in line with openings in the openings in a floor return duct system. furnace door.
  • Page 12 3 FEET MIN. ROOF JACK ASSY. ROOF CAP ASSY. DRAW BAND FLEX DUCT CEILING TRIM COLLAR VENT PIPE DRAW BAND CONNECTOR CAUTION MAINTAIN 2 1/2" MINIMUM CLEARANCE BETWEEN FLUE PIPE AND FLEX DUCT. FAILURE TO COMPLY WITH THIS RESTRICTION COULD CAUSE EQUIPMENT DAMAGE.
  • Page 13: Chimney Installation

    Extend the vent pipe down to engage the locking NFPA 54 (National Fuel Gas Code) and utility slot with the screw in the top of the furnace flue regulations. To install the gas supply piping, pipe. Turn to lock and tighten the screw. All joints connect a separate gas line from the gas meter and connections should be inspected before to the burner with a manual shut-off valve...
  • Page 14: Oil Piping Installation - Po Series Only

    Locate the storage tank conveniently near the CAUTION: home. For above ground fuel tank installations, the tank may rest three to four inches off the ground. Fuel tanks may also be buried if prop- The furnace and its appliance main gas erly coated to resist corrosion.
  • Page 15 Figure 13. Wiring Diagram...
  • Page 16: How To Eliminate Air Leaks

    4. Run the line where it will not be subject to with wiring of the same material, gauge, and damage. Also make bends gradually and temperature rating. avoid kinks which might restrict oil flow. Line Voltage Requirements 5. Open the burner access door. Connect Before proceeding with the electrical connec- the oil line to the intake port on the pump.
  • Page 17: Room Thermostat Connections

    If the limit will not reset, continues to Connect R to one of the low voltage trip, or the blower does not function, notify your terminals on the burner. NORDYNE Distributor or Service PRO Connect W to the other low voltage terminal immediately. on the burner.
  • Page 18: Maintenance

    MAINTENANCE D. Do not use this appliance if any part has been under water. Immediately call a quali- Air Filters fied service technician to inspect the ap- Air filters should be inspected and cleaned pliance and to replace any part of the monthly.
  • Page 19: Checking The Input Of The Furnace

    Firing Rate Natural Gas Natural Gas LP Gas LP Gas Time Burner Input Orifice Time Per Rev.* Orifice Per Rev.** Designation (BTUH) Number (sec) Number (sec) Gas Gun-65-DI-S 65,000 Gas Gun-75-DI-S 75,000 Gas Gun-90-DI-S 85,000 * There times are based on natural gas at an average of 1,000 BTU per cubic foot, a burner manifold pressure of 3.5 in WC, and a meter dial size of 1 cubic foot.
  • Page 20: Gas Burner Controls

    Regulator Converter Figure 16. Natural Gas Configuration Combustion Blower Centrifugal Switch Determine which pressure, the inlet gas or The electric motor for the blower which supplies manifold pressure, you want to measure. combustion air to the burner is equipped with a centrifugal switch wired in series with the burner With a 3/16”...
  • Page 21: Adjusting The Burner

    1/8 turn, and replace the black cover onto 3. Disconnect gas burner electric cord, gas the converter top to protect the threads. piping to burner, and thermostat leads. 11. Reinstall the burner assembly into the 4. Remove three (3) hexagon nuts holding furnace.
  • Page 22: Lighting And Operating Instructions For Cmf2 Po Oil Burners

    8.0% to 9.0% for natural gas and 9.0% to 10.0% and release the reset button. The lockout time will be extended to 4 for LP gas. The burner should run quietly. For high altitude operation (altitudes greater minutes. than 2,000 feet), the input should be de-rated by 4% for each 1,000 feet above sea level by If prime is not established within the reducing the orifice size or decreasing the...
  • Page 23: Firing Rate Conversion

    90,000 BTU/hr using the appropriate certified when the temperature fan switch opens. NORDYNE conversion kit installed by a NORDYNE distributor or Service PRO. See the The control will close the gas valve, if the Replacement Parts Listing for the appropriate presence of flame is not or no longer detected.
  • Page 24: Adjusting Heat Distribution

    Once flame is established, the ignition CAUTION: remains on 10 seconds to ensure flame stability. It then turns off. (interrupted Label all wires prior to disconnection ignition) when servicing controls. Wiring Errors can cause improper and dangerous op- The circulating air blower will energize eration.
  • Page 25 4. Check for 24 volts to ignition control 3. Improper gas pressure or burner air adjustment is not allowing flame to contact ignitor tip for flame proving a. No voltage at purge timer - check rectification. the centrifugal switch in the com- bustion motor.
  • Page 26: Troubleshooting

    K. High Gas Bills B. Oil Furnace The indicator light on the oil primary control 1. Check the combustion air adjustment. provides lockout, recycle, and cad cell 2. Be sure the proper size orifice is being indications as follows: used. 1.
  • Page 27 5. Jumper T to T terminals on primary b. If indicator light stops flashing, burner control. turns on, but control locks out again, check cad cell. If cad cell is Okay, a. If burner starts, check thermostat replace primary control. or limit wiring connections.
  • Page 28 INSTALLER: Please leave these installation instructions with the homeowner. ¢708657O¤ 708657C 708657C (Replaces 708657B) Specifications and illustrations subject to change without notice and without incurring obligations. Printed in U.S.A. (03/07) O’Fallon, MO...
