OWNER'S MANUAL
MODEL NO. 271470
13.5 HP 38 INCH
LAWN TRACTOR
•
Assembly
•
Operation
•
Maintenance
•
For Parts and Service, contact our authorized distributor:
call 1-800-849-1297
For Technical Assistance: call 1-800-829-5886
Service and Adjustments
•
Troubleshooting
•
Repair Parts
177110 Rev. 1 01.30.01 RH
PRINTED IN U.S.A.
Advertisement
Table of Contents
Related Manuals for Poulan Pro 177110
Summary of Contents for Poulan Pro 177110
- Page 1 LAWN TRACTOR • Assembly • Operation • Maintenance • Service and Adjustments • For Parts and Service, contact our authorized distributor: call 1-800-849-1297 For Technical Assistance: call 1-800-829-5886 177110 Rev. 1 01.30.01 RH Troubleshooting • Repair Parts PRINTED IN U.S.A.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Rules ... 2 Maintenance ... 16 Product Specifications ... 5 Service and Adjustments ... 20 Assembly ... 7 Storage ... 25 Operation ... 10 Troubleshooting ... 26 Maintenance Schedule ... 16 Repair Parts ... 30 Warranty ... 46 SAFETY RULES IMPORTANT: This cutting machine is capable of amputating hands and feet and throwing objects. -
