WARNING: If not installed, operated and
maintained in accordance with the manu-
facturer's instructions, this product could
expose you to substances in fuel or from
fuel combustion which can cause death or
serious illness.
R-1584
INSTALLATION INSTRUCTIONS
OWNER'S MANUAL
AND
FAN TYPE
VENTED
WALL FURNACE
MODEL
FAW-55SPP
EFFECTIVE DATE
AUGUST, 2000
WARNING: If the information in this
manual is not followed exactly, a fire or
explosion may result causing property
damage, personal injury or loss of life.
— Do not store or use gasoline or other
flammable vapors and liquids in the vi-
cinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do
not use any phone in your building.
•
Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
•
If you cannot reach your gas supplier,
call the fire department.
— Installation and service must be per-
formed by a qualified installer, service
agency or the gas supplier.
Page 1
Advertisement
Table of Contents
Related Manuals for Empire Comfort Systems FAW-55SPP
Summary of Contents for Empire Comfort Systems FAW-55SPP
- Page 1 INSTALLATION INSTRUCTIONS OWNER'S MANUAL FAN TYPE VENTED WALL FURNACE MODEL FAW-55SPP EFFECTIVE DATE AUGUST, 2000 WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
- Page 2 Specifications This series is design certified in accordance with American National Standard / CSA Standard Z21.86b-1998 and CSA 2.32b-M98 by the Model FAW-55SPP American Gas Association and Canadian Gas Association, as a Fan Input BTU/HR (KW/H) 55,000 (16.1) Type Vented Wall Furnace and must be installed according to these Height 82 3/8"...
-
Page 3: Safety Information For Users Of Lp-Gas
SAFETY INFORMATION FOR USERS OF LP-GAS by point with the members of your household. Someday Propane (LP-Gas) is a flammable gas which can cause fires and explosions. In its natural state, propane is odorless and when there may not be a minute to lose, everyone's safety will colorless. - Page 4 Ventilation and Combustion Air Installing Optional Side Outlets Wall furnaces shall be installed in a location in which the facilities for Side outlet register, SOR-1 may be installed on one or both sides of the ventilation permit satisfactory combustion of gas and proper venting furnace at the required clearances of 18 inches (457mm) to adjacent wall under normal conditions.
- Page 5 4" (102mm) MINIMUM 4" (102mm) MINIMUM TO COMBUSTIBLES TO COMBUSTIBLES WHEN SIDE REGISTERS ARE NOT USED UNIT MAY BE RECESSED 4" (102mm) 5 1/2" (140mm) 5 1/2" (140mm) 16" (406mm) Figure 1 3 1/4" (83mm) 11 1/2" (292mm) 4" (102mm) OVAL TYPE "B" CONNECTION Figure 3 Figure 3A...
- Page 6 4. Connect nylon cap on 3' (914mm) plug assembly to nylon plug on the The use of the following gas connectors is recommended: wiring harness. — ANS Z21.24 Appliance Connectors of Corrugated Metal Tubing 5. Place 7/8" (22mm) strain relief bushing around the cord of the 3' and Fittings (914mm) plug assembly.
-
Page 7: Proper Flame Adjustment
To light the pilot, it is important that the electrode be 1/8" (3mm) from at each end of the motor. Use a few drops of #10 motor oil. To clean the the thermocouple. The spark must occur at the point the burner flame motor, blow air through its ventilation openings with a vacuum cleaner hits the thermocouple. - Page 8 "shut off" due to improper venting or a blocked flue. 4. Type of gas being used and that shown on the rating label. The Service Department at Empire Comfort Systems, Inc. may be To reset the manual reset vent safety switch: contacted to assist in servicing furnace.
-
Page 9: For Your Safety Read Before Lighting
FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance has a pilot which must be lighted by •... - Page 10 Do not order bolts, screws, washers or nuts. They are standard hardware items and can be purchased at any local hardware store. Shipments contingent upon strikes, fires and all causes beyond our control. Empire Comfort Systems, Inc. Nine Eighteen Freeburg Ave. Belleville, Illinois 62222-0529...
- Page 11 R-1584 Page 11...
- Page 12 Model No. FAW-55 may be vented as shown. The vent cap must be at least 12 feet (3.7m) above the floor. Clearance to combustible construction is held by the fixed spacers at 1 inch (25mm) with B-1 vent pipe. Installation must conform to local codes. 4"...
