- Page 1 Models DE62T27CW1 DG62T27CW1 DE62T27DW1 DG62T27DW1 Supplementary to 517760B 517760C...
- Page 2 517760C...
- Page 3 517760C - APRIL 2007 REPRINT - AUGUST 2007 The specifications and servicing procedures outlined in this manual are subject to change without notice. The latest version is indicated by the reprint date and replaces any earlier editions. Note: This supplementary manual is only to be used in conjunction with service manual 517760B.
-
Page 4: Table Of Contents
517760C CONTENTS SERVICING REQUIREMENTS....................5 Health & Safety .......................5 Electrical Safety ......................5 Electrostatic Discharge ....................5 Good Working Practices ....................5 Safety Test ........................5 Sheet Metal Edges......................5 MODELS INFORMATION......................6 Models Number.......................6 Serial Number .........................6 Product Code ........................7 TECHNICAL OVERVIEW ......................7 Finish ..........................7 Electrical Supply......................7 Dimensions ........................7 Maximum Capacity (Full Load) .................. -
Page 5: Servicing Requirements
517760C SERVICING REQUIREMENTS Health & Safety Note: When servicing the AeroSmart electronic dryer, health and safety issues must be considered at all times. Specific safety issues are listed below to remind service people of the health and safety issues. Electrical Safety WARNING! TO AVOID ELECTRIC SHOCK! Do not attempt to service this dryer without suitable training and qualifications. -
Page 6: Models Information
517760C MODELS INFORMATION The product serial plate is located on the upper rear of the cabinet and contains the following information: Models Number The models number contains the following information: Product Type (Dryer) Heating Type (E = Electric / G = Gas) Capacity cu/ft (6.2) IEC Top Loading Size (27 inches wide) -
Page 7: Product Code
517760C Product Code A suffix letter has been added to the Product Code. This suffix letter will change whenever a part is changed that is not completely retro-fittable without the need for a kit, or whenever a cosmetic change is made. Model Product Code Serial... -
Page 8: Components
517760C COMPONENTS The only visual change of major components between the G (General), I (Intuitive™) and the AeroSmart™ dryer is with the console assembly. The Aerosmart™ LCD models incorporates an IMD (In-mould decorative display), which uses capacitive touch buttons that sense the user’s fingers over the buttons. It has a large LCD Display allowing us to show graphics on the screen. -
Page 9: Fascia
517760C Fascia LCD Models Power On/Off button. Wrinkle Free On/Off. When the LED is on the wrinkle free option is turned on. Wrinkle Free LED used also for data download (Refer to Section 7.4). Start/Pause button. LCD Screen. Left arrow (used when scrolling through options on the LCD screen). Right arrow (used when scrolling through options on the LCD screen). -
Page 10: Service Procedures
517760C SERVICE PROCEDURES Note: These instructions refer to the removal of the display module only. Refer to Service Manual 517760B for full servicing instructions. Note: Prior to carrying out any service procedures ensure that the machine has been isolated from the power supply. To remove the display module, follow the procedures as detailed below. -
Page 11: Diagnostics
517760C DIAGNOSTICS Overview – LCD Models If a fault occurs that prevents correct operation of the dryer, and is detected by the controllers, the dryer is stopped, the LCD shows a fault code and the beeper is continuously turned on and off. -
Page 12: Fault Code Summary
517760C User Warnings There are two possible user warnings. The machine is beeping and the lidlock light is flashing: Close the lid and press Start/Pause. If the lid is already closed, open and close it again, then press Start/Pause. Disconnect from the power (either by unplugging the dryer or turning off at the power supply). - Page 13 517760C Fault Code 7 Motor Current Excessive. Remedy: (1) Free up the dryer. Remove overload or cause of jamming. (2) Replace the motor control module. (3) Replace the motor. Fault Code 7b Display Module RAM Check Error (LCD Models only) On power up, the display has checked its memory against a known reference and found differences.
- Page 14 517760C Fault Code 20 Door Actuator Stalled. Remedy: As per fault code 21. Fault Code 21 Door Actuator Required Excess Voltage. Remedy: (1) Ensure there is no weight placed on the lid of the product (e.g. clothes basket). If so, remove the weight and retest. (2) Inspect the installation, making sure that the cabinet sits evenly on the floor.
- Page 15 517760C Fault Code 30 Lid Lock unable to Lock – (User Warning). Reason: The lid lock failed to lock. (Not user displayed.) Remedy: (1) Ensure the lid is closed and the tongue engaged. (2) Replace the lid lock harness. (3) Replace the lid lock. (4) Replace the sensor module.
-
Page 16: Diagnostic Mode - Lcd Models
517760C DIAGNOSTIC MODE – LCD MODELS Entering the Diagnostic Mode Press & Hold for 2 seconds To enter the DIAGNOSTIC MODE, turn the power on at the power point and off at the console. Press and hold the WRINKLE FREE button and then press the SELECT button. Keep the buttons pressed for at least 2 seconds, after which time two beeps will sound and the screen above will appear. -
Page 17: Machine Status Screen
517760C 7.2.2 Machine Status Screen Machine Status Screen Tacho: This displays position of the drum. The displayed figure is updated every five seconds and will change as the drum revolves. Exht tmp: This displays the temperature in C of the exhaust sensor. Actuator: This displays the count of the current draw of the actuator motor. -
Page 18: Showroom Mode
517760C Showroom Mode Press and Hold START/PAUSE, then press the SELECT button Showroom mode will play the introduction and repeat it continuously, until the dryer has been isolated from the power supply. To access the showroom mode follow the steps below. Turn the power supply to the dryer on. -
Page 19: Testing The Conductivity Contacts
517760C Testing the Conductivity Contacts Impedance Test To enter the conductivity impedance test mode, enter the diagnostic mode then press the TIME DRY button five times. In this mode, touching damp clothes or fingers across the conductivity contacts will cause the LED display to change. If the contacts, or harness to them, have gone open circuit, no change will occur in the LED display. -
Page 20: Cool Down
517760C COOL DOWN The dryer enters a cool down period at the end of the cycle. During this period the dryer continues to run with the heating elements/burner turned off, blowing ambient air through the load to help prevent creasing. Autosensing: If any AutoSensing cycle has been selected, the cool down period will continue until the exhaust temperature drops to 95 F (35... -
Page 21: Cycle Charts - Lcd Models
517760C CYCLE CHARTS – LCD MODELS 12.1 Electric This chart lists the available cycles that can be selected on the electric models, and provides information regarding these cycles. Main Cycles Cycle Heat Temperature Autosensing/ Dryness Level Door Closed Direction Additional Door open Direction Cooldown comments 3.6kW (2/3) - Page 22 517760C Life Cycles Heat Temperature Dryness Level Door Closed Direction Autosensing/ Additional Door open Direction Cooldown comments 3.6kW (2/3) 1.4kW 3.6kW (2/3) 1.4kW Timed Dry Special Care (1/3) (1/3) Handwash 127°F (53°C) Autosensing 95°F (35°C) or 10 Mins Wrinkle Free Jeans (Work &...
-
Page 23: 12.2 Gas
517760C 12.2 Gas This chart lists the available cycles that can be selected on the gas models, and provides information regarding these cycles. Main Cycles Cycle Heat Temperature Autosensing/ Dryness Level Door Closed Direction Additional Door open Direction Cooldown comments Ignition Timed Dry Delay... - Page 24 517760C Life Cycles Heat Temperature Dryness Level Autosensing/ Additional Door Closed Direction Door open Direction Cooldown comments Ignition Timed Dry Special Care Delay Heating Handwash 127°F (53°C) Autosensing 95°F (35°C) or 10 Mins Wrinkle Free 2m 20s No Heat Jeans (Work & Fashion) High 149°F (65°C) Autosensing...
-
Page 25: Cycle Charts - Led Models
517760C CYCLE CHARTS – LED MODELS 13.1 Electric This chart lists the available cycles that can be selected on the electric models, and provides information regarding these cycles. Main Cycles Cycle Heat Temperature Autosensing/ Dryness Level Additional Door Closed Direction Door open Direction Cooldown comments 3.6kW (2/3) -
Page 26: Wiring Diagram - Electric Models
517760C WIRING DIAGRAM – ELECTRIC MODELS ELECTRIC MODELS... -
Page 27: Wiring Diagram - Gas Models
517760C WIRING DIAGRAM – GAS MODELS GAS MODELS... - Page 28 517760C...
- Page 29 517760C Notes...
