Mechanical LBC 3081/02 Dimensions (dia. x max. depth) 157 x 70 mm (6.2 x 2.8 in) Weight 360 g (0.8 lb) Color Flame red (RAL 3000) Certified B15 Acc. to DIN 4102 Bosch Security Systems B.V. Installation note 2016.12 | V1.03 |...
Page 6
The reference plane is perpendicular to the center of the reference axis – The horizontal plane is perpendicular to the center of the reference plane Figure 2.1: Circuit diagram Figure 2.2: Frequency response Figure 2.3: Polar diagram 2016.12 | V1.03 | Installation note Bosch Security Systems B.V.
Page 7
Ceiling loudspeaker Technical data | en Figure 2.4: CE-label Bosch Security Systems B.V. Installation note 2016.12 | V1.03 |...
