DSST~2801~A.qxd 1/25/2003 6:45 PM Page 1
Multi-HANDSET, Multi-BASE UNIT 2.4GHz
Digital Spread Spectrum Technology
CORDLESS ALL DIGITAL ANSWERING SYSTEM
WITH CALLER ID/CALL WAITING
77 CHANNEL AUTOHOP
Model XG2801
OWNER'S MANUAL
INSTALLATION AND
OPERATING INSTRUCTIONS
PLEASE READ THIS
MANUAL CAREFULLY
BEFORE USE.
KEEP FOR YOUR
REFERENCE.
For installation information,
please see "Getting Started"
instructions on page 6 or your
separate Quick Start guide.
Visit Us on the Web:
www.uselectronics.info
© 2002 BellSouth Corporation
Advertisement
Table of Contents
Related Manuals for BellSouth XG2801
Summary of Contents for BellSouth XG2801
- Page 1 OPERATING INSTRUCTIONS PLEASE READ THIS MANUAL CAREFULLY BEFORE USE. KEEP FOR YOUR REFERENCE. For installation information, please see “Getting Started” instructions on page 6 or your separate Quick Start guide. Visit Us on the Web: www.uselectronics.info © 2002 BellSouth Corporation...
- Page 2 DSST~2801~A.qxd 1/25/2003 6:45 PM Page 2 Special Features Special Features CALLER ID SYSTEM ongratulations on your selection of a quality XACT Product. With proper care and adherence to the set-up and user instructions in this Owner's Manual, this unit will provide Multi-Function Large LCD Screen - Shows the number you are dialing and, with Caller ID service you with years of trouble-free service.
- Page 3 DSST~2801~A.qxd 1/25/2003 6:45 PM Page 4 Special Features HANDSET Controls ANSWERING SYSTEM FEATURES Fully Digital Answering System - Provides a full range of answering functions without using cassette tapes. Digital Memory - Allows recording of memos and messages. 9. HANDSET ANTENNA Two-Digit LED Message Display - Indicates the number of messages, indicates the status of the system.
- Page 4 DSST~2801~A.qxd 1/25/2003 6:46 PM Page 6 HANDSET Controls BASE UNIT Controls /MENU Button: (VOLUME) During TALK mode, press to adjust the receiver volume to a comfortable listening level. (MENU) Press to access the special functions operation in STANDBY mode. (For special functions see pages 21~27.) 1.
- Page 5 DSST~2801~A.qxd 1/25/2003 6:46 PM Page 8 BASE UNIT Controls BASE UNIT Controls Button: Press and hold down to record memo messages. (MAILBOX 2) Button: Press to activate functions for MAILBOX 2. MAIL MEMO Button: Press to set/check the day and time. (MAILBOX 3) Button: Press to activate functions for MAILBOX 3.
-
Page 6: Table Of Contents
DSST~2801~A.qxd 1/25/2003 6:46 PM Page 10 Contents Contents Safety Instructions ......................4 Forwarded Calls....................20 Getting Started.........................6 Long Distance Calls....................20 Desk Mounting ........................ 9 Outgoing Calls....................... 21 Wall Mounting........................9 Function Settings....................21 Cordless Telephone Operation..................10 A. Setting the Ringer Level................22 Preparing for Use....................... -
Page 7: Safety Instructions
DSST~2801~A.qxd 1/25/2003 6:46 PM Page 12 Contents Safety Instructions When the Memory is Full..................35 IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of fire, electric shock and/or injury, always follow these Two-Way Recording....................35 basic safety precautions when using your cordless telephone equipment. Remote Operation through a Tone Telephone............ -
Page 8: Getting Started
DSST~2801~A.qxd 1/25/2003 6:46 PM Page 14 Safety Instructions Getting Started Connecting Your Phone E. If the telephone has been dropped or the case has been damaged. F. If the telephone exhibits a distinct change in performance. This section is a reference guide to the basic functions and operations of your cordless 16. - Page 9 COVER the dial tone continues, it means that you You are now ready to use your new do not have TONE dialing service. Press BellSouth Cordless Telephone. button on the HANDSET to hang TALK up. Set the TONE/PULSE Select Switch IMPORTANT to the PULSE mode and then try again.
-
Page 10: Desk Mounting
DSST~2801~A.qxd 1/25/2003 6:46 PM Page 18 Desk Mounting Cordless Telephone Operation Preparing for Use Desk Mounting Before you can use your cordless telephone, you must charge the HANDSET for 12 hours. For normal position, place the BASE UNIT on any desired but suitable Failure to do so will require recharging of the BATTERY PACK more often. -
Page 11: Placing Calls
DSST~2801~B.qxd 1/25/2003 7:03 PM Page 2 Cordless Telephone Operation Cordless Telephone Operation Placing Calls Extension In Use Indicator 1. Press the button. “Talk” will display and the Call TALK This telephone can detect when a HANDSET is already Timer starts to count. in use. -
Page 12: Caller Id System Operation
DSST~2801~B.qxd 1/25/2003 7:03 PM Page 4 Caller ID System Operation Caller ID System Operation Caller ID System Caller ID with Call Waiting This telephone automatically displays an incoming caller’s name and telephone number When you subscribe to Call Waiting service from your local telephone company, this together with the date and time of the call. -
Page 13: Viewing The Caller List
DSST~2801~B.qxd 1/25/2003 7:03 PM Page 6 Caller ID System Operation Caller ID System Operation Viewing the Caller List Storing Caller ID Records into the DIRECTORY (PHONE BOOK) 1. When viewing the Caller ID List, press the SCROLL UP or DOWN button to 1. -
Page 14: Name And Telephone Number Directory (Phone Book)
DSST~2801~B.qxd 1/25/2003 7:03 PM Page 8 Caller ID System Operation Caller ID System Operation Name and Telephone Number DIRECTORY (PHONE BOOK) Telephone Keypad Characters The TELEPHONE KEYPAD buttons are used to enter characters when entering names and This DIRECTORY (PHONE BOOK) lets you scroll through the list to find the person you need for one numbers. -
Page 15: Placing Calls From The Directory (Phone Book)
DSST~2801~B.qxd 1/25/2003 7:03 PM Page 10 Caller ID System Operation Caller ID System Operation Placing Calls from the DIRECTORY (PHONE BOOK) Deleting a Stored Record in the DIRECTORY (PHONE BOOK) 1. Press the button. The LCD Screen will display “Phone book.” 1.
