Manual de Instrucciones
Manuel d'Instructions
For Occasional Use Only
WARNING:
Read and follow all Safety Rules and Operating Instructions before
using this product. Failure to do so can result in serious injury.
ADVERTENCIA:
Lea el manual de instrucciones y siga todas las advertencias e en-
strucciones de seguridad. El no hacerlo puede resultar en lesiones
graves.
AVERTISSEMENT:
Lire le manuel d'instructions et bien respecter tous les avertisse-
ments et toutes les instructions de sécurité. Tout défaut de le faire
pourrait entraîner des blessures graves.
Electrolux Home Products, Inc.
104 Warren Road
Augusta, GA 30907
Copyright E2004 Electrolux Home Products, Inc.
Instruction Manual
220 / 260
Electrolux Canada Corporation
6150 McLaughlin Road
Mississauga, ON L5R 4C2
530164806
R
1/14/04
Advertisement
Table of Contents
Related Manuals for Poulan Pro 2004-01
Summary of Contents for Poulan Pro 2004-01
- Page 1 Instruction Manual Manual de Instrucciones Manuel d’Instructions For Occasional Use Only WARNING: Read and follow all Safety Rules and Operating Instructions before using this product. Failure to do so can result in serious injury. ADVERTENCIA: Lea el manual de instrucciones y siga todas las advertencias e en- strucciones de seguridad.
-
Page 2: Identification Of Symbols
IDENTIFICATION OF SYMBOLS WARNING! This chain saw can be dangerous! Care- less or improper use can cause serious or even fatal injury. Always wear appropriateear protection, eye protection and head protection. Always use two hands when operating the chain saw. WARNING! Contacting the guide bar tip with any object should be avoided;... - Page 3 S Keep the handles dry, clean, and free of oil or fuel mixture. S Keep fuel and oil caps, screws, and fas- teners securely tightened. S Use only Poulan PROR accessories and replacement parts as recommended. HANDLE FUEL WITH CAUTION S Do not smoke while handling fuel or while operating the saw.
-
Page 4: Maintain Control
Clear The Working Area REDUCE THE CHANCE OF KICKBACK S Recognize that kickback can happen. With a basic understanding of kickback, you can reduce the element of surprise which contributes to accidents. S Never let the moving chain contact any ob- ject at the tip of the guide bar. -
Page 5: Safety Notice
Symmetrical Guide Bar Large Radius Tip S Low- -Kickback Chain, designed with a contoured depth gauge and guard link which deflect kickback force and allow wood to gradually ride into the cutter. Low- - Kickback Chain has met kickback per- formance requirements when tested on a representative sample of chain saws be- low 3.8 cubic inch displacement specified... -
Page 6: Special Notice
abnormal swellings. Prolonged use in cold weather has been linked to blood vessel damage in otherwise healthy people. If symptoms occur such as numbness, pain, loss of strength, change in skin color or texture, or loss of feeling in the fingers, hands, or joints, discontinue the use of this tool and seek medical attention. -
Page 7: Chain Tension
6. Place the chain over and behind the clutch, fitting the drive links in the clutch drum sprocket. Place chain onto the sprocket 7. Fit bottom of drive links between the teeth in the sprocket in the nose of the guide bar. -
Page 8: Operation
OPERATION KNOW YOUR SAW READ THIS INSTRUCTION MANUAL AND SAFETY RULES BEFORE OPERATING YOUR CHAIN SAW. Compare the illustrations with your unit to familiarize yourself with the location of the various controls and adjustments. Save this manual for future reference. Chain Front Hand Guard Adjustment Tool... - Page 9 Bar and chain oil must be free flowing for the oil system to pump enough oil for adequate lubrication. Genuine Poulan or Poulan PROR bar and chain oil is recommended to protect your unit against excessive wear from heat and friction.
-
Page 10: Cutting Methods
5. Push the choke/fast idle lever in to the HALF CHOKE position. CHOKE/FAST IDLE LEVER (SIDE VIEW) Choke/ fast idle lever HALF FULL 6. Pull the starter rope quickly with your right hand until the engine starts. 7. Allow the engine to run for approximately 5 seconds. -
Page 11: Tree Felling Techniques
S Release the throttle trigger as soon as the cut is completed, allowing the en- gine to idle. If you run the saw at full throttle without a cutting load, unneces- sary wear can occur to the chain, bar, and engine. S To avoid losing control when cut is com- plete, do not put pressure on saw at end of cut. - Page 12 CUTTING A FALLEN TREE (BUCKING) Bucking is the term used for cutting a fallen tree to the desired log size. WARNING: Do not stand on the log being cut. Any portion can roll causing loss of footing and control. Do not stand downhill of the log being cut.
- Page 13 Using a support stand LIMBING AND PRUNING WARNING: Be alert for and guard against kickback. Do not allow the moving chain to contact any other branches or ob- jects at the nose of the guide bar when limb- ing or pruning. Allowing such contact can re- sult in serious injury.
-
Page 14: Carburetor Adjustment
Cleaning the air filter: A dirty air filter decreases engine perform- ance and increases fuel consumption and harmful emissions. Always clean after 15 tanks of fuel or 5 hours of operation, which- ever comes first. Clean more frequently in dusty conditions. A used aire filter can never be completely cleaned. -
Page 15: Need Assistance
Replace guide bar when the groove is worn, the guide bar is bent or cracked, or when exce- ss heating or burring of the rails occurs. If re- placement is necessary, use only the guide bar specified for your saw in the repair parts list or on the decal located on the chain saw. -
Page 16: Limited Warranty
LIMITED WARRANTY ELECTROLUX HOME PRODUCTS, INC., warrants to the original purchaser that each new Poulan PROR brand gasoline chain saw is free from defects in material and workmanship and agrees to repair or replace under this warranty any defective gasoline chain saw as follows from the original date of purchase. - Page 17 U.S. EPA / ENVIRONMENT CANADA EMISSION CONTROL WARRANTY STATEMENT YOUR WARRANTY RIGHTS AND OB- LIGATIONS: The U. S. Environmental Protection Agency, Environment Canada and ELECTROLUX HOME PRODUCTS, INC., are pleased to explain the emissions control system warranty on your year 2002- -2004 small off- -road engine.
- Page 18 The information on the product label indicates which standard your engine is certified. Example: (Year) EPA Phase 1 or Phase 2 and/or CALIFORNIA. This engine is certified to be emissions compliant for the following use: Moderate (50 hours) Intermediate (125 hours) Extended (300 hours)
